ViewSonic VX1935wm-1 Servise Manual page 41

EXPLODED PARTS LIST (VX1935wm-1)
ViewSonic Model Number: VS11307
Rev: 1a
Serial No. Prefix: Q8Y
Item ViewSonic P/N
1 E-00008004
2 E-00008005
3 N/A
4 N/A
5 N/A
6 N/A
7 N/A
8 C-00008005
9 B-00008074
10 N/A
11 PL-00008001
12 N/A
13 N/A
14 N/A
15 N/A
16 N/A
17 C-00008107
18 C-00008108
19 PL-00008024
20 C-00008109
21 N/A
22 N/A
23 PL-00008002
24 N/A
25 N/A
26 N/A
27 N/A
28 E-00008073
ViewSonic Corporation
Ref. P/N
30-V9031R50G000 VA903 SPEAKER 1.5W/8R RIGHT
30-V9031R51G000 VA903 SPEAKER 1.5W/8R LEFT
40-09010003G000 VX1935wm Cable Clipper Up ABS-HB Silver
40-09010004G000 VX1935wm Cable Clipper Down ABS-HB Silver
41-03010042G000 VX1935wm Base BKT SECC
41-03010043G000 VX1935wm Hinge Sup. BKT SECC
41-07010015G000 VX1935wm Hinge SECC
42-02110008G000 Back cover of ESD rubber-2 Black φ7*1.5
70-VX193500G000 VX1935 KEY BOARD ASS'Y (Lead Free)
43-90000072G300 SCREW M4x10 PH SW+W NI ME
42-02110002G000 HU171 Rubber Foot Black
40-01010055G000 VX1935wm Bezel ABS-HB Pantone Black-C
40-02010024G000 VX1935wm Back cover ABS-HB Black
40-03010030G000 VX1935wmButton 3-KeyABS-HB Pantone Black
40-03010031G000 VX1935wmButton 2-KeyABS-HB Pantone Black
40-04020010G000 VX1935wm Power LENS PC
40-05010019G000 VX1935wm Arm_front cover ABS-HB Silver
40-05010020G000 VX1935wm Arm_Back cover ABS-HB Silver
40-06010019G000 VX1935wm Base ABS-HB Pantone Black-C
40-11010001G000 VX1935wm Base_cover ABS-HB Silver
41-03010037G000 HX191_WALL MOUNT_BRACKET
41-03010052G000 VX1935M KEY LOCK BRACKET SECC
42-04170008G000 Name plate Brand for Viewsonic AL
43-01030802G000 SCREW M3x4 PAN,NI,ME
43-01040604G000 SCREW M4*6 PAN BZ ME
43-04030802G010 SCREW M3*8 FLAT NI TAP
43-90000066G410 SCREW M3x8 PHW LW CR3/BL TAP
190SGW1-A00 LIQUID CRYSTAL DEVICE HSD190SGW1-A
Description
Confidential - Do Not Copy
38
Q'ty
1
1
1
1
1
1
1
4
1
8
7
1
1
1
1
1
1
1
1
1
2
1
1
10
2
4
4
1
VX1935wm-1
