NVIDIA SLI
is a revolutionary technology that allows two NVIDIA SLI graphics cards to work
together to deliver incredible 3D graphics performance.
To assist the do-it-yourself community, NVIDIA is providing the following guide on how to set-up
an NVIDIA SLI system.
Note: this guide assumes basic knowledge of how to build or upgrade a PC. If you do not feel comfortable with this level
of know how, please refer to our list of
build or upgrade a PC.
STEP ONE
Determine your NVIDIA SLI component and operating system needs:
The following components are required:
1. An NVIDIA SLI-certified motherboard with NVIDIA SLI Connector
2. Two NVIDIA SLI-certified add-in cards
3. Windows XP operating system
Check here for a list of
the best gaming and application experiences.
STEP TWO
Determine your power needs:
Based on testing at NVIDIA's SLI Validation lab, the following power supply suggestions should
be followed.
NVIDIA SLI System Type
High-End: GeForce 6800 Ultra
Mid-Range: GeForce 6800 GT or 6800
Entry-Level: GeForce 6600 GT
If the power supply specifies two 12V windings (i.e. 12V1 and 12V2), then these current numbers
can be added together to check against the specifications described above.
For systems with the 6800 Ultra or 6800 GT, please make sure the power supply also contains a
PCI Express auxiliary power supply connector:
where to buy pre-built NVIDIA SLI
NVIDIA SLI-certified motherboards and
Minimum Recommended PCI Express Power
Supply
500W–550W, +12V @ 30A
420W–480W, +12V @ 25A
350W–420W, +12V @ 20A
systems, or refer to other resources on how to
add-in-cards, for
