- Page 1 Operation / Installation Manual 操作 / 安装说明 Petunjuk Pemakaian / Pemasangan Hoạt động / Hướng dẫn lắp đặt Electric Oven 电烤箱 Pemanggang Listrik LÒ NƯỚNG ĐIỆN RBO-106SIX Rinnai Corporation...
-
Page 2: Table Of Contents
Troubleshoot --- -----------------------------------------------------------------------------------------------------------------------------------------12 Installation ------------------------------------------------------------------------------------------------------------------------------------------------13 IMPORTANT To register your product warranty, please paste the serial numbers stickers enclosed with the packaging on your warranty card. Please contact your local Rinnai Customer Care Centre should you require further assistance. Version: 2012 04... -
Page 3: Safety Warnings
SAFETY WARNINGS Please read this user manual thoroughly before attempting to use this appliance for the first time. This manual contains important information on safe installation, use and care of the appliance. Keep these instructions for reference and pass them on to any future user. ... -
Page 4: Appliance Specifications
APPLIANCE SPECIFICATIONS Voltage and frequency of power supply 220V – 240V / 50Hz Appliance dimension W594 X D566 X H594 mm Cavity dimension W453 X D440 X H333 mm Oven capacity 56 litres Net weight 32.5 kg CONTROL PANEL... -
Page 5: Using For The First Time
USING FOR THE FIRST TIME Setting and changing the time New appliances have a slight smell on first use. The first time you use your appliance, it is advisable to set the The oven only operates when the time has been set. thermostat to the highest setting and leave the empty Each time the appliance is connected to the power oven on for at least half an hour. -
Page 6: Oven Operation
OVEN OPERATION The flashing bars indicate that Speedcook mode Notes on oven operation is operating. When the oven heats up to the set Turn on the appliance by pressing ON/OFF key temperature, the bars of the heat indicator light ... - Page 7 Notes on clock mode To display the current time, press CLOCK key When a clock mode has been selected, the corresponding symbol flashes for approximately 5 The selected cooking time starts to count down. seconds. During this time, you can set the time When the time has elapsed, the oven will automatically go off.
- Page 8 Setting the delayed oven start Child lock The child lock can be activated to prevent the oven being This mode enables you to set the COOK TIME switched off intentionally by children. END TIME countdown simultaneously. The maximum To activate the child lock, press and hold child lock setting is 120 minutes from the present time displayed.
-
Page 9: Oven Function
OVEN FUNCTION Rinnai ovens are equipped with easy controls and the oven may operate in the following modes. GRILL AND FAN mode The top central heating element is activated. Heat is diffused by radiation from the heating element. The forced circulation of air caused by the fan at the back of... - Page 10 FAST-COOK mode Cooling ventilation The combination of all the heating elements together This appliance is equipped with a cooling fan, which with the fan creates a constant heat distributed turns on automatically when the oven is hot. uniformly throughout the oven. This cooking method is The fan will switch off automatically when the oven is ideal for fast cooking (not requiring any pre-heating) and sufficiently cooled down.
- Page 11 Cooking table Mode Dish Weight Cooking rack position Preheating time Temperature Cooking time (kg) from bottom (minutes) (minutes) Conventional Duck 65-75 heating Roast veal or beef 70-75 Roast Pork 70-80 Biscuits (short pastry) 15-20 Tarts 30-35 Multi-cooking Pizza (on 2 racks) 15-20 Lasagna 30-35...
-
Page 12: Maintenance And Care
We recommend you your local Rinnai to replace the layer after a few years of regular use. Customer Care Centre. For purchase of spare part, please check with your local Rinnai Customer Care Centre. -
Page 13: Troubleshoot
Oven light does not work If the problem persists despite observing the above Replace or tighten oven lamp. See ‘Replacing the checks, please contact your local Rinnai Customer Care oven lamp’ section in this manual. Centre for assistance. Oven smokes excessively during cooking For service calls under warranty, please note that it is ... -
Page 14: Installation
INSTALLATION Installation must be performed by qualified personnel only. The manufacturer declines all responsibility for improper installation and does not accept responsibility for appliance warranty in the event of damage caused by incorrect installation. Fit the appliance in appropriate cabinet Ventilation ... - Page 16 Rinnai Customer Care Centres Indonesia China Customer Care of PT. Rinnai Indonesia Guangzhou Rinnai Gas & Electric Jl. Raya Pejuangan No.21, Komp. Ruko Sastra Graha No.11-13 Room 2805, No.31 Jianghe Building, Tianshou Road, Jakarta 11530 Guangzhou, China Tel : (62) 0800 1 889 889 (toll free) /...
