Summary of Contents for Bosch ISP-PPR1-WA16x

  • Page 1 LSN Peripherals LSN Motion PIR/Microwave LSN Seismic LSN Glassbreak LSN Smoke LSN Magnetic Contacts LSN Holdup LSN Expansion Modules LSN Display Panels LSN Power Supplies www.boschsecurity.com Bosch Security Systems B.V.
  • Page 2 Detectors with Anti‑mask System Overview LSN Technology This detector is a two-wire unit for use with the Bosch Local Security Network system (LSN and LSN Improved). It communicates alarm, trouble or tamper conditions through serial communication on the LSN bus.
  • Page 3 If the system is configured for local LED control, the alarm LED activates for four seconds following a successful test or flashes after a failed test. www.boschsecurity.com Bosch Security Systems B.V.
  • Page 4 -10°C to +55°C (+14°F to +130°F) For UL Certificated installations, 0°C to +49°C (+32°F to +120°F) Environmental Class II: EN 50130-5 Protection Rating: IK04 (EN 50102) Selectable Short-range Coverage 8 m x 10 m (25 ft x 33 ft) Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 5 Wires are hidden inside. Swiveling B335-3 low-profile mount B335-3 Swiveling, low-profile, plastic mount for wall mounting. The vertical swivel range is +10° to -20°, while the horizontal swivel range is ±25°. Available in triple packs. www.boschsecurity.com Bosch Security Systems B.V.
  • Page 6 System Overview LSN Technology This detector is a two-wire unit for use with the Bosch Local Security Network system (LSN and LSN Improved). It communicates alarm, trouble or tamper conditions through serial communication on the LSN bus.
  • Page 7 Draft, Insect, and Small Animal Immunity The sealed optic chamber provides immunity to drafts and insects, reducing false alarms. Small animal immunity reduces false alarms caused by animals less than 4.5 kg (10 lb), such as rodents. www.boschsecurity.com Bosch Security Systems B.V.
  • Page 8 Selectable Short-range Coverage 8 m x 10 m (25 ft x 33 ft) Protection Rating: IK04 (EN 50102) Mounting Considerations The recommended mounting height is 2 m to 3 m (7 ft to 10 ft). Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 9 Wires are hidden inside. Swiveling B335-3 low-profile mount B335-3 Swiveling, low-profile, plastic mount for wall mounting. The vertical swivel range is +10° to -20°, while the horizontal swivel range is ±25°. Available in triple packs. www.boschsecurity.com Bosch Security Systems B.V.
  • Page 10 Vertical swivel range of the mirror: +2° to -16° - Protection against false alarm - Higher tolerance to environmental conditions - Not suitable for the long-range version High sensitivity: - Protection against intruders - With normal environmental conditions Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 11 3 units • Monitoring area 3 m x 21 m • Vertical swivel range of the mirror: +7° to -16° Top view Side view Parts Included Type Qty. Component DS 935 LSN Infrared motion detector www.boschsecurity.com Bosch Security Systems B.V.
  • Page 12 Factory default setting: The PIR technology ensures Parts-1 and -3 V1.2.1: 2000-08 detection in the event of microwave technology failure. Germany DS840LSN-F5 Configuration Configure the detector using the software in the Approvals DS840LSN DS840LSN-C DS840LSN-F5 corresponding LSN control panel. Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 13 Requires 4 mAh per hour in standby mode. Trademarks ® TriTech is a registered trademark of Bosch Security Systems in the USA. Ordering Information DS840LSN Detector (10.525 GHz) DS840LSN Operates at 10.525 GHz. Monitoring area of...
  • Page 14 After initial set-up of the detector in an LSN cluster, wait at alarm suppression. However, high temperature fluctuations least one minute until the detector is operationally ready. on the reference surfaces should be avoided. Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 15 11 m. This means the zone configuration can be adjusted to match the spatial conditions. Side view Non-monitored surface Installation height Side view Top view The distance from the side to the wall depends on the range www.boschsecurity.com Bosch Security Systems B.V.
  • Page 16 -20 °C to +60 °C • Humidity (EN60721) <95% relative humidity, no dew point Dimensions (H x W x D) 135.5 x 55 x 45 mm Housing protection category IP41/IK02 (EN60529, EN50102) VdS environmental class Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 17 The sensitivity of the antimask message can be adjusted with the configuration software. You can use the functions to switch between the REAL-time antimask message and the latch antimask message. REAL-time (non-saving): A cover is displayed as long as the detector is masked. www.boschsecurity.com Bosch Security Systems B.V.
