Applicable Tire Size:
18-inch – 20 x 1-1/8"
(ETRTO 28-451)
Max Tire Outer Diameter:
512 mm
Read this instructions carefully before use
Minoura Japan Headquarters
(for all customers)
1197-1 Godo, Anpachi, Gifu 503-2305 Japan
Phone: +81-584-27-3131 / Fax: +81-584-27-7505
Email: minoura@minoura.jp
www.minoura.jp
Indoor Bicycle Trainer for mini-velo
– instructions manual –
Minoura North American Tech Center
(for U.S. residents only)
1996 East Avenue, Hayward, CA 94541 U.S.A.
Phone: 1-510-538-8599 / Fax: 1-510-538-5899
Email: support@minourausa.com
(ver.2.0 2015/4)
Made in Japan
Advertisement
Related Manuals for MINOURA liveride lr240
Summary of Contents for MINOURA liveride lr240
- Page 1 Max Tire Outer Diameter: 512 mm Read this instructions carefully before use Minoura Japan Headquarters Minoura North American Tech Center (for all customers) (for U.S. residents only) 1197-1 Godo, Anpachi, Gifu 503-2305 Japan 1996 East Avenue, Hayward, CA 94541 U.S.A.
-
Page 2: Important Notice
• Use the supplied rear quick release skewer for maximum stability. Minoura is not responsible for any problem caused from using your own skewer. • Use on flat and level floor or ground, and fully open the legs for your safety. - Page 3 LR240 Schematics UF-10 UF-8 UF-6 UF-7 BF-8 GM-23 BF-4 BF-6 M5-2 BF-4 MF-3 BF-6 GM-9 GM-7 GM-6 GM-5 GM-4 GM-3 GM-2 GM-10 GM-16 GM-11 GM-12 < CAUTION > GM-13 Do NOT touch GM-2 "Alloy Rotor" during and 15 minutes after workout. It is VERY HOT.
- Page 4 1 x M4 Hex Wrench Replace your rear wheel quick release skewer to the supplied one. Minoura guarantees the stability only when using the supplied skewer due to the coupling inner shape. If your bike is not equipped with quick release skewer and it's a hub nut type, replace the left side coupling (UF-8) to the optional "Left Side Coupling for Hub...
- Page 5 Wipe all dust away from the rear tire surface and place your rear wheel in between the couplings. Loosen Lock Nut (Fig. C) 1) Loosen the lock nut (UF-9) to allow the left side coupling (UF-8) be free. (Fig. C) 2) Pull up the quick hub clamp lever (UF-6) to retract the right side coupling.
- Page 6 Contact the Drive Roller to the rear tire by turning the Roller Pressure Adjust Knob clockwise. (see Fig. J) The best position is that the roller compresses the tire in the depth of 3 – 4 mm. (see Fig. K) Please note too much and too less roller pressure will bring premature tire wear.
- Page 7 If the rear tire has touched any other parts than the Drive Roller, the part may be damaged and your tire will wear out quickly. It is impossible to adjust the rear wheel position by adjusting the left side coupling position.
- Page 8 Why My Remote Shifter Doesn't Work Properly? You may have a shifting problem that you cannot set at L or H position properly due to the lengthened inner cable. To fix this problem, follow the steps to adjust the initial cable tension. Set your remote shifter at "H"...
