Rinnai RBO-10MSY Easy Manual

Oven Easy Manual
Model : RBO-10MSY
Left: Minus & Adds
Temperature
Control Panel
Middle Button:
1. Child Lock On / Off (it will automatic Off after 8 Sec.)
2. Alarm
3. Cook Time (Duration)
4. Stop Cook
5. Minus Adjustment
6. Adds Adjustment
First Step once on the OVEN (Clock Setting)
 Press
&
3
*Adjust use by adds n minus button.
*If you didn't set the clock time, the digital panel will run the time from 00:00
First Step Once Baking Cookies or Cake or Bread or ... please be aware
 Pre-Heat the Oven at least 30 minutes or until the temperature indicator light off.
This is very important for success baking.
 Pre-heat is not available for "Full Automatic Function"
 Once you finish setting the time, leave you hand away 3~5 second, then the
OVEN is receive the setting, it show at the left corner on the screen.
 If any the setting you set was wrong or would like to change, just press the
RESET button, it function like erase all the setting you set before.
 If you would like check the count down time for alarm, please press on the Alarm
Button once and the digital will show n the time.
1 2 3
together is Reset for setting the Clock Time in 24Hour format.
4
4 5 6
Right: Scroll Left & Right
Cooking Function
Control Panel
