INSTRUCTION MANUAL
Super High Resolution
Day & Night Color Camera
(Optional WDR)
KCV-8710NV/R30
www.kodobr.com.br

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KCV-8710NV and is the answer not in the manual?

Questions and answers

Summary of Contents for Kodo Pro KCV-8710NV

  • Page 1 INSTRUCTION MANUAL Super High Resolution Day & Night Color Camera (Optional WDR) KCV-8710NV/R30 www.kodobr.com.br...
  • Page 2 LIMITATION OF LIABILITY THE INFORMATION IN THIS PUBLICATION IS BELIEVED TO BE ACCURATE IN ALL RESPECTS, HOWEVER, WE CANNOT ASSUME RESPONSIBILITY FOR ANY CONSEQUENCES RESULTING FROM THE USE THEREOF. THE INFORMATION CONTAINED HEREIN IS SUBJECT TO CHANGE WITHOUT NOTICE. REVISIONS OR NEW EDITIONS TO THIS PUBLICATION MAY BE ISSUED TO INCORPORATE SUCH CHANGES...
  • Page 3: Explanation Of Graphical Symbols

    WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECTS THROUGH THE VENTILATION GRILLS OR OTHER OPENINGS ON THE EQUIPMEMT. CAUTION EXPLANATION OF GRAPHICAL SYMBOLS The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”...
  • Page 4: Ce Compliance Statement

    FCC COMPIANCE STATEMENT FCC INFORMATION : This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 5: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the m anufacturer’s instructions.
  • Page 6 PRECAUTIONS Before installation, carefully read the manual to ensure correct operation and setup, heeding all warnings and instructions. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions. Ensure manual is kept in good condition for future use. Do not install the device near any heat sources such as radiators, heat registers, stoves, or other equipment (including amplifiers) that produce heat.
  • Page 7: Table Of Contents

    TABLE OF CONTENTS CONTENTS OF PACKAGE ------------------------------------------------------------------------- 7 INTRODUCTION --------------------------------------------------------------------------------------- 8 CAMERA CONNECTIONS -------------------------------------------------------------------------- 9 INSTALLATION ----------------------------------------------------------------------------------------- 10 LENS ADJUSTMENT --------------------------------------------------------------------------------- 12 CAMERA OVERVIEW -------------------------------------------------------------------------------- 13 CAMERA ADJUSTMENT ---------------------------------------------------------------------------- 14 EXTERNAL DIMENSION----------------------------------------------------------------------------- 23 SPECIFICATIONS ------------------------------------------------------------------------------------- 25 CONTENTS OF PACKAGE Installation of the camera must be performed by qualified service personnel in accordance with all local and national electrical and mechanical codes.
  • Page 8: Introduction

    INTRODUCTION The camera provided high-quality image using SONY 1/3” CCD and digital signal processing LSIs. Features:  1/3" Super-HAD CCD  Super high-resolution (700TVL)  Wide Dynamic Range (~x512) (Optional)  Day & Night(Auto, Manual, External, Filter delay, Change level adjust) ...
  • Page 9: Camera Connections

    CAMERA CONNECTIONS Connection Cable Description COLOR Description AC24V/DC12V WHITE AC24V/DC12V BLUE RS485(-) GREEN RS485(+) YELLOW ALARM OUT GRAY DN EXT-IN BLACK&WHITE DN EXT-OUT BLACK SKY BLUE UTP+(Option) PINK UTP- (Option) 1) External Day/Night Control Select Day/Night mode using external equipment, by connecting control lines to the appropriate terminals.
  • Page 10: Installation

    INSTALLATION – VP DOME 1. Loosen the four torx screws located midway up the front of the housing leaving the screws intact in the front portion. (Fig. 1) 2. Drill the mounting location, using the Drilling guide. (Fig. 3) 3. Attach the housing to the ceiling using suitable fasteners, M6x35 tapping screws are supplied.
  • Page 11 INSTALLATION – INDOOR DOME 1. Using the drilling guide, drill the mounting holes and cable hole in place on the ceiling or wall. 2. To remove dome cover, turn the dome body counterclockwise until locators reach end of travel and pull off. Push the liner on the sides where the patterns are put in the teeth of a comb and pull it out.
  • Page 12: Lens Adjustment

    LENS ADJUSTMENT Field of view: Adjust setting from Telephoto (T) to wide (W) field of View. Focus: Adjust lens focus from near (N) to infinity. DC AUTO IRIS LENS 2.6-6mm 4-9mm 2.8~12mm 6-50mm Image Size 1/3” CCD 1/3" CCD 1/3" CCD 1/3"...
  • Page 13: Camera Overview

    CAMERA OVERVIEW Right Down Left Enter Test Video Output External AD Key Input BNC/UTP Switch External AD Key Control (optional) White / AD output AD Key Terminal GND Terminal Black / GND <Remarks> 1) Menu: Represent present menu subject on top of screen. In case of used Multi-Camset, Represent CAM ID and “camset”...
  • Page 14: Camera Adjustment

