REAR PANEL FEATURES ......................... 13 SPECIFICATIONS ............................ 14 FREE EXTENDED WARRANTY OFFER ..................... 15 The contents of this manual may be subject to change without notice. The latest version is available for download on the official Orange Amplification website: http://www.orangeamps.com/support/downloads/...
Crush PiX 20LDX IMPORTANT SAFETY INFORMATION The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of un-insulated ‘dangerous voltage’ within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. Terminals labelled as “Speaker Outputs”...
Page 6
Crush PiX 20LDX • Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. • Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades, one wider than the other.
Page 7
AC mains wall outlet. This Class I electrical equipment must be earthed. The correct mains fuse value for your region are displayed on the unit, close to the AC Mains Input. Replace only with the same type and value. If the mains fuse repeatedly blows, contact your Orange dealer.
Crush PiX 20LDX To reduce the possibility of outside electrical interference during performance, operate your amplifier and instrument away from appliances/equipment that generate high levels of electronic/electromagnetic noise. This may include, but is not limited to: fluorescent lighting, refrigerators, motors, mobile phones, radios, computers etc.
Crush PiX 20LDX Note: Changes or modifications to this equipment not expressly approved by Orange Amplification may void the user’s authority to operate this equipment. This Class B digital apparatus complies with Canadian Interference Regulations CAN ICES-3(B)/NMB- 3(B). Cet appareil numérique de classe B est conforme aux règlements CAN ICES-3(B)/NMB-3(B).
Crush PiX 20LDX FRONT PANEL FEATURES 1. Input Jack Socket Plug your instrument cable into this jack socket. 2. Gain Control This controls pre-gain level. 3. Overdrive Switch Use this switch to engage the Overdrive circuit (switch depressed) or the Clean channel (switch in the out position).
Page 11
Crush PiX 20LDX 5. High Provides high frequency equalization if required. 6. Mid Provides middle frequency equalization with cut and boost. 7. Low Provides low frequency equalization as required. 8. Volume Controls the overall volume of the amplifier. 9. Aux In Use this 1/8"...
Page 12
Crush PiX 20LDX 12. FX mode Use this control select the type of FX applied to the output signal. Each effect type and its location is indicated by the markings around the control. 13. FX Level Use this control to set the amount of digital effect applied to the output signal.
Crush PiX 20LDX REAR PANEL FEATURES 16. A/C Main Power Switch This switch turns the AC MAIN power on/off. 17. AC Inlet and Fuseholder Connect the supplied standard 3-pin “IEC” plug here.
90 days from the date of purchase. The warranty status of any Orange product is subject to its being used for its intended purpose in suitable conditions. As the manufacturer we reserve the right to refuse to warranty any Orange product which has been misused in any way whatsoever.
