RANGE HOODS
INSTALLATION INSTRUCTIONS - USE AND CARE
HB0062
MODELS ESB10, QDE, AND ESC270
!
READ AND SAVE THESE INSTRUCTIONS
INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER.
HOMEOWNER: CLEANING AND OPERATION INFORMATION
REGISTER YOUR PRODUCT ONLINE AT: www.venmar.ca
INTENDED FOR DOMESTIC COOKING ONLY
ON PAGES 9 AND 10.
!
SV06727 rev. 05

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ESB10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Broan ESB10

Summary of Contents for Broan ESB10

  • Page 1 RANGE HOODS INSTALLATION INSTRUCTIONS - USE AND CARE HB0062 MODELS ESB10, QDE, AND ESC270 INTENDED FOR DOMESTIC COOKING ONLY READ AND SAVE THESE INSTRUCTIONS INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER. HOMEOWNER: CLEANING AND OPERATION INFORMATION ON PAGES 9 AND 10.
  • Page 2 WARNING WARNING TO REDUCE THE RISK OF FIRE, ELECTRIC TO REDUCE THE RISK OF INJURY TO SHOCK INJURY PERSONS, PERSONS IN THE EVENT OF A RANGE TOP OBSERVE THE FOLLOWING: GREASE FIRE, OBSERVE THE FOLLOWING*: 1. Use this unit only in the manner intended by the 1.

  • Page 3: Table Of Contents

    ABOUT THIS MANUAL Please take note this manual uses the following symbols to emphasize particular information: WARNING Identifies an instruction which, if not followed, might cause serious personal injuries including possibility of death. CAUTION Denotes an instruction which, if not followed, may severely damage the unit and/or its components.

  • Page 4: Install Ductwork

    1. INSTALL DUCTWORK Plan where and how the ductwork will be installed. The ducting from this fan to the outside of the building has a strong effect on the air flow, noise and energy use of the fan. Use the shortest, straightest duct routing possible for best performance, and avoid installing the fan with smaller ducts than recommended.

  • Page 5: Prepare The Installation

    3. PREPARE THE INSTALLATION Make sure the following items are included: • Hood • Filters (2) • Adapter/damper assembly 3¼” x 10’’ (located inside the hood, under the bottom panel) • Compact fluorescent lamps (120 V, 13 W, PLC13, 2700 K with G24q-1 base) (packed behind the light diffuser) •...

  • Page 6: Prepare The Hood

    4. PREPARE THE HOOD Remove both filters from the hood. Disassemble the adapter/damper (A) from the hood. NOTE: The adapter/damper is located inside the hood. Remove the bottom panel (B) to access the adapter/damper. Refer to figure at right. HO0091 Punch out the appropriate electrical knock-out hole.

  • Page 7: Install The Adapter/Damper

    5. INSTALL THE ADAPTER/DAMPER NOTE: If this hood replaces another one, please note that the location of the air exhaust can vary from one manufacturer to another. HORIZONTAL DISCHARGE, HORIZONTAL DISCHARGE, NEW INSTALLATION HOOD REPLACEMENT Fold down the foldable flange (A) of the It may be necessary to adjust the adapter/ adapter/damper.

  • Page 8: Install The Hood

    6. INSTALL THE HOOD Run power cable to installation location. Place the hood at its location. Using a pen, mark the position of the screws (smaller part of the embossed keyholes). Remove the hood and install four 1/2” double thread screws at sides locations (A), leaving a 1/8”...

  • Page 9: Fluorescent Lamps

    9. FLUORESCENT LAMPS WARNING This hood has fluorescent lamps containing mercury. Dispose of appropriately, according to local laws and requirements. This range hood must use compact fluorescent lamps (120 V, 13 W, PLC13, 2700 K with G24q-1 base) (included). NOTE: The range hood is shipped with both fluorescent lamps packed behind the light diffuser. ...

  • Page 10: Cleaning

    10. CLEANING (CONT'D) TAINLESS STEEL CLEANING Don’t: • Regularly wash with clean cloth or rag soaked • Use any steel or stainless steel wool or any with warm water and mild soap or liquid dish other scrapers to remove stubborn dirt. detergent.

  • Page 11: Service Parts

    The manufacturer recommends to contact a certified service depot for all replacement parts and repairs. MODEL ESB10  ESCRIPTION...

  • Page 12: Hl0093

    12. SERVICE PARTS (CONT'D) EPLACEMENT ARTS AND EPAIRS In order to ensure your unit remains in good working condition, you must use the manufacturer genuine replacement parts only. The manufacturer genuine replacement parts are specially designed for each unit and are manufactured to comply with all the applicable certification standards and maintain a high standard of safety.
