LED TV

user manual

imagine the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service, please register
your product at
www.samsung.com/register
Model _____________ Serial No. _____________

Advertisement

Table of Contents

   Also See for Samsung UE32C6500

   Summary of Contents for Samsung UE32C6500

  • Page 1: User Manual

    Contact SAMSUNG WORLDWIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. Country Web Site Customer Care Centre EIRE 0818 717100 www.samsung.com/ie 0845 SAMSUNG (7267864) www.samsung.com/uk LED TV user manual imagine the possibilities Thank you for purchasing this Samsung product.
  • Page 2 The reception quality of TV may be affected due to differences in broadcasting method between the countries. Please check the TV performance in the local SAMSUNG Authorized Dealer, or the Samsung Call Centre whether it can be improved by reconfiguring TV setting or not.
  • Page 3: Table Of Contents

    Contents Getting Started Accessories Viewing the Control Panel Viewing the Remote Control Connecting to an Antenna Plug & Play (Initial Setup) Connections Connecting to an AV Device Connecting to an Audio Device 10 Changing the Input Source Basic Features 11 How to Navigate Menus 11 Using the INFO button (Now &...
  • Page 4: Getting Started

    Getting Started Accessories ✎ Please make sure the following items are included with your LED TV. If any items are missing, contact your dealer. ✎ The items’ colours and shapes may vary depending on the models. ✎ Cables not included in the package contents can be purchased separately. y Remote Control &...
  • Page 5: Viewing The Control Panel

    Viewing the Control Panel ✎ The product colour and shape may vary depending on the model. Power Indicator Speakers Remote control sensor Remote control sensor Aim the remote control towards this spot on the TV. Power Indicator Blinks and turns off when the power is on and lights up in standby mode. Toggles between all the available input sources.
  • Page 6: Viewing The Remote Control

    (p. 19). This is not available in some Anynet+ (HDMI-CEC) modes locations. (p. 32, 39). P.SIZE: Selects the picture size (p . 17). (�: Controls recording for Samsung SUBT.: Displays digital subtitles (p. 21). recorders that have the Anynet+ feature) Installing batteries (Battery size: AAA) ✎...
  • Page 7: Connecting To An Antenna

    Connecting to an Antenna When the TV is initially powered on, basic settings proceed automatically. ✎ Preset: Connecting the mains and antenna. VHF/UHF Antenna Cable ANT OUT Power Input Plug & Play (Initial Setup) When the TV is initially powered on, a sequence of on-screen prompts will assist in configuring basic settings. Press the POWERP button.
  • Page 8: Connections

    Connections Connecting to an AV Device Using an HDMI or HDMI/DVI cable: HD connection (up to 1080p) Available devices: DVD, Blu-ray player, HD cable box, HD STB (Set-Top-Box) satellite receiver, cable box, satellite receiver (STB) DVD / Blu-ray player HDMI OUT DVI OUT DVD / Blu-ray player AUDIO OUT White R-AUDIO-L ✎...
  • Page 9: Connecting To An Audio Device

    Connecting to an Audio Device Using an Optical (Digital) or Headphone Cable Connection Available devices: digital audio system, amplifier, DVD home theatre digital audio system OPTICAL ✎ DIGITAL AUDIO OUT (OPTICAL) When a Digital Audio System is connected to the DIGITAL AUDIO OUT (OPTICAL) jack, decrease the volume of both the TV and the system. 5.1 CH (channel) audio is available when the TV is connected to an external device supporting 5.1 CH.
  • Page 10: Changing The Input Source

    Connections CONNECTIONS COMMON INTERFACE Slot To watch paid channels, the “CI or CI+ CARD” must be inserted. If you don’t insert the “CI or CI+ CARD,” some channels will display the message “Scrambled Signal”. The pairing information containing a telephone number, the “CI or CI+ CARD”...
  • Page 11: Basic Features

    Basic Features TTX/MIX PRE-CH MUTE How to Navigate Menus Using the INFO button (Now & Next guide) Before using the TV, follow the steps below to learn how to The display identifies the current channel INFO navigate the menu and select and adjust different functions. and the status of certain audio-video CH LIST settings.
  • Page 12 Basic Features Using Scheduled View Channels: Shows the channel list according to ■ channel type. Guide 2:10 Tue 1 Jun My Channels: Shows the group of the channel. ■ DTV Air 800 five Scheduled: Shows all the currently reserved Family Affairs ■ 18:00 - 18:30 programmes.
  • Page 13: Channel Menu

