  • Page 1: Quick Installation Guide

    Quick Installation Guide 1/3” Dome, Fixed, Day&Night, DNR, WDR, 2,8-12mm, 700TVL, Effio V, 12V VKCD-12140F2812IR...
  • Page 3 Precautions Precautions Fully understand this document before using this device, and strictly observe rules in this document when using this device. If you install this device in public places, provide the tip "You have entered the area of electronic surveillance" in an eye- catching place.
  • Page 4  Strictly conform to local electrical safety standards and use power adapters that are marked with the LPS standard when installing and using this device. Otherwise, this device may be damaged.  Use accessories delivered with this device. The voltage must meet input voltage requirements for this device.
  • Page 5 Special Announcement All complete products sold by the manufacturer are delivered along with nameplates, operation instructions, and accessories after strict inspection. The manufacturer shall not be held responsible for counterfeit products. This manual may contain misprints, technology information that is not accurate enough, or product function and operation description that is slightly inconsistent with the actual product.
  • Page 6: Table Of Contents

    Contents 1 Overview ........................1 1.1 Introduction ........................1 1.2 Functions and Features ....................1 2 Hardware Connection ..................... 3 2.1 Power and video cables ....................3 2.2 Function Keys ........................ 3 3 Device Dimensions ....................5 4 Device Installation ....................7 5 Function Menus .....................
  • Page 7: Overview

    Overview 1.1 Introduction The product is a 700 TVL wide dynamic range infrared bullet camera that uses a 1/3" Super HAD CCD II image sensor. By using the Effio-V digital processing technology, the camera can capture high-quality, high-resolution and Super-WDR images. 1.2 Functions and Features ...
  • Page 8 The camera allows you to define a maximum of 15 quadrilateral mask areas, which meets privacy requirements.  Built-in mobile optical filter (optional)  Built-in zoom lens (f=2.8–12mm)  Intelligent IR technology The intelligent IR technology enables the camera to adjust shutter, aperture, and gain depending on image brightness in black and white mode, optimizing the infrared effect and preventing center overexposure.
  • Page 9: Hardware Connection

    Hardware Connection 2.1 Power and video cables Figure 2-1 shows the power and video cables. Figure 2-1 Power and video cables Connect the BNC connector of the power or video cable to a video signal cable and connect the other connector to a low-voltage power cable (12 V DC). After installing the camera, directly connect the video cable and power cable.
  • Page 10 Figure 2-2 Function keys OSD menu control key: It is used to enter OSD menus or select menu items when you press this key in the middle of the multi-function switch. UP/DOWN keys: The UP and DOWN keys are used to select menu items upwards and downwards by prodding the multi-function switch upwards and downwards.
  • Page 11: Device Dimensions

    Device Dimensions Figure 3-1 shows the camera dimensions. Figure 3-1 Dimensions (unit: mm) Figure 4-1 shows the components of the camera. Figure 3-2 Camera components...
  • Page 13: Device Installation

    Device Installation Step 1 Open a package, take out the camera, unscrew the camera compression ring, and disassemble the camera. Step 2 Drill holes on the ceiling or wall, perform positioning of the position of the installation block with the camera mounting base as reference template, and reserve the cable entries of the video/power cables.
  • Page 14 Figure 4-2 Camera installation Step 5 Turn the main body, adjust the lens direction, and note the position of the dome cover window.  Connect the BNC connector of the power or video cable to a video signal cable and connect the other connector to a low-voltage power cable.
  • Page 15 Step 6 Adjust view angle and focal length by using an adjusting tool, as shown in Figure 5-4. Figure 4-4 View angle and focal length adjustment Step 7 Use soft cloth to wipe the lens front glass which is likely to be soiled due to installation for cleaning the camera, and complete product installation and debugging.
  • Page 16: Function Menus

    Function Menus 5.1 OSD Main Menu When you press the OSD menu control key, the OSD main menu SETUP MENU appears, as shown in Figure 5-1. The OSD main menu provides function options such as LANGUAGE, SCENE SELECT, PICT ADJUST, SYSTEM SETTING, PRIVACY MASK SETUP, MOTION DETECTION, EZOOM SETUP, and DIS.
  • Page 17: Advanced Setting Menu

