3. Front Panel Function Control Description

3.1 Short Cuts Function from the button(s)
[1]
[2]
[▼] or [▲]
Hot Keys for Function Controls
[▼]+ [▲]
[1] + [2]
[1] + [▼] + [▲]
(hold for 3 sec)
[1] + [▼]
(hold for 10 sec)
[1] + [▲]
(hold for 10 sec)
[2] + [ ]
with signal (hold for 3 sec)
Remark : All the short cuts function are only available while OSD off
3.2 Front Panel Hardware Controls
Power Switch (Front Head)
Power LED (Front Head)
Front Panel Controls (Head)
[ 1 ] [ 2 ] [ ] [▼] [▲]
Reaction Time
ViewSonic Corporation
Main Menu
Input toggle (Analog or Digital)
To immediately activate Brightness /Contrast menu.
Recall Contrast or Brightness while in the Contrast or
Brightness adjustment, or recall both of Contrast and
Brightness when the OSD is not on.
Toggle 720x400 and 640x400 mode when input 720x400
or 640x400 mode
White Balance. White Balance should set the screen on
the pure black and white pattern with 640*480@60Hz
resolution.
Power Lock (Unlock). User won't be able to turn off the
monitor.
OSD Lock (Unlock). It will lock all functions.
Factory Mode (Press [ ] exit factory mode. )
Inter Factory Mode adjust white balance and setting Burn
in Mode (On or Off) .
Power Control, soft Power Switch.
Blue – ON
Orange – Active Off
Dark = Soft Power Switch OFF
[ 1 ] Button 1
[ 2 ] Button 2
[ ] Power
[▼] Down Arrow Button
[▲] Up Arrow Button
Note: Power Button, Button 1 and Button 2
must be one-shot logic operation. (i.e. there
should be no cycling)
OSD must fully appear within 0.5s after
pushing Button 1
