Connecting Optional Devices

Refer to the following for information on connecting the motherboard's optional
devices:
SATA1~6: Serial ATA connectors
These connectors are used to support the new Serial ATAIII devices for the highest
data transfer rates (6.0 Gb/s), simpler disk drive cabling and easier PC assembly. It
doubles the transfer rate of current SATA 3.0Gb/s interface.
Pin
Signal Name
1
Ground
3
TX-
5
RX-
7
Ground
Pin
2
4
6
-
Installing the Motherboard
Signal Name
TX+
Ground
RX+
-
15
