Hardware Installation
Installation and initialization of ConnectX-5 adapter cards require attention to the mechanical attributes, power specification, and precautions for electronic
equipment.

Safety Warnings

Safety warnings are provided here in the English language. For safety warnings in other languages, refer to the
Instructions
document available on
Please observe all safety warnings to avoid injury and prevent damage to system components. Note that not all warnings are relevant to all models.
Note that not all warnings are relevant to all models.
General Installation Instructions
Read all installation instructions before connecting the equipment to the power source.
Jewelry Removal Warning
Before you install or remove equipment that is connected to power lines, remove jewelry such as bracelets, necklaces, rings, watches and
so on. Metal objects heat up when connected to power and ground and can meltdown, causing serious burns and/or welding the metal
object to the terminals.
Over-temperature
This equipment should not be operated in an area with an ambient temperature exceed-ing the maximum recommended: 55°C (131°F). An
airflow of 200LFM at this maximum ambient temperature is required for HCA cards and NICs. To guarantee proper airflow, allow at least
8cm (3 inches) of clearance around the ventila-tion openings.
During Lightning - Electrical Hazard
During periods of lightning activity, do not work on the equipment or connect or dis-connect cables.
Copper Cable Connecting/Disconnecting
Some copper cables are heavy and not flexible, as such they should be carefully attached to or detached from the connectors. Refer to the
cable manufacturer for spe-cial warnings and instructions.
Equipment Installation
This equipment should be installed, replaced, or serviced only by trained and qualified personnel.
Equipment Disposal
Disposal of this equipment should be in accordance to all national laws and regula-tions.
Local and National Electrical Codes
This equipment should be installed in compliance with local and national electrical codes.
Hazardous Radiation Exposure
Caution – Use of controls or adjustment or performance of procedures other than those specified herein may result in hazardous
radiation exposure.For products with optical ports.
CLASS 1 LASER PRODUCT and reference to the most recent laser standards:
IEC 60 825-1:1993 + A1:1997 + A2:2001 and EN 60825-1:1994+A1:1996+ A2:20

Installation Procedure Overview

The installation procedure of ConnectX-5 adapter cards involves the following steps:
Step
Procedure
1
Check the system's hardware and software requirements.
nvidia.com
.
Adapter Installation Safety

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ConnectX-5 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Nvidia ConnectX-5

  • Page 1 Hardware Installation Installation and initialization of ConnectX-5 adapter cards require attention to the mechanical attributes, power specification, and precautions for electronic equipment. Safety Warnings Safety warnings are provided here in the English language. For safety warnings in other languages, refer to the...
  • Page 2 Specifications section of the manual for more power requirements. Airflow Requirements ConnectX-5 adapter cards are offered with two airflow patterns: from the heatsink to the network ports, and vice versa, as shown below. Please refer to the Specifications section for airflow numbers for each specific card model.
  • Page 3 All cards in the system should be planned with the same airflow direction. Software Requirements Operating Systems/Distributions section under the Introduction section. Software Stacks - NVIDIA OpenFabric software package MLNX_OFED for Linux, WinOF-2 for Windows, and VMware. See the Driver Installation section. Unpacking the Product The adapter is being installed in a system that operates with voltages that can be lethal.
  • Page 4 Be careful not to put stress on the LEDs on the adapter card. Save the two screws. Installing the New Bracket Place the bracket onto the card until the screw holes line up. Do not force the bracket onto the adapter card. Screw on the bracket using the screws saved from the bracket removal procedure above.
  • Page 5 Secure the adapter with the adapter clip or screw. To uninstall the adapter card, see Uninstalling the Card Cables and Modules To obtain the list of supported NVIDIA cables for your adapter, please refer to the Cables Reference Table at http://www.nvidia.com/products/interconnect /cables-configurator.php Cable Installation All cables can be inserted or removed with the unit powered on.
  • Page 6 VEN and DEV (fields are separated by ‘&’). In the display example above, notice the sub-string “PCI\VEN_15B3&DEV_1003”: VEN is equal to 0x15B3 – this is the Vendor ID of NVIDIA; and DEV is equal to 1018 (for ConnectX-5) – this is a valid NVIDIA PCI Device ID.
  • Page 7 Uninstalling the Card Safety Precautions The adapter is installed in a system that operates with voltages that can be lethal. Before uninstalling the adapter card, please observe the following precautions to avoid injury and prevent damage to system components. Remove any metallic objects from your hands and wrists. It is strongly recommended to use an ESD strap or other antistatic devices.
