INTRODUCTION
T h i s s e r v i c e m a n u a l d e s c r i b e s t h e l a t e s t s e r v i c e
information for the IC-F24/IC-F24S/IC-F25/IC-F25S UHF
TRANSCEIVER at the time of publication.
MODEL VERSION SYMBOL
USA–02
USA–03
IC–F24
GEN–02
GEN–03
USA–02
USA–03
IC–F24S
GEN–02
GEN–03
IC–F25 EUR–02
IC–F25S EUR–02
To upgrade quality, all electrical or mechanical parts and
internal circuits are subject to change without notice or
obligation.
DANGER
NEVER connect the transceiver to an AC outlet or to a DC
power supply that uses more than 8 V. Such a connection
could cause a fire or electric hazard.
DO NOT expose the transceiver to rain, snow or any liquids.
DO NOT reverse the polarities of the power supply when
connecting the transceiver.
DO NOT apply an RF signal of more than 20 dBm (100mW)
to the antenna connector. This could damage the trans-
ceiver's front end.

ORDERING PARTS

Be sure to include the following four points when ordering
replacement parts:
1. 10-digit order numbers
2. Component part number and name
3. Equipment model name and unit name
4. Quantity required
<SAMPLE ORDER>
2260002840 Switch SKHLLFA010
8930063350 Lens 2775 Lens
Addresses are provided on the inside back cover for your
convenience.
1. Make sure the problem is internal before disassembling the transceiver.
2. DO NOT open the transceiver until the transceiver is disconnected from its power source.
3. DO NOT force any of the variable components. Turn them slowly and smoothly.
4. DO NOT short any circuits or electronic parts. An insulated turning tool MUST be used for all adjustments.
5. DO NOT keep power ON for a long time when the transceiver is defective.
6. DO NOT transmit power into a signal generator or a sweep generator.
7. ALWAYS connect a 30 dB to 40 dB attenuator between the transceiver and a deviation meter or spectrum analyzer when
using such test equipment.
8. READ the instructions of test equipment thoroughly before connecting equipment to the transceiver.
Icom, Icom Inc. and are registered trademarks of Icom Incorporated (Japan) in the United States, the United Kingdom,
Germany, France, Spain, Russia and/or other countries.
CH FREQUENCY
US2 16 400–470 MHz
US3 16 450–512 MHz
GE2 16 450–470 MHz
GE3 16 450–520 MHz
US2S 2 400–470 MHz
US3S 2 450–512 MHz
GE2 2 400–470 MHz
GE3 2 450–520 MHz
EU2 16 400–470 MHz
EU2S 2 400–470 MHz
IC-F24 Main unit 5 pieces
IC-F24 Chassis 10 pieces

REPAIR NOTES
