- Page 1 OWNER’S MANUAL HIGH WALL INVERTER (English) (BSHVD1S SERIES)
- Page 2 Warranty terms are subject to property access and industry safety standards.) OPTIONAL MULTI- INDOOR OUTDOOR CAPACITY SPLIT OUTDOOR MODEL MODEL COOL / HEAT BSHV25D1S BCHV25D1S 2.6 kW / 2.8 kW MCHV54D12 BSHV35D1S BCHV35D1S 3.5 kW / 3.85 kW MCHV73D13 BSHV50D1S BCHV50D1S 5.2 kW / 5.85 kW...
-
Page 3: Table Of Contents
CONTENTS MAIN COMPONENTS..................2 INTRODUCTION & SAFETY ................3 OPERATION REMOTE CONTROLLER................4 CONTROLLER LAYOUT................5 CONTROLLER DISPLAY LAYOUT ..............5 ON/OFF ......................6 MODE ......................6 FAN SPEED....................6 BUTTONS ...................6 ▲ ▼ CLOCK ......................6 TIMER SETTINGS..................7 SWING UP / DOWN ..................7 X-FAN ......................7 TURBO ......................7 TEMP ......................8 SLEEP ......................8 I FEEL......................8 CHILD LOCK....................8... -
Page 4: Main Components
MAIN COMPONENTS INDOOR UNIT cooling power receiver indicator indicator window heating temp. drying indicator indicator indicator NOTE: Display panel style or position may differ from the above graphics. OUTDOOR UNIT Air inlet SINGLE SPLIT OR MULTI-SPLIT UNIT Air inlet Front panel Aux. -
Page 5: Introduction & Safety
SUBSTANTIAL FINES. Warranty Booklet. WHERE SPECIFIED, ONLY The installer must read the Installation QUALIFIED AND LICENSED Manual before installing the Braemar TECHNICIANS SHOULD PERFORM High Wall Inverter Air Conditioning WORK ON THIS UNIT, FAILING Unit. The home owner/user should WHICH THE WARRANTY ON THE read the Owner's Manual before UNIT WILL BE VOID. -
Page 6: Operation
OPERATION Your Braemar High Wall Air CHANGING BATTERIES Conditioning Unit has been designed Push down on the battery panel to and built with reliable, quality open the battery compartment area. components. To ensure many years of trouble free, dependable service Insert 2 x AAA 1.5V batteries, ensuring... -
Page 7: Controller Layout
OPERATION cont. CONTROLLER LAYOUT Signal transmitter FAN button MODE button ON/OFF button FAN button buttons ▲ ▼ SWING button CLOCK button TIMER ON / TURBO button OFF buttons TEMP button SLEEP button HEALTH / X-FAN VENT button LIGHT button I FEEL button CONTROLLER DISPLAY LAYOUT Set fan speed feel... -
Page 8: On/Off
OPERATION cont. ON / OFF FAN SPEED Press to turn the power on or off. Press the FAN button to toggle SLEEP function will be cancelled when between AUTO, Low, Medium and power is turned off. High speed. AUTO MODE Press to toggle between AUTO, AUTO fan speed is default on power COOL, DRY, FAN and HEAT modes. -
Page 9: Timer Settings
OPERATION cont. TIMER SETTINGS SWING UP / DOWN The unit can be programmed to turn Press to adjust the UP/DOWN louvre, on, turn off or a combination of both each press will toggle between the when in standby or power ON modes. below settings:- Use the below settings. -
Page 10: Temp
OPERATION cont. SLEEP cont. TEMP In HEAT mode, the SET temperature Press the TEMP button to toggle will decrease by 1°C and then 2°C for between the following on the indoor the first 2 hours, and then stay display:- constant. SET temperature (room target temperature). -
Page 11: Light
OPERATION cont. LIGHT Press the LIGHT button to toggle between LIGHT ON and LIGHT OFF status. Default is LIGHT ‘ON’. ENERGY SAVING When in COOL mode, press the TEMP and CLOCK buttons simultaneously to start Energy Saving function. The remote controller display will show the ‘SE’... -
Page 12: Error Display
OPERATION cont. ERROR DISPLAY Your High Wall air conditioner includes abnormal operation detection hardware and software. If the unit enters an abnormal state, the temperature indicator on the fascia display will blink to display a corresponding error code. Indoor display Error code (example only) Error codes and their meanings are shown below: Error Code... -
Page 13: Maintenance & Service
MAINTENANCE & SERVICE SAFETY INDOOR COIL (REFER PAGE 2) Ensure drain connections are checked Always isolate power for the air on an annual basis (as set out in the conditioner from electricity mains Maintenance Schedule below). Drains before cleaning or maintenance. can become blocked by all types of insects, and rats have been known to AIR FILTER... -
Page 14: Maintenance Schedule
Braemar High Wall Inverter Air Conditioning Unit as per the items and frequency set out in the Schedule, and as indicated elsewhere in this Manual. -
Page 15: Operation Tips
OPERATION TIPS The following events may occur during normal operation: 1. Protection of the air conditioner. Compressor protection • The compressor cannot restart for 3 minutes after it stops. • The supply air drops below a pre-determined set point; this prevents the indoor coil from freezing. -
Page 16: Troubleshooting
TROUBLESHOOTING Problem Probable Cause Remedy 1. The air conditioner 1.1 Power failure. 1.1 Wait for power to resume. does not run. 1.2 Fuse blown or circuit 1.2 Replace the fuse or reset breaker open. the breaker. 1.3 Thermostat adjustment 1.3 Check thermostat setting. too low (in heating mode) In ‘I FEEL’... -
Page 17: Warranty & Service
WARRANTY & SERVICE For prompt, efficient service, please follow the above before calling the appropriate number below. For Refrigerated Cooling Issues 1300 526 477 When calling the Warranty Service number, please ensure you have your model and serial number available, along with date of purchase, and if possible a description of the problem. - Page 18 NOTES BSHVD1S Series High Wall Inverter Unit...
- Page 19 NOTES cont. SEELEY INTERNATIONAL – OWNER’S MANUAL...
- Page 20 It is the policy of Seeley International to introduce continuous product improvements. Accordingly, specifications are subject to change without notice. Please consult with your dealer to confirm the specifications of the model selected. Warranty Service Refrigerated Cooling 1300 526 477 seeleyinternational.com braemar.net.au AU 1507 BSHV25D1S01-A...