    Editing Area(No Save), Default(Read Only). Save Area(Use on Start), Backup * Don’t Power off while doing Save, Load, Backup, Overwrite CAMERA ADJUSTMENT <White Balance> 1) ATW/Wide Mode: No limits in the range of color temperature. 2) ATW/Indoor Mode: Suitable for low color temperature. - CRS(Color Rolling Suppression) Mode supported.
  • Page 15 * Motion is occured: Fast screen update mode. 3) Low Light: If using UDF function, this function being disabled. - AGC: Boost the signal and adjusting the brightness. (Off/Low/Mid/High) - Sens-Up: By summing multiple fields, adjusting the proper brightness in low light conditions (2X~ 256X) - Apert : In low light conditions, reduce noise by lowing the sharpness value.
  • Page 16 Global Functions: This functions being performed in the entire area. - Output Select: It must be specify the outputs, each function will be enabled. Press [Enter Key], to select output of each detection zone. Alarm: Trigger alarm to output port. Communication: Event string sends on RS-485 Screen: Display on screen.
  • Page 17 * For more than 180 of interior angle is not permitted. Line: Select Start/End Point. It you select one of start/end, the active point is displayed. Move the point with 4-arrow keys. Press [ENTER] key is to finish edit point. Posi: Adjust area position with 4-arrow keys.
  • Page 18 recording start. *) In Simple mode is not supported. Detect object moving. From top to enter of In & Out Rect area, detecting direction of moving out. Direction *) Please don’t use as a signal for video recording start. *) In Simple mode is not supported. Detect object moving.
  • Page 19: System Setup

    Rst Time (sec): Time for release to windy object that staying with no motion 3) Display Setup: Configuration for information on screen. NOTE: * Priority: Abandon/Absent > Loiter > Moving Object > Windy * Same priority: large object size order Alarm: Represent alarm icon on right-up side by of screen.
  • Page 20 - Cam Info: Display camera basic information. NOTE: * Cam ID/Baud rate/Protocol/Lens Type/CCD Type/Video System/Firmware Version - System Lock: System locking by 4-characters PID (Lock/Unlock) - Change PID: Change PID used in the system lock. NOTE: * Enter PID: Input previous password. Default PID is “0000”. * Enter New PID: Input new password.
  • Page 21 Automated white pixel compensation for not compensated pixel by static method, No limits of compensation pixel number. Select level (Low/Mid/High). Higher value setting is compensating more pixels. NOTE: * If the scene contains high frequency components can cause a loss. Static/Manual: Manual white pixel compensation by appointment method.
  • Page 22 Active only used AC Power. - Int(Internal)/Ext(External) If mode is set to Ext, Sync Phase can be adjusted. 5) Day/Night - Detection: Configuration D/N change method. (Internal/Fix-Day/Fix-Night/EXT-IN) Internal: Operating DN changing with internal detection algorithm. Fix-Day: Day mode fixed. Fix-Night: Night mode fixed. External: Work with EXT-IN mode.
  • Page 23 EXTERNAL DIMENSION – VP DOME 0.1 in. (2.5mm thick), Window Size impact-resistant P.C (LEXAN) 3.93 in. (10cm) diameter Cable Entry One 1" (25mm) opening holes Weight – Unit: 1.66 lb. (760 g) Shipping: 2.11 lb. (960 g)
  • Page 24 EXTERNAL DIMENSION – INDOOR DOME Dimensions 11 3 1 4 5 .6 0.1 in. (2.5mm thick), U n i t: mm Window Size impact-resistant P.C (LEXAN) 3.93 in. (10cm) diameter Cable Entry One 1" (25mm) opening holes Weight – Unit: 0.99 lb.
  • Page 25: External Dimension

    SPECIFICATIONS (WDR) ITEM NTSC ELECTRICAL Input Voltage DUAL(DC12V, AC24V) ±10% Power Consumption IR Off: 3.5 Watts(300mA) / IR On:6.0 Watts(500mA) Power Connector 2-Pin Terminal Block VIDEO Image Device 1/3" Sony Super-HAD II PS 960H CCD Total Pixels 1020(H) x 508(V) 1020(H) x 596(V) Effective Pixels 976(H) x 494(V)
  • Page 26: Specifications

    SPECIFICATIONS (WDR-Lite) ITEM NTSC ELECTRICAL Input Voltage DUAL(DC12V, AC24V) ±10% Power Consumption IR Off: 3.5 Watts(300mA) / IR On:6.0 Watts(500mA) Power Connector 2-Pin Terminal Block VIDEO Image Device 1/3" Sony EXview 960H CCD II Total Pixels 1020(H) x 508(V) 1020(H) x 596(V) Effective Pixels 976(H) x 494(V) 976(H) x 582(V)
  • Page 27 MEMO...
  • Page 28 MEMO...
  • Page 29 MEMO...
  • Page 30 50303195A...