  • Page 18 EMC strength up to 2 GHz 30 V/m • VdS environmental class Housing • Dimensions (H x W x D) 135.5 x 55 x 45 mm • Housing protection category IP41/IK02 • Weight 0.150 kg Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 19 Ordering Information IR 270 T LSNi Infrared Motion Detector, IR270 T LSNi Antimask For monitoring rooms for unauthorized entry, 18 m wide-angle version with antimasking and look-down zone, 25 m long-range version with long-range mirror (optional) www.boschsecurity.com Bosch Security Systems B.V.
  • Page 20 2.2 m. suppressed. This is realized by linking the passive infrared For optimal performance, position the detector in a location and ultrasound systems. where the intruder's anticipated path is at 45° to the detector axis. Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 21 US range standard Distance between detectors Several detectors may be deployed in the same room. If more than four detectors are installed opposite each other in the same room, the distance must be > 8 m. www.boschsecurity.com Bosch Security Systems B.V.
  • Page 22 Detection zone The GM 570 LSN seismic detector can be operated in a room with ultrasound detectors; the detection zone is not affected by this. Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 23 Dropping cash boxes into night safes results in brief, acute Interim values can also be selected. Multiple detectors do seismic signals. There are several ways of reducing these. not mutually influence each other. • Joint between inlet channel and night safe www.boschsecurity.com Bosch Security Systems B.V.
  • Page 24 Dimensions (H x W x D) • GMXB0 floor socket 150 x 150 x 50 mm • Floor socket with flange 220 x 150 x 50 mm Maximum load 1000 kg Protection category IP 50 Bosch Security Systems B.V. www.boschsecurity.com...

  • Page 25: Glass Break Detector

    Installation distance from frames: 20 mm Germany G 101502, B GBS 2036 LSN The detector cannot be used for the following types of plates: • Pyrostop glass (fire-retardant) • Structured glass • Plates made of plastic material • Glass bricks www.boschsecurity.com Bosch Security Systems B.V.
  • Page 26 37 x 19 x 12 mm • Connection cable Ø 3.2 mm, length 4 m Ordering Information GBS 2036 LSN Passive Glass Break 4998014173 Detector For monitoring level glass surfaces within a max. radius of 2 m Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 27 OT or O detector. The detector should then be mode exchanged immediately in order to be able to keep using the higher reliability of detection of the OTC or OC detector. Combined Optical Thermo-max. Thermal differ- ential Chemical www.boschsecurity.com Bosch Security Systems B.V.
  • Page 28 Maximum cable length 1000 m, for J‑Y(St) Y n x 2 x 0.6/0.8 It is possible to activate a remote external detector alarm • Can be connected to the following LSN fire panels: display. BZ 500 LSN Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 29 MPA External Detector Alarm Display OTC 410 / OC 410 Approx. 80 g / approx. 125 g according to DIN 14623 • OT 400 / O 400 / T 400 Approx. 75 g / approx. 115 g www.boschsecurity.com Bosch Security Systems B.V.
  • Page 30 SSK 400 (packing unit = 10 units) TP4 400 Support Plate for Detector TP4 400 Identification (packing unit = 50 units) TP8 400 Support Plate for Detector TP8 400 Identification (packing unit = 50 units) Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 31 MSS 300 ws - EC MSS 400 LSN MSS 401 LSN Germany G 204067 MSS 300 G 204068 MSS 400 / 401 Russia GOST POCC DE.C313B06298 Installation/Configuration Notes • MAGIC.SENS Detector Base Sounders are intended only for interior areas. www.boschsecurity.com Bosch Security Systems B.V.
  • Page 32 ISO 8201 For direct connection to the LSN with direct separate power supply 11 USA temporal 3 tone 2850 Hz 94 dB(A) ISO 8201 * Delivery state: tone complying with DIN 33404 or EN 457 Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 33 IP 30 IP 30 Permissible operating tem- -10 °C . . . +55 °C -10 °C . . . +55 °C -10 °C . . . +55 °C -10 °C . . . +55 °C perature www.boschsecurity.com Bosch Security Systems B.V.
