- Page 1 F59PH Diesel Engine Freight/Passenger Set Operation Manual (3V PS2) Thank you for purchasing this RailKing product. PLEASE READ BEFORE USE AND SAVE...
-
Page 2: Table Of Contents
Table of Contents Set Up Set up Checklist ......... . 3 Assembling RealTrax®... -
Page 3: Set Up Checklist
You can obtain replacement parts and replacement instructions from the M.T.H. (Order online: www.mth-railking.com, e-mail: parts@mth- Parts Department railking.com,Fax: 410-423-0009, Phone: 410-381-2500, Mail: 7020 Columbia Gateway Drive, Columbia MD 21046-1532, ). RailKing F59PH Diesel R-T-R F reight/Passenger Set w/Proto-Sound® 2.0... -
Page 4: Assembling Realtrax
(Lock-on is the interface between the track and transformer) REMOVE TAB FROM OUTER EDGE Make sure the metal STEP STEP STEP Align Quick contacts line up. Connect Plugs Gently push together RealTrax RailKing F59PH Diesel R-T-R F reight/Passenger Set w/Proto-Sound® 2.0... -
Page 5: Connecting The Transformer
“OFF” position, Full Counter Clockwise Position. Failure either to add fluid to the smoke unit or to turn it off may damage the smoke unit heating element and/or wicking material. RailKing F59PH Diesel R-T-R F reight/Passenger Set w/Proto-Sound® 2.0... -
Page 6: Coupling The Engine And Cars
Push cars together Place the engine and cars Position on the track. Open couplers by pressing down on plunger. Position armiture for proper operation Figure 3 Coupling the Engine and Cars RailKing F59PH Diesel R-T-R F reight/Passenger Set w/Proto-Sound® 2.0... -
Page 7: Basic Operation
(see Fig. 4 ). Volume Adjustment Knob Figure 4: Volume Adjustment RailKing F59PH Diesel R-T-R F reight/Passenger Set w/Proto-Sound® 2.0... -
Page 8: Activating Proto-Sound 2.0 Conventional Mode Feature
After about 30 seconds, press the Direction button again to trigger the third FYS/PSA sequence. Again, after allowing about 30 seconds for that sequence to run, press the Direction button one more time to trigger the fourth and final FYS/PSA sequence. RailKing F59PH Diesel R-T-R F reight/Passenger Set w/Proto-Sound® 2.0... -
Page 9: Tips On Using Fys/Psa
Horn/Whistle button, allowing approximately ½ second to lapse between each quick button press. The sound of the liftbar and air line de pletion will play, and the knuckle will be released. Fire Horn/ Horn/ Horn/ Bell Rear Whistle Whistle Whistle Coupler RailKing F59PH Diesel R-T-R F reight/Passenger Set w/Proto-Sound® 2.0... -
Page 10: Proto-Coupler™ Operation
Direction Lock Two Whistle Blasts whistle (indicates change is made) Repeat to Return to Normal Condition RailKing F59PH Diesel R-T-R F reight/Passenger Set w/Proto-Sound® 2.0... -
Page 11: Reset To Factory Defaults
Cab Chatter plays at random intervals when the engine idles in neutral. Engine Start-up and Shut-down sounds play when the engine is initially powered on or is powered off for five seconds or more. RailKing F59PH Diesel R-T-R F reight/Passenger Set w/Proto-Sound® 2.0... -
Page 12: Maintenance
4. Reassemble the truck and motor, being careful not to pinch the pickup and ground wires between the truck block and motor mount. Lubricate Pick Up Roller Axles (L) Grease Idler Gears (G) Lubricate All Wheel Axles (L) Figure 5: Lubrication Points RailKing F59PH Diesel R-T-R F reight/Passenger Set w/Proto-Sound® 2.0... -
Page 13: Cleaning The Wheels, Tires And Track
ABS plastic, the block includes a built-in cleaning pad. For really stuborn track, you can insert sandpaper into the block in just a few quick steps. Track Cleaning Block (40-1099) Maintenance Kit (30-50010) RailKing F59PH Diesel R-T-R F reight/Passenger Set w/Proto-Sound® 2.0... -
Page 14: Locomotive Traction Tire Replacement
