Specifications

Supported sampling
AUDIO:
frequency:
VOICE:
Decoding/ Encoding:
AUDIO
VOICE:
No. of channels:
Stereo, 2 channels (AUDIO, TUNER)
Mono, 1 channel (VOICE Rec/ Play,
TUNER Rec/ Play)
Frequency response:
20Hz to 20,000Hz (+0dB, -7dB) (AUDIO)
20Hz to 3,000Hz (+0dB, -7dB) (VOICE)
Mic:
Mono
Radio Frequency range
EB,EG
(FM):
GC,GK
GN areas:
PP area:
Output level
3.3mW+ 3.3mW (16Ω, M3 jack)
Power supply:
DC1.2V (one rechargeable battery)
Approximate play
SD audio continuous playback:
*1
time
:
32kHz, 44.1kHz, and 48kHz
8kHz
AAC, WMA and MP3
G.726
87.50MHz to 108.00MHz
(50kHz steps)
87.90MHz
to
107.90MHz(200kHz steps)
87.50MHz
to
108.00MHz(50/100kHz
steps)
14hours 30minutes
SV-SD100VEB
SV-SD100VEG
SV-SD100VGC
SV-SD100VGK
SV-SD100VGN
SV-SD100VPP
Colour
(S)................... Silver Type
TUNER:
VOICE:
Approximate recording
TUNER REC: 4hours
*1
times
:
VOICE REC:
Maximum dimensions
42.9x 43.2 x 17.5mm
11
(WxHxD):
(1
Cabinet dimensions
42.0 x 42.0 x 17.5mm
21
(WxHxD):
(1
Mass:
39.9g (1.407oz.) with battery
27.4g (0.967oz.)without battery
AC adaptor input:
AC110V - 240V 50Hz/60Hz
Recording Media:
SD Memory Card
(card capacities between 8MB and 1GB)
· Specifications are subject to change without notice.
· The play times shown depend on operating conditions.
· Mass and dimensions are approximate.
· Useable capacity will be less.
· This unit is compatible with Windows Media Audio 9 (WMA9),
though not with WMA9 Professional/Lossless/Voice and MBR
*1
When the supplied rechargeable battery is fully charged.
*2
Multiple Bit Rate: A file that contains the same content encoded at
several different bit rates.
© 2005 Matsushita Electric Industrial Co., Ltd. All
rights
reserved.
distribution is a violation of law.
AD0503028CE
SD Audio Player
7hours 30minutes
11hours
6hours
11
11
/
"x1
/
"x
/
")
16
16
16
21
11
/
"x1
/
"x
/
")
32
32
16
Unauthorized
copying
A1
*2
.
and

Advertisement

Table of Contents
loading

Related Manuals for Panasonic SV-SD100VEB

Summary of Contents for Panasonic SV-SD100VEB

  • Page 1: Specifications

    AD0503028CE SD Audio Player SV-SD100VEB SV-SD100VEG SV-SD100VGC SV-SD100VGK SV-SD100VGN SV-SD100VPP Colour (S)....Silver Type Specifications Supported sampling AUDIO: 32kHz, 44.1kHz, and 48kHz TUNER: 7hours 30minutes frequency: VOICE: 8kHz VOICE: 11hours Approximate recording TUNER REC: 4hours Decoding/ Encoding: AUDIO AAC, WMA and MP3...

  • Page 2: Table Of Contents

    SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP CONTENTS Page Page 1 Accessories 8.8. SERVICE 6: Settings Readout 2 Location of Controls 8.9. SERVICE 7: Default Settings Writing 3 Power Supply Preparations 8.10. SERVICE 8: Card Recognition Operation Check 4 Caution for AC mains lead 8.11.

  • Page 3: Location Of Controls

    SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP 2 Location of Controls 3 Power Supply Preparations...

  • Page 4: Caution For Ac Mains Lead

    SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP 4 Caution for AC mains lead...

  • Page 5: Disassembly Instructions

    SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP 5 Disassembly Instructions · This section describes procedures for replacing the main components. · For reassembly after operation checks or replacement, reverse the respective procedures. Special reassembly procedures are described only when required.

  • Page 6: Removal Of The Sub1 P.c.b., Sub2 P.c.b. And Main

    SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP 5.2. Removal of the Sub1 P.C.B., Sub2 P.C.B. and Main P.C.B. · Follow the (Step 1) - (Step 4) of item 5.1.

  • Page 7: Removal Of The El

    SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP 5.3. Removal of the EL · Follow the (Step 1) - (Step 4) of item 5.1. · Follow the (Step 2) - (Step 3) of item 5.2.