  • Page 34 In case of fire, the light is scattered by the smoke particles requirements. In addition, the detectors are suitable for and strikes the photo diodes (2), which transform the areas with heightened dust exposure. quantity of light into a proportional electrical signal. Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 35 Contamination of the detector surface leads to active adaptation of the threshold (drift compensation) and to a fault indication in the case of heavy contamination. www.boschsecurity.com Bosch Security Systems B.V.
  • Page 36 Weight Without / with packaging light (e g. in rooms with IR systems for interpreters). • The detectors must be mounted so that they are not exposed to any direct sunlight. Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 37 Minimum installation height Out of arm's reach FAA‑500‑CB Built-in Housing for Concrete FAA-500-CB Minimum installation height recommend- Ceilings ed by BOSCH: 2.70 m FAA‑500‑SB Surface Mount Back Box FAA-500-SB Minimum distance to lamps 0.5 m FAA‑500‑SB-H Surface Mount Back Box...
  • Page 38 120 m² max. 120 m² max. 120 m² max. 120 m² Monitoring area Maximum installation 16 m 16 m 16 m 16 m height white transparent with color white transparent with color Color inserts inserts Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 39 Depending on the specified detector class, the temperature sensor triggers the alarm status when the maximum temperature of 54 °C or 69 °C is exceeded (thermal maximum), or if the temperature rises by a defined amount within a specified time (thermal differential). www.boschsecurity.com Bosch Security Systems B.V.
  • Page 40 14.10.01/TSE-6990 Detectors • Fault indication in the event of the failure of the detector electronics • Continuous display of contamination level during service • Fault indication if heavy contamination is detected (in place of false alarms) Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 41 FAH-T 420 (KKW) -20 °C . . . +50 °C Permissible relative humidity 95% (non-condensing) Permissible air speed 20 m/s. Protection class as per EN 60529 IP 40, IP 43 detector base with damp room seal www.boschsecurity.com Bosch Security Systems B.V.
  • Page 42 MSF 400 Detector Base with Damp Room MSF 400 Seal for surface-mounted and flush-mounted cable feed MSC 420 Additional Base with Damp Room MSC 420 Seal for surface-mounted cable feed Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 43 If the door or window is opened less than 1 cm, the magnetic contact should not be able to detect this. An opening of more than 3 cm must be detected. www.boschsecurity.com Bosch Security Systems B.V.
  • Page 44 6 x 30 mm (Ø x L) • Plastic sleeve 8 x 31 mm (Ø x L) • Connection cable Ø 3.2 mm, length 4 m Wire colors aLSN1: white bLSN1: brown aLSN2: white bLSN2: yellow Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 45 An opening of more than 3 cm must be detected. Detector High-Ohm multimeter Contact open: approx. 3 MOhm Contact closed: approx. 1 megaohm Note Only the intrusion contact can be checked in this way. The tamper switch of the Class C www.boschsecurity.com Bosch Security Systems B.V.
  • Page 46 8 x 31 mm (Ø x L) • Surface mounting housing 54 x 13 x 12.5 mm • Connection cable Ø 3.2 mm, length 4 m Wire colors aLSN1: white bLSN1: brown aLSN2: white bLSN2: yellow Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 47 If the door or window is opened less than 1 cm, the magnetic contact should not be able to detect this. An opening of more than 3 cm must be detected. www.boschsecurity.com Bosch Security Systems B.V.
  • Page 48 6 x 30 mm (Ø x L) • Plastic sleeve 8 x 31 mm (Ø x L) • Connection cable Ø 3.2 mm, length 4 m Wire colors aLSN1: green bLSN1: brown aLSN2: green bLSN2: yellow Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 49 If the door or window is opened less than 1 cm, the magnetic contact should not be able to detect this. An opening of more than 3 cm must be detected. • For installation on ferromagnetic materials, the distance plates must be used. www.boschsecurity.com Bosch Security Systems B.V.
  • Page 50 8 x 20 mm (Ø x L) • Connection cable Ø 3.2 mm, length 4 m • Surface mounting housing 54 x 13 x 12.5 mm Wire colors aLSN1: orange bLSN1: brown aLSN2: orange bLSN2: yellow Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 51 Each LSN contact is a physical LSN element (1 out of 127 possible per loop). Temperature range -25 °C to 70 °C Connection cable: 4 m, LiY(St) Y 4 x 0.14 mm with screen, exterior Ø 3.2 mm www.boschsecurity.com Bosch Security Systems B.V.
