Bottom View - Outform idisplay User Manual

7" Display Exterior Components
7
8
No. Description
1 DC in Power Supply Port
2 USB Host Port
3 SD Card Slot
4 RJ45 Ethernet jack with Power over Ethernet
5 micro SIM Card Slot
6 3.5mm audio jack
7 Power/Back button (5 sec. press for power)
8 VESA 40mm x 40mm mounting bracket screw holes
9 Volume control

Bottom View

1 2 3 4
Rear View
6
5 2 6
9