    ¦ Using Favourite Channels Channel Menu ¦ Retuning Channels My Channels (in Channel Manager) Antenna (Air / Cable) Shows all favourite channels. ■ Edit My Channels : You can set the selected Before your television can begin memorizing the available channels to desired my channels group. channels, you must specify the type of signal source that is connected to the TV (i.e.
  • Page 14 Basic Features Manual Store ¦ Other Features Scans for a channel manually and stores in the TV. ✎ Cable Search Option If a channel is locked using the Child Lock function, the PIN input window appears. (depending on the country) ■ Digital Channel: When scanning has finished, channels Sets additional search options such as the frequency and are updated in the channel list.
  • Page 15: Picture Menu

    ¦ Adjusting Picture Settings Scheduled (in Channel Manager) Backlight / Contrast / Brightness / You can view, modify or delete a show you have reserved to watch. Sharpness / Colour / Tint (G/R) ■ Change Info: Change a show you have reserved to Your television has several setting options for picture quality watch. control. ■...
  • Page 16 Basic Features ¦ Changing the Picture Options ■ Colour Space (Auto / Native / Custom): Adjust the range of colours available to create the image. To adjust Colour, Red, Green, Blue and Reset, set Colour Space to Custom. Advanced Settings ■ White Balance: Adjust the colour temperature for a (available in Standard / Movie mode) more natural picture. You can adjust the detailed setting for the screen including R-Offset / G-Offset / B-Offset: Adjust each colour’s colour and contrast.
  • Page 17 ✎ Picture Options NOTE Depending on the input source, the picture size ✎ In PC mode, you can only make changes to the options may vary. Colour Tone, Size and Auto Protection Time. The available items may differ depending on the selected mode. Picture Options In PC mode, only 16:9 and 4:3 modes can be Colour Tone : Normal...
  • Page 18: Sound Menu

    PC may differ in which case the same basic set-up information will almost always be applied. SRS TruDialog (Off / On) (If not, contact your computer manufacturer or Samsung (standard sound mode only) Dealer.) This function allows you to increase the intensity of a voice 1. Click on “Control Panel”...
  • Page 19 Audio Format Additional Setting (digital channels only) (digital channels only) When sound is emitted from both the main speaker and the ■ DTV Audio Level (MPEG / HE-AAC): This function audio receiver, a sound echo may occur due to the decoding allows you to reduce the disparity of a voice signal speed difference between the main speaker and the audio (which is one of the signals received during a digital TV receiver.
  • Page 20: Setup Menu

    Basic Features ¦ Selecting the Sound Mode Time Zone (depending on the country): Select your time zone. ✎ When you set to Dual f-g, the current When Country is set to Others, you can use this sound mode is displayed on the screen. DUAL function.
  • Page 21 Commerce), tele-education, tele-conferencing, digital → 8 → 2 → 4 → MUTE POWER (on). libraries and network games. Network (Network Type / Network Setup / Network Test / SWL(Samsung Wireless Link) / SWL connect) For details on setting up options, refer to the “Network Connection” instructions (p. 25). English Downloaded From TV-Manual.com Manuals...
  • Page 22 While Internet@TV is in operation, the PIP function – Equalizer is not available. cannot be used. ■ BD Wise (Off / On): Provides the optimal picture quality PIP settings for Samsung DVD, Blu-ray and Home Theatre products Main picture Sub picture which support BD Wise. When BD Wise is turned On, Component, HDMI1/DVI,...
  • Page 23: Support Menu

    The time required to download the software is signal or by network connection or downloading the latest determined by the signal status. firmware from “www.samsung.com,” to a USB memory device. ■ Standby Mode Upgrade: A manual upgrade will be Current Version the software already installed in the TV.
  • Page 24: Advanced Features

    Advanced Features Connecting to a PC Using an HDMI/DVI Cable / a D-sub Cable DVI OUT AUDIO OUT AUDIO OUT PC OUT Display Modes (D-Sub and HDMI/DVI Input) Optimal resolution is 1920 X 1080 @ 60 Hz. Horizontal Frequency Vertical Frequency Pixel Clock Frequency Sync Polarity Mode Resolution (KHz) (Hz) (MHz) (H / V) 640 x 350 31.469 70.086 25.175 720 x 400 31.469...
  • Page 25: Network Connection

    Network Connection You can set up your TV so that it can access the Internet through your local area network (LAN) using a wired or wireless connection. ¦ Connecting to a Wired Network You can attach your TV to your LAN using cable in three ways: y You can attach your TV to your LAN by connecting the LAN port on the back of your TV to an external modem using a Cat 5 cable.
  • Page 26 Network Setup 1. Follow Steps 1 through 6 in the “How to set up Network Test automatically” procedure. SWL(Samsung Wireless Link) : Off 2. Set Internet Protocol Setup to Manual. SWL connect 3. Press the ▼ button on your remote to go to the first entry field.
  • Page 27: Connecting To A Wireless Network