  • Page 52 352 | LSN Peripherals | LSN Magnetic Contacts Protection category IP68 Wire colors aLSN: 2 x white b1LSN: brown b2LSN: yellow Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 53 LSN testing device (software version 3.x onward). Parts Included Type Qty. Component MSA-LSN B Surface-mount magnetic contact incl. 4 m cable and 2 x AG4 surface mounting housing with accessories www.boschsecurity.com Bosch Security Systems B.V.
  • Page 54 Temperature range -25 °C to 70 °C Connection cable: 4 m, LiY(St) Y 4 x 0.14 mm with screen, exterior Ø 3.2 mm Protection category IP68 Wire colors aLSN: 2 x white b1LSN: brown b2LSN: yellow Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 55 Connecting LSN contacts • Connection cable: 4 m, LiY(St) Y 4 x 0.14 mm Each LSN contact is a physical LSN element (1 out of with screen, exterior Ø 3.2 mm 127 possible per loop). www.boschsecurity.com Bosch Security Systems B.V.
  • Page 56 356 | LSN Peripherals | LSN Magnetic Contacts Protection category IP68 Wire colors aLSN: 2 x green b1LSN: brown b2LSN: yellow Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 57 The tamper switch of the Class C AG4 surface mounting housing and enables installation magnetic contact can be checked by the LSN on ferromagnetic materials. control panel or with the LSN testing device (software version 3.x onward). www.boschsecurity.com Bosch Security Systems B.V.
  • Page 58 Temperature range -25 °C to 70 °C Connection cable: 4 m, LiY(St) Y 4 x 0.14 mm with screen, exterior Ø 3.2 mm Protection category IP68 Wire colors aLSN: 2 x green b1LSN: brown b2LSN: yellow Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 59 The magnetic switch is installed at ground level (requires a flat surface). Vehicles with rubber tires can drive over the switch without causing problems. • The magnetic switch must not be used as a door- stopper. www.boschsecurity.com Bosch Security Systems B.V.
  • Page 60 40 x 35 x 66 mm • Connection cable Ø 3.2 mm, length 4 m • Metal tubing Ø 6 x 9 mm, length 1 m Wire colors aLSN1: white bLSN1: brown aLSN2: white bLSN2: yellow Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 61 LSN testing device The magnetic switch is installed at ground level (requires a flat surface). Vehicles with rubber tires can (software version 3.x onward). drive over the switch without causing problems. www.boschsecurity.com Bosch Security Systems B.V.
  • Page 62 40 x 35 x 66 mm • Connection cable Ø 3.2 mm, length 4 m • Metal tubing Ø 6 x 9 mm, length 1 m Wire colors aLSN1: green bLSN1: brown aLSN2: green bLSN2: yellow Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 63 Each LSN contact is a physical LSN element (1 out of 127 possible per loop). • The length of LSN contact connection cables must be included when planning the total line length of the LSN loop, as LSN technology is incorporated in these detectors. www.boschsecurity.com Bosch Security Systems B.V.
  • Page 64 74 x 10 x 19 mm • Connection cable Ø 3.2 mm, length 4 m Wire colors aLSN1: green bLSN1: brown aLSN2: green bLSN2: yellow Ordering Information SKA 100 LSN Bolt Contact 4998014066 For monitoring perimeter door closure Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 65 37 x 10 x 19 mm included when planning the total line length of the LSN • With operating lever 74 x 10 x 19 mm loop, as LSN technology is incorporated in these • detectors. Connection cable None www.boschsecurity.com Bosch Security Systems B.V.
  • Page 66 Panic button incl. adhesive seal Technical Specifications Operating voltage (LSN part) +12 V to 30 V Current consumption (line voltage) Approx. 0.5 mA Ambient temperature -0 °C to +50 °C Ambient climates DIN 40040 R14 Protection category IP 40 Bosch Security Systems B.V. www.boschsecurity.com...

  • Page 67: Expander Module

    • Weight 960 g Protection category IP 32 Environmental class Certifications and Approvals Permissible -10 °C to +55 °C ambient temperature Region Certification Europe IPB-IF100 LSN Germany G 105022, C IPB-IF100 LSN www.boschsecurity.com Bosch Security Systems B.V.
