TP-Link AP300 Quick Installation Manual page 2

Client Mode
The AP device functions as a wireless adapter to connect the wired device (e.g. Xbox/TV) to a wireless network.
Internet
Host AP
Connect the device according to the steps A and B in the diagram.
1.
Turn on the power and wait until the Power (
2.
Connect your computer or smart device to the AP device via a wired or wireless connection.
3.
The default SSID and wireless password are printed on the product label.
4. Launch a web browser and enter http://tplinkap.net, then log in using admin (all lowercase)
for both Username and Password.
Hardware Information
LED:
LED Status
On
Off
Power
Blinking
On
Off
2.4GHz and 5GHz
On
Off
On
Off
Ethernet
Slow blinking
On
Quick blinking
WPS/Signal Strength
Solid blue
Solid orange
Off
Frequently Asked Questions (FAQ)
Q1. How do I restore the AP device to its factory default settings?
With the device powered on, use a pin to press and hold the Reset button for
five seconds until the Power LED starts blinking, then release the button.
.
Note: Upon resetting, all previous configurations will be cleared, and the AP device will reset
to the default AP Mode.
Q2. What can I do if the login window does not appear?
• Change the computer's static IP address to obtain an IP address
automatically.
• Verify if http://tplinkap.net or http://192.168.0.254 is correctly entered in
the web browser.
• Use another web browser and try again.
• Reboot your AP device and try again.
• Power off your host AP and enter http://tplinkap.net into the web browser
to try again.
Host AP's SSID
) LED is lit and stable.
Indication
The device is on.
The device is off.
The device is initializing or upgrading.
AP/Multi-SSID mode
The 2.4GHz and 5GHz wireless are working properly.
The 2.4GHz and 5GHz wireless are disabled.
Repeater/Bridge/Client mode
The host AP's 2.4GHz or 5GHz network is selected.
The host AP's 2.4GHz or 5GHz network is not selected.
A device is connected to the Ethernet port.
No device is connected to the Ethernet port.
WPS operation indicator
WPS connection is in process.
WPS connection is successful.
WPS connection fails.
Signal strength indicator (Repeater/Bridge/Client mode)
The signal strength is good.
The signal strength is too weak.
The device is disconnected from the host network.
Q3. How do I recover the AP device's web management password or
retrieve my Wi-Fi password?
• If you forget the password required to access the AP device's web
management page and your Wi-Fi password, you must restore the AP
device to its factory default settings.
• If your forget your Wi-Fi password, but are able to access the AP
device's management interface, connect a computer or mobile device
to the AP device via wired or wireless. Log in and go to Advanced >
Wireless > Basic Settings to retrieve or reset your Wi-Fi password.
Q4. What can I do if my wireless is not stable?
It may be caused by too much interference, you can try the following
methods:
• Set your wireless channel to a different channel.
• Move the AP device to a new location away from Bluetooth devices and
other household electronics, such as cordless phone, microwave, and baby
monitor, etc., to minimize signal interference.
Q5. What can I do to maximize my signal strength in Repeater/Bridge mode?
When choosing an ideal location to optimize wireless signal in Repeater/
Bridge mode, please use the following recommendations.
A
Click Quick Setup, then select your Region and click Next.
5.
Select Client mode and click Next. Follow the step-by-step on-screen instructions to
6.
complete the configuration.
Now, connect your wired-only device to the AP device using an Ethernet cable.
Enjoy!
Default Wireless Network Information:
The default case-sensitive SSIDs (Network Names) and Wireless Password/PIN are printed
on the product label.
LED Button:
Press this button to turn on or turn off the LEDs.
• The Best Way is Halfway
Generally, the ideal location for the repeater is halfway between your
wireless router and your wireless clients. If that is not possible, place it
closer to your wireless router to ensure stable performance.
• Less Obstacles Ensure Better Performance
Choose a location with less obstacles that may block the signal between
the AP device and the host network. An open corridor or a spacious
location is ideal.
• Less Interference Provides More Stability
Choose a location away from Bluetooth devices and other household
electronics, such as cordless phone, microwave, and baby monitor, etc.,
to minimize signal interference.
Other
Device
or
TV
or
B