    ¦ Connecting to a Wireless Network To connect your TV to your network wirelessly, you need a wireless router or modem and a Samsung Wireless LAN Adapter (WIS09ABGN), which you connect to your TV’s back or side panel USB jack. See the illustration below.
  • Page 28 Advanced Features Notice The picture may appear corrupted for some channels when the TV is connected to the Samsung Wireless LAN Adapter. In such case, establish a connection using one of the following methods: Method 1 Method 2 Connect using the USB right angle adapter...
  • Page 29 5. If the Security/PIN pop-up appears, go to Step 6. If the Network Setup Network Connecting Screen appears, go to Step 10. 6. Press the ▲ or ▼ button to select Security or PIN. For Select a Network : Not Selected ► most home networks, you would select Security (for Internet Protocol Setup : Auto...
  • Page 30 You can connect to a mobile device without an access point If the other methods do not work, you need to enter the through the “Samsung Wireless LAN Adapter” by using a Network setting values manually. peer to peer network.
  • Page 31 As your TV has a different MAC ✎ If a Samsung Wireless LAN Adapter is connected to the address, your ISP can not authenticate its MAC address, USB 2 port, the network may not operate normally. We and your TV can not connect.
  • Page 32: Media Play

    PC IP addresses should be the same and only the last part (the host address) should be changed. (e.g. IP Address: 123.456.789.**) 2. Using a LAN cable, connect between the external modem and the PC onto which the Samsung PC Share Manager programme will be installed.
  • Page 33 The Divx DRM, Multi-audio, embedded caption does not supported. ✎ Samsung PC Share manager should be permitted by the firewall programme on your PC. ✎ When you use Media Play mode through a network connection, According to functions of the provided server: The sorting method may vary.
  • Page 34 Advanced Features ¦ Screen Display Move to the file you desired using the up/down/right/left buttons and then press the ENTERE or � (Play) button. The file is played. ✎ Supports the View Devices and Home in Media Play homepage. Information: Videos Page /Movie 01.avi You can ascertain the selected file name and the number of files Movie 01.avi...
  • Page 35 – Below 1280 x 720: 60 frame max – Above 1280 x 720: 30 frame max • GMC 2 over is not supported. • H.263 is not supported. • Only Samsung Techwin MJPEG is supported. English Downloaded From TV-Manual.com Manuals...
  • Page 36 Advanced Features Playing movie file continuously (Resume Play) If you exit the playing Videos function, it can be played later from the point where it was stopped. ✎ If you press the ENTERE button (Chaptering) during playing the file, you can explore scene divided into 5 chapters you want.
  • Page 37 ¦ Playing the Multiple Files Playing the selected video/music/photo files 1. Press the Yellow button in the file list to select the desired file. Videos 2 files selected Page /Movie 01.avi 2. Repeat the above operation to select multiple files. ✎ Movie 01.avi Movie 02.avi NOTE Jan.10.2010 Jan.10.2010 The c mark appears to the left of the selected files.
  • Page 38 Advanced Features Videos/Music/Photos Play Option menu During playing a file, press the TOOLS button. Category Operations Videos Music Photos Title You can move the other file directly. > Repeat Mode You can play recorded, movie and music files repeatedly. > > Picture Size You can adjust the picture size for preference. >...
  • Page 39: Anynet

    Anynet+ is a function that enables you to control all connected Samsung devices that support Anynet+ with your Samsung TV’s remote. The Anynet+ system can be used only with Samsung devices that have the Anynet+ feature. To be sure your Samsung device has this feature, check if there is an Anynet+ logo on it.
  • Page 40 Anynet+ function. Make sure to switch to an Anynet+ device by using the Device List. ¦ Recording You can make a recording of a TV Programme using a Samsung recorder. 1. Select Recording. ✎ When there are more than two recording devices When multiple recording devices are connected, the recording devices are listed.
  • Page 41 ¦ Listening through a Receiver You can listen to sound through a receiver (i.e Home Theatre) instead of the TV Speaker. 1. Select Receiver and set to On. 2. Press the EXIT button to exit. ✎ If your receiver supports audio only, it may not appear in the device list. ✎...
  • Page 42: Internet@tv

    Screen Display Recommended Applications: TV Screen: Recommended Displays the recommended service by Displays the current channel. Samsung. You are not able to add or delete a service in this list. Information: My Applications by Date 1/1 Displays notices, new applications, and...
  • Page 43 Account Login ■ System Setup For a application with multiple account, use ◄ and ► to Ticker Autorun (Off / On): Enable/disable ticker autorun access the different account. upon powering on the TV. ✎ The Ticker application provides useful News, Login Weather, and Stock Market information. The Ticker application on Internet@TV must be downloaded to use this feature.
  • Page 44 Samsung Apps y Video: Displays various video media such as movies, TV shows and short length videos. Samsung Apps is a store for downloading applications to be y Sports: Displays various sports media such as match used on Samsung TV/AV equipment. information, images and short length video.
  • Page 45: Allshare