  • Page 68 368 | LSN Peripherals | LSN Expansion Modules Ordering Information IPB-IF100 LSN 16 Zone Expander Module F01U512129 For monitored connection of conventional de- tectors (16 primary lines) and for controlling (8 control outputs) on the local security net- work LSN Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 69 +10 VDC to +33 VDC Europe NAK 100 LSN Current consumption 2.5 mA Germany G 195059, C NAK 100 LSN Connection Branch for loop or stub lines Line voltage +20 mV Protection category as per EN 60529 IP 30 www.boschsecurity.com Bosch Security Systems B.V.
  • Page 70 Weight Approx. 140 g Ordering Information NAK 100 LSN Branch Interface NAK 100-AP For connecting a branch stub with other LSN bus elements to a loop or stub of the local se- curity network LSN Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 71 The module housing has a tamper contact that, if triggered, sends a unique message and is evaluated as a sabotage alert. An integrated buzzer can be used to signal status changes (e.g. for tests). www.boschsecurity.com Bosch Security Systems B.V.
  • Page 72 NNK 110 LSN Emergency call coupler tial • Starting current Max. 5 A • Permanent current Max. 2 A • Switch-off current Max. 1 A • Switching voltage Max. 60 V • Switching performance Max. 30 W Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 73 NNK 110 LSN Emergency Call Coupler 4998114146 For monitored connection of conventional de- tectors (4 primary lines), to controls (3 control outputs) and a non-monitored line for closure monitoring on the local security network LSN www.boschsecurity.com Bosch Security Systems B.V.
  • Page 74 (e.g. for tests). Control panel Certifications and Approvals LSN element Primary lines 1 to 4 Region Certification Loop Europe NVK 100 LSN Stub Germany G 195058, C NVK 100 LSN Coded arming device, block-type lock Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 75 Max. 50 mA at +8 V Max. 40 mA at +12 V Max. 30 mA at +30 V • Full load: Max. 315 mA at +8 V Max. 230 mA at +12 V Max. 105 mA at +30 V www.boschsecurity.com Bosch Security Systems B.V.
  • Page 76 10 mA Ambient temperature 0 °C to +55 °C Protection type IP 40 Ordering Information NVK 100 LSN Coupler 4998117565 For connecting conventional arming equip- ment and detectors to the Local Security Net- work LSN Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 77 The unswitched input is terminated by an internal pull-up elements in the LSN loop continue to be monitored. In this resistor. case, the system automatically creates two stub lines that continue to monitor from both sides up to the location of the fault. www.boschsecurity.com Bosch Security Systems B.V.
  • Page 78 Dimensions (H x W x D) 85 x 85 x 28 mm Protection category IP 40 Environmental class Ordering Information IC 400 LSN Universal Expander 4998110382 For connecting conventional motion detectors to the local security network LSN Bosch Security Systems B.V. www.boschsecurity.com...

  • Page 79: Expander Modules

    KD 55/1 LSN 2 zone expander module, mounted flush-mounted, evaluated as a unique message. incl. mount, circuit board and cover Certifications and Approvals Region Certification Europe KD 55/1 LSN Germany G 101038, C KD 55/1 LSN www.boschsecurity.com Bosch Security Systems B.V.
  • Page 80 (2 primary lines) on the local security network LSN, surface-mounted KD 55/1 LSN 2 Zone Expander Module, 4998117576 Flush-Mounted For monitored connection of conventional de- tectors (2 primary lines) on the local security network LSN, flush-mounted Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 81 Remote Operating Panel, the BAT 100 LSN should be System Overview positioned directly adjacent to the BE 500. Item Description BAT 100 LSN, display without hood Lower part of housing ATG with 32 LEDs Keys for "LED test" or "buzzer off" Tamper contact www.boschsecurity.com Bosch Security Systems B.V.
  • Page 82 All 32 LEDs off: max. 6 mA Mechanics BAT 100 LSN housing Dimensions (H x W x D) 270 x 270 x 75 mm Material Plastic, ABS Terluran Color Light gray, RAL 9002 Weight Approx. 1 kg Bosch Security Systems B.V. www.boschsecurity.com...
  • Page 83 LSN control panel connected must be included in the calculation. • Current consumption at 12 V; 1.2 A per connection LSN element point Connection in an LSN loop or in up to 2 LSN stubs www.boschsecurity.com Bosch Security Systems B.V.
  • Page 84 With bridging time of 60 hrs < 600 mA • With bridging time of 30 hrs < 1.2 A • Current available at 28 V from 500 mA in total connector board (+V/0 V and ext. users) Bosch Security Systems B.V. www.boschsecurity.com...
