Connect the Hardware

If your Internet connection is through an Ethernet
cable from the wall instead of through a Cable
modem, connect the Ethernet cable directly to
the Archer C7's Internet port.
Internet
Modem
Power adapter
Archer C7
Power adapter
1
Turn off the modem .
2
Connect the modem to the
Internet port on your Archer
C7 with an Ethernet cable.
3
Turn on the modem, and then
wait 2 minutes for it to restart.
4
Turn on the router.
5
Verify that the following LEDs are on and stable
before continuing with the configuration.
Power System 2.4G 5G
On Flashing Flashing Flashing
Note: If the 2.4G LED and 5G LED are off, please turn
on the Wireless On/Off switch on the rear panel. And 5
seconds later check the LEDs again.
Internet
On/Flashing