    Function Option Description MASK SETUP parameters related to privacy mask. You can set a maximum of 15 privacy areas. MOTION Used to enable or disable the triggering alarming function. DETECTION EZOOM SETUP Used to magnify, pan and tilt pictures. Used to enable or disable the digital image stabilization function.
  • Page 18: Picture Adjustment Menu

    Function Description Option ATW. HLC/BLC Used to enable or disable HLC or BLC. HLC works only in the dark environment, it can effectively inhibit the night open strong light source such as headlights. Used to enable SUPER-WDR, D-WDR, or disable WDR and set WDR-related parameters.
  • Page 19: System Setting Menu

    Figure 5-3 Picture adjustment menu Table 5-3 describes the function options on the picture adjustment menu. Table 5-3 Function options on the picture adjustment menu Function Option Description BRIGHTNESS Used to set the picture brightness level. The level ranges from 0 to 255. CONTRAST Used to set the picture contrast level.
  • Page 20: Privacy Mask Setup Menu

    Figure 5-4 System setting menu Table 5-4 describes the function options on the system setting menu. Table 5-4 Function options on the system setting menu Function Option Description SYNC MODE Used to display the current synchronization mode. When the synchronization mode is external synchronization, you can slightly adjust the picture level phase.
  • Page 21 Figure 5-5 Privacy mask setup menu Table 5-5 describes the function options on the privacy mask setup menu. Table 5-5 Function options on the privacy mask setup menu Function Description Option AREA Used to select an area to be edited. DISPLAY Used to enable or disable the function of displaying the selected area.
  • Page 22: Motion Detection Menu

    5.6 Motion Detection Menu When you select MOTION DETECTION on the OSD main menu and press the OSD menu control key, the MOTION DETECTION menu appears, as shown in Figure 5-6. Figure 5-6 Motion detection menu Table 5-6 describes the function options on the motion detection menu. Table 5-6 Function options on the motion detection menu Function Option Description...
  • Page 23: Maintenance Menu

    Figure 5-7 EZOOM SETUP menu Table 5-7 describes the function options on the EZOOM SETUP menu. Table 5-7 Function options on the EZOOM SETUP menu Function Description Option Used to magnify a picture. The magnification level ranges from 000 to 255. Used to pan a picture.
  • Page 24 Figure 5-8 Maintenance menu Table 5-8 describes the function options on the maintenance menu. Table 5-8 Function options on the maintenance menu Function Description Option CAMERA Used to reset the camera to factory settings. RESET W. PIX Used to configure white dot compensation. Available options are MASK MANUAL, AUTO, and DATA CLEAR.
  • Page 25: Technical Specifications

    Technical Specifications Table 6-1 lists the technical specifications of the camera. Table 6-1 Technical specifications Specifications Description Image sensor 1/3" Super HAD CCD II Effective pixels PAL: 976 (H) × 582 (V), NTSC: 976 (H) × 494 (V) Resolution 720 TVL ≥50 Db (weighting) Minimum 0.01 Lux (AGC ON), 0 Lux (IR LEDs ON)
  • Page 26 Specifications Description BNC connector, UTC+Video (1.0Vp-p/75Ω), PAL/NTSC Video output supported Lens Zoom lens: f= 2.8–12 mm Relative iris F1.4 value Horizontal view 92°~27.2° angle Φ14 Lens interface Auto Iris DC drive IR-LED Wavelength: 850 nm; IR-LED quantity: 8 pcs. IR-LED control ON: 1–5 Lux;...
  • Page 27: A Hazardous Substance Declaration

    Hazardous Substance Declaration Hazardous Substance or Element Hexavalent Polybrominated Component Plumbum Mercury Cadmium Polybrominated Chromium Diphenyl Ethers (Pb) (Hg) (Cd) Biphenyls (PBB) (Cr6+) (PBDE) Structural ○ ○ ○ ○ ○ × part Board/circuit ○ ○ ○ ○ ○ × module Cable ○...
  • Page 28 VIDEOR E. Hartig GmbH Exclusive distribution through specialised trade channels only. VIDEOR E. Hartig GmbH Carl-Zeiss-Straße 8 63322 Rödermark/Germany Tel. +49 (0) 6074 / 888-0 Technical changes reserved Fax +49 (0) 6074 / 888-100 www.videor.com...