Additional tires are available directly from the M.T.H. Parts Department (Order online: www.mth-railking.com, e-mail: parts@mth-railking.com,Fax: 410-423-0009, Phone: 410-381-2500, Mail: 7020 Columbia Gateway Drive, Columbia MD 21046- 1532, ). RailKing F59PH Diesel R-T-R F reight/Passenger Set w/Proto-Sound® 2.0... -
Page 15: Locomotive Light Bulb Replacement
Replace the bulb by pushing the socket up at an angle from the bulb holder and pulling (Part #CG-0000017) the bulb from its socket. Replace with a new bulb and reverse the steps to reassemble the caboose. RailKing F59PH Diesel R-T-R F reight/Passenger Set w/Proto-Sound® 2.0... -
Page 16: Passenger Car Light Bulb Replacement
You may need to twist the car a little to make to roof come loose from the body. 3. Gently pull the bulb away from its housing and push the replacement bulb into the housing (like a Christmas tree light). 4. Reassemble in reverse order. RailKing F59PH Diesel R-T-R F reight/Passenger Set w/Proto-Sound® 2.0... -
Page 17: Self-Charging Battery Back-Up
**Do not use alkaline batteries for testing or checking purposes for the 3- Volt PS2 boards. Using alkaline batteries will damage the 3-Volt battery charging circuit.** Lift Out Battery Figure 8. RailKing F59PH Diesel R-T-R F reight/Passenger Set w/Proto-Sound® 2.0... -
Page 18: Proto Smoke Unit Operation
Choose from 12 different scents: Christmas, Coal, Diesel, Wood Burning, Coffee, Eggs & Bacon, Vanilla, Candy Cane, Barbeque, Pipe Smoke, Cinnamon Roll, and Apple Pie RailKing F59PH Diesel R-T-R F reight/Passenger Set w/Proto-Sound® 2.0... -
Page 19: Troubleshooting
Control Switch. Switch Should be in the “OFF” position for the rear coupler to fire. Cab Chatter Remedy Sometimes the Cab Chatter sounds don't Cab Chatter plays only in neutral at random play. intervals. RailKing F59PH Diesel R-T-R F reight/Passenger Set w/Proto-Sound® 2.0... - Page 20 FYS/PSA step in the FYS/PSA cycle. Wait at least 30 after fourth press of the direction button. seconds in each FYS/PSA sound clip before pressing the direction button. RailKing F59PH Diesel R-T-R F reight/Passenger Set w/Proto-Sound® 2.0...
-
Page 21: Compatibility
Lionel SW Unknown 130-Watt Standard Lionel TW 8-18v 175-Watt Standard Lionel ZW A,B,C or D 8-20v 275-Watt Standard Lionel Post-War A,B,C or D 0-20v Electronic Common 135/190 Watt Celebration Series ZW RailKing F59PH Diesel R-T-R F reight/Passenger Set w/Proto-Sound® 2.0... -
Page 22: Railware Interactive Dvd
*If you are running Windows 95, 98 or NT choose the folder 32 BIT. Run the file AR32E301.EXE and follow the directions it provides. If you have problems you cannot resolve by using these directions, contact custserv@mth- railking.com or call 410-381-2580 for further help RailKing F59PH Diesel R-T-R F reight/Passenger Set w/Proto-Sound® 2.0... -
Page 23: Additional Features With Dcs Remote Control System
Programming Digital Command Operations for up to 250 Accessories and 250 Individual Switches User Can Script, Record and Playback Train Routes Operating instructions for all DCS Command features will accompany the DCS remote control equipment. RailKing F59PH Diesel R-T-R F reight/Passenger Set w/Proto-Sound® 2.0... -
Page 24: Service And Warranty Information
Service & Warranty Information How to Get Service Under the Terms of the Limited One-Year Warranty When you suspect an item is defective, please check the operator's manual for standard operation and trouble- shooting techniques that may correct the problem. Additional information may be found on the M.T.H. Website. Should you still require service, follow the instructions below to obtain warranty service.