    ✎ For more information, visit “www.samsung.com” or contact the Samsung call centre. Mobile devices may Using the Message Function need additional software installation. For details, refer to Using this function, you view call arrivals, SMS messages each device's user’s guide.
  • Page 46 ✎ contents on your mobile phones. For the NOTE procedures, refer to the mobile phone manual. In Samsung mobile, ScreenShare must be installed ✎ Some special characters may be displayed as and the supporting application must be executed; blank or broken characters.
  • Page 47: Other Information

    Other Information Analogue Channel Teletext Feature The index page of the Teletext service gives you information on how to use the service. For Teletext information to be displayed correctly, channel reception must be stable. Otherwise, information may be missing or some pages may not be displayed. ✎...
  • Page 48: Assembling The Cables

    Other Information Assembling the Cables Stand Type Enclose the cables in the Cable Tie so that the cables are not visible through the transparent stand. Wall-Mount Type ✎ Do not pull the cables too hard when arranging them. This may cause damage to the product’s connection terminals. English Downloaded From TV-Manual.com Manuals...
  • Page 49: Installing The Wall Mount

    For detailed information on installing the wall mount, see the instructions provided with the wall mount. Contact a technician for assistance when installing the wall mount bracket. Samsung Electronics is not responsible for any damage to the product or injury to yourself or others if you elect to install the TV on your own.
  • Page 50 Samsung is not liable for these kinds of accidents. Samsung is not liable for product damage or personal injury when a non-VESA or non-specified wall mount is used or the consumer fails to follow the product installation instructions.
  • Page 51: Anti-theft Kensington Lock

    Anti-theft Kensington Lock The Kensington Lock is not supplied by Samsung. It is a device used to physically fix the system when using it in a public place. The appearance and locking method may differ from the illustration depending on the manufacturer.
  • Page 52: Troubleshooting

    If you have any questions about the TV, first refer to this list. If none of these troubleshooting tips apply, please visit “www. samsung.com,” then click on Support, or contact the call centre listed on the back-cover of this manual.
  • Page 53 If you are using a HDMI connection, check the audio output setting on your PC. Network Connection (Depending on Models) Wireless network connection failed. • Samsung Wireless USB dongle is required to use a wireless network. • Make sure the Network Connection is set to Wireless (p. 27). •...
  • Page 54 • Programme the Cable/Set top box remote control to operate the TV. Refer to the Cable/Set user doesn’t turn the TV on or off, or adjust the manual for the SAMSUNG TV code. volume. A “Mode Not Supported” message •...
  • Page 55 ¦ Licence TheaterSound, SRS and the symbol are trademarks of SRS Labs, Inc. TheaterSound technology is incorporated under licence form SRS Labs, Inc. Manufactured under licence from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. Manufactured under licence under U.S. Patent #’s: 5,451,942; 5,956,674; 5,974,380; 5,978,762; 6,487,535 &...
  • Page 56: Specifications

    Video: 1080 24p, 1080p, 1080i, 720p 576p, 576i, 480p, 480i Audio: 2Ch Linear PCM 32/44.1/48kHz, 16/20/24bits. Analogue audio input (HDMI IN1 only) PC input (HDMI IN1 only) Stand Swivel (Left / Right) -20˚ ~ 20˚ Model Name UE32C6500 UE37C6500 Screen Size (Diagonal) 32 inches 37 inches Sound...
  • Page 57 Model Name UE32C6510 UE37C6510 UE32C6530 UE37C6530 UE32C6540 UE37C6540 Screen Size (Diagonal) 32 inches 37 inches Sound (Output) 10 W X 2 Dimensions (WxDxH) Body 557 X 240 X 85.9 mm 630 X 270 X 88.9 mm With stand 771 X 240 X 542 mm 894 X 270X 615 mm Weight Without Stand...
  • Page 58: Index

    Other Information Index AllShare Film Mode Receiver Amplify Fine Tune Recording Antenna Flesh Tone Remote Control Anynet+ Frequency Repeat Mode Auto Adjustment RGB Only Mode Auto Volume Rotate HDMI 8, 39 Headphones Background Music Home Theatre 9, 39 Select All Balance L/R Self Diagnosis Basic View...
  • Page 59: Warning! Important Safety Instructions

    Warning! Important Safety Instructions Please read the appropriate section that corresponds to the marking on your Samsung product before attempting to install the product. This symbol indicates that high voltage is CAUTION present inside. It is dangerous to make any kind of contact with any internal part of this product. RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, This symbol alerts you that important literature DO NOT REMOVE COVER (OR BACK).
  • Page 60: Wiring The Mains Power Supply Plug (uk Only)

    3. Warranty repairs must be carried out by Authorised Samsung Dealers or Authorised Service Centres. No re-imbursement will be made for repairs carried out by non Samsung Dealers and, any such repair work and damage to the products caused by such repair work will not be covered by this warranty.
