  • Page 1 SAFETY AND OPERATING MANUAL Original Instructions V3.0 ROTARY HAMMER 700W TTB589SDS...
  • Page 2 Congratulations on your purchase of a power tool from Titan Power Tools (UK) Ltd. We want you to continue getting the best performance from it so this hand- book includes information on safety, handling and care. Please retain this handbook in case of you need to refer to any of the information in the future.
  • Page 3 DO NOT stretch to hold the drill. Do not drill above shoulder height or below Knee height, as the drill cannot be securely held. Never drill holes that are above the declared maximum size in the manual. ROTARY HAMMER 700W TTB589SDS...
  • Page 4: General Safety Instructions

    Do not use the tool when you are tired or under the influence of drugs, alco- hol or medication. One moment of carelessness while using a tool can result in serious personal injury. b) Use safety equipment. Always wear eye protection. Safety equipment such as dust ROTARY HAMMER 700W TTB589SDS...
  • Page 5 Service a) Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. ROTARY HAMMER 700W TTB589SDS...
  • Page 6 The silica is broken into very fine dust (also known as Respirable Crystalline Silica or RCS) during many common tasks such as cutting, drilling and grinding Breathing in very fine particles of crystalline silica can lead to the development of: Lung cancer Silicosis ROTARY HAMMER 700W TTB589SDS...
  • Page 7 The directive requires power tool manufacturers and suppliers to provide indicative vibration test results to enable users to make informed decisions as to the period of time a power tool can be used safely on a ROTARY HAMMER 700W TTB589SDS...
  • Page 8 (taking account of all parts of the operating cycle such as the times when the tool is switched off and when it is running idle in addition to the trig- ger time). ROTARY HAMMER 700W TTB589SDS...
  • Page 9 This product produces an electromagnetic field during operation! This field may under some circumstances interfere with active or passive medical implants! To reduce the risk of serious or fatal injury, we recommend persons with medical implants to consult their doctor ROTARY HAMMER 700W TTB589SDS...
  • Page 10 The motor will disengage from the output shaft. When this happens, the bit will stop turning. As soon as the torque limiter actuates, release the trigger and remove the tool and bit immediately. This will help prevent premature wear of the tool. ROTARY HAMMER 700W TTB589SDS...
  • Page 11 Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or local store for recycling advice. yyWxx Manufacturing date code: Year of manufacturing (20yy) and week of manufacturing (Wxx); ROTARY HAMMER 700W TTB589SDS...
  • Page 12 6. Function selection switch 7. Function selection switch lock button 8. Forward/Reverse lever 9. On/Off Switch 10. Switch lock button 11. Variable speed knob 12. Depth stop 13. Drill bits ( 6/ 8/ 10 x 160mm) ROTARY HAMMER 700W TTB589SDS...
  • Page 13: Technical Data

    Sound power level : =100dB(A) K=3dB(A) Wear ear protection when sound pressure is over 80dB(A) ACCESSOIRES The Rotary Hammer is supplied with the following accessories: 1 pc Auxiliary handle 1 pc Depth stop 3 pcs Drill bits 6/8/10x160mm ROTARY HAMMER 700W TTB589SDS...
  • Page 14 The bit locks itself. Check the locking by pulling on the tool. Removing Retract back the bit holder locking sleeve (3) and pull out the bit. Fig.3 ROTARY HAMMER 700W TTB589SDS...
  • Page 15 DRILL / HAMMER DRILL / CHISEL FUNCTION The operation of the gearbox for each application is set with the function mode selection switch. To change between functions, depress the unlocking button and rotate the selector to the desired operating mode. ROTARY HAMMER 700W TTB589SDS...
  • Page 16: Drilling Operation

    (drilling mode only). When drilling into soft wood, the drill should be oper- ated at high speed. When drilling into hard wood, the drill should be oper- ated at low speed. ROTARY HAMMER 700W TTB589SDS...
  • Page 17 Ensure that a masonry drill or chisel bits is being used. Maintain firm pressure on the machine so the bit does not wonder. A wondering bit may cause injury. Carbide tipped masonry bits should be used for all masonry drilling. ROTARY HAMMER 700W TTB589SDS...
  • Page 18: Troubleshooting

    If something unusual occurs during use, switch off the supply and disconnect the plug. Inspect and repair the tool before using it again. The repairs must be carried out by a qualified technician. Repair of the tool must only be carried out by a ROTARY HAMMER 700W TTB589SDS...
  • Page 19: Environmental Protection

    Directive 2002/96/EC. It will then be recycled or dismantled to minimize impacts on the environment, electrical and electronic products are potentially hazardous to the environment and human health due to the presence of hazardous substances. ROTARY HAMMER 700W TTB589SDS...
  • Page 20: Plug Replacement (Uk & Ireland Only)

    13 A mp fuse approved to BS 1362 Connect Blue to N Brown L(live) (neutral) Outer sleeve Cable grip firmly clamped ROTARY HAMMER 700W TTB589SDS...
  • Page 21 Declaration of Conformity We, Importer Titan Power Tools (UK) Ltd. Trade House, Mead Avenue, BA22 8RT Declare that the product: Designation: ROTARY HAMMER 700W Model: TTB589SDS Complies with the following Directives: 2004/108/EC Electromagnetic Compatibility Directive 2006/42/EC Machinery Directive 2006/95/EC Low Voltage Directive...
