Specifications - QSC HPR152F Manual

Configuration
1
Frequency Response (-6 dB)
1
Frequency Range (-10 dB limit)
Nominal Coverage (-6 dB)
Maximum SPL (1 meter)
Amplifiers
Power Output
Input Impedance
Controls
Indicators
Cooling
Amplifier Protection
Current consumption at 120 VAC
(1/8 power EIA noise)
Enclosure
Finish
Grille
Connectors
Dimensions (HWD)
Weight (Net)
Available Accessories
1) Measured in half-space
Specifications subject to change without notice.
HPR152F HPR153F
15" 2-way 15" 3-way
15" cone transducer with 15" cone transducer with
3" voice coil 3" voice coil
1.75" diaphragm compression driver 6.5" horn loaded mid-range
1.4" diaphragm compression driver
53 Hz - 18 kHz 42 Hz - 19 kHz
50 Hz - 20 kHz 38 Hz - 20 kHz
90° x 60° 90° x 40°
135 dB peak 133 dB peak
400 W LF Class H 400 W LF Class H
100 W HF Class AB+B 100 W MF Class AB+B
100 W HF Class AB+B
22k ohm balanced / 22k ohm balanced /
11k ohm unbalanced 11k ohm unbalanced
Gain Gain
Low-cut filter Low-cut filter
Front LED On/Off Front LED On/Off
Power Power
Circuit breaker Circuit breaker
Power Power
Signal Signal
Limit Limit
Convection Convection
Thermal and Output Thermal and Output
Power Limiting Power Limiting
1.5 A 1.8 A
Painted birch plywood Painted birch plywood
Black textured paint Black textured paint
Powder coated 16 gauge steel Powder coated 16 gauge steel
Balanced female XLR Balanced female XLR
line level input line level input
Balanced male XLR full range Balanced male XLR full range
line level out line level out
32" x 19" x 18" 44.75" x 19" x 18"
(813mm x 485mm x 455mm) (1137mm x 485mm x 455mm)
100 lbs / 45.5 kg 118 lbs / 54 kg
HPR COVER 152F HPR COVER 153F
HPR POLE 26
HPR151W HPR181W
15" subwoofer 18" subwoofer
15" cone transducer with 18" cone transducer with
3" voice coil 4" voice coil
47 Hz - 110 Hz 42 Hz - 110 Hz
43 Hz - 140 Hz 39 Hz - 140 Hz
N/A N/A
133 dB peak 134 dB peak
700 W Class H 700 W Class H
22k ohm balanced / 22k ohm balanced /
11k ohm unbalanced 11k ohm unbalanced
Gain Gain
Low-cut filter Low-cut filter
Front LED On/Off Front LED On/Off
Power Power
Circuit breaker Circuit breaker
Phase Phase
Power Power
Signal Signal
Limit Limit
Convection Convection
Thermal and Output Thermal and Output
Power Limiting Power Limiting
2.2 A 2.5 A
Painted birch plywood Painted birch plywood
Black textured paint Black textured paint
Powder coated 16 gauge steel Powder coated 16 gauge steel
Balanced female XLR Balanced female XLR
line level inputs x 2 (L+R) line level inputs x 2 (L+R)
Balanced male XLR full range Balanced male XLR full range
line level through puts x 2 (L+R) line level through puts x 2 (L+R)
Male XLR low-cut line level Male XLR low-cut line level
outputs x 2 (L+R) outputs x 2 (L+R)
25" x 22" x 20.75" 28" x 23.5" x 23"
(635mm x 559mm x 525mm) (711mm x 597mm x 582mm)
98 lbs / 44.5 kg 127 lbs / 58 kg
HPR COVER 151W HPR COVER 181W
HPR POLE 26 HPR POLE 26

Specifications
