LCD DISPLAY FEATURES

1. PLAY - Active while the unit is actually playing a CD.
2. PAUSE - Active when the unit is paused.
3. CUE - Flashing when the unit is setting a cue point. Lit continuously
when the unit is paused at a cue point.
4. PROGRAM - Used for preprogramming the track order to be played
automatically by the unit. This is a great function if you need to leave
the CD player alone.
5. TIME MODE -
(Elapsed) is for showing time as it is taking place.
(Remain) shows how much time is left on a particular track. This
function is controlled by the TIME BUTTON (4).
6. SINGLE - Shows when the unit is set to play just one track at a time.
When this is not lit the CD will play continuously through all tracks. This
function is controlled by the SING/CONT BUTTON (2).
7. PITCH - Is lit when the PITCH BUTTON is active.
8. TIME BAR - Shows either time remaining or elapsed depending on the
setting of the TIME BUTTON (4).
9. PITCH - Shows the percentage change in pitch.
10. TRACK - Shows the track that the unit is playing with.
11. MINUTES - Shows the minutes elapsed or remaining depending on
mode setting.
©2001 Numark Industries
12. SECONDS - Shows the seconds elapsed or remaining depending on
mode setting.
13. FRAMES - The CD Player breaks down a second into 75 frames for
accurate cueing. This shows the frames elapsed or remaining
depending on mode setting.
14. LOOP - shows when the CD is repeating a particular area with the
music on the CD.
15. RELOOP - shows when the CD has had a loop set previously and can
go back to it to loop again.
TRANSPORT FEATURES
19. DISC TRAY- Place your CD in here.
20. OPEN/CLOSE (Disc Tray Open/Close) - Press to load or eject the
disc. Each press will open or close the disc tray on the transport.
NOTE: Tray will not open unless the disc has been paused.
21. POWER BUTTON - Turn on and turn off the machine from this button.
The unit should always be shut down with this button first before any
external power is removed.
22. RCA AUDIO JACKS - Connect your CD player to your mixer from this
line level output.
23. VOLTAGE SELECTOR - Set this switch to the voltage for your
location.
24. POWER CORD - Plug your unit into a power outlet after checking
voltage setting.
25. CONTROL CONNECTOR - Plug your control cables for each unit into
here and the back of the remote unit.
26.
DIGITAL OUTPUTS - The format is type 2, form 1, also known as
S/PDIF (Sony/Phillips Digital Interface Format). In order to use the
digital output you must set the digital output selector to on. This will
deactivate the variable pitch slider and the pitch bend buttons or pitch
wheel. If you were able to adjust the pitch, other devices will not read
the digital output properly.