  • Page 8: Service Position

    SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP 6 SERVICE POSITION This Service Position is used for checking and replacing parts. Use the following Extension cable and P.C.B. for servicing. 6.1. Extension cable and P.C.B. Parts No.

  • Page 9: Precautions When Executing The Main Pcb Replacement Service

    SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP 7 Precautions When The supplied device key loaded PCB (REP3902A-M) does not contain the regional default settings file. Executing The Main PCB That file must be written to the audio player by the procedure shown below.

  • Page 10: Entering The Service Mode

    SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP 8.2. Entering The Service Mode 1. Place a fully charged battery in the audio player and turn the power ON. 2. Select the audio mode. 3. Insert the service mode SD-card in the audio player.

  • Page 11: Service 1: El Display Mode Switching

    SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP Menu Item Service Mode Operation After Buttons Used Canceling The Service Mode Function Description Menu Selection Service Mode SERVICE 10 Checks Service mode None Open the battery Performs repeat playback and checks for voice...

  • Page 12: Service 3: Control Button Operation Check & Remaining Battery Capacity Display Check

    SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP 8.5. SERVICE 3: Control Button 8.5.1.2. KEY (Control Button´s AD Value) Operation Check & Remaining Displays the AD value judgment for the button operation. Battery Capacity Display Button Operation...

  • Page 13: Service 5: Settings Initialization (All Settings)

    SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP 8.7. SERVICE 5: Settings 8.10. SERVICE 8: Card Recognition Initialization (all settings) Operation Check Initializes the model & region settings, as well as resume Verifies that the SD-card (where audio file is saved) can be information, and the tuner´s preset frequency.

  • Page 14: Service 9: Audio Playback Check

    SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP 8.11. SERVICE 9: Audio Playback 8.12. SERVICE 10: Voice Playback Check Check Performs repeat playbacks, checking for audio playback errors. Performs repeat playbacks, checking for voice playback errors. 1. Execute the "8.3 SERVICE 1: EL Display Mode Switching"...

  • Page 15: Service 11: Voice Recording Check

    SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP 8.13. SERVICE 11: Voice Recording Check Repeats the "SD-card formatting, full recording (recording until card´s capacity is completely used), and playbacks" procedure, and checks for voice recording errors. 1. Execute the "8.3 SERVICE 1: EL Display Mode Switching"...

  • Page 16: Service 12: Fm Recording Check

    SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP 8.14. SERVICE 12: FM Recording Check Performs "FM radio reception, repeats the "SD-card formatting, full recording (recording until card´s capacity is completely used), and playback" procedure, and checks for FM recording errors.

  • Page 17: Service 13: Device Check

    SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP stops at that point. 3. Open the battery cover to end the procedure. Fig.S21 8.15.1. Explanation Of Device Check Results Fig.S20 Display Symptom/Condition Cause & Countermeasure Content 8.15. SERVICE 13: Device Check...
  • Page 18 SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP Error Code Error Description Cause Countermeasure 100B DIR entry reading error (secure) Hardware/software Replace the SD-card with another card. If the error persists, check the main PCB´s IC4 and peripheral circuitry.
  • Page 19 SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP Error Code Error Description Cause Countermeasure 8067 No vacancy in MSG processing queue software Try changing the SD-card, and turning the power OFF and ON. If the error persists, try removing the battery and installing it again.
  • Page 20 SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP Error Code Error Description Cause Countermeasure F006 No CHGACK interruption Hardware Try changing the SD-card, and turning the power OFF and ON. If the error persists, try removing the battery and installing it again.
  • Page 21 SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP Error Code Error Description Cause Countermeasure E00A No playback-enabled file Data Either perform a recording at the audio player, or replace the SD-card with a card that contains a recording.
  • Page 22 SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP Error Code Error Description Cause Countermeasure B078 File deletion ended in error software/Data Try changing the SD-card, and turning the power OFF and ON. If the error persists, try removing the battery and installing it again.

  • Page 23: Type Illustration Of Ics, Transistors And Diodes

    SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP 9 Type Illustration of ICs, Transistors and Diodes C0CBAAB00038 C0JBAF000529 C0DBAGE00018 C0EBD0000247 C1ZBZ0002665 21PIN C0CBAAC00166 C0JBAZ002327 C1ZBZ0002666 25PIN C3ZBL0000020 56PIN MN677381HAZR 164PIN ENWA9301R 24PIN C1BB00000909 B1CHMC000007 MNPH930FLDR 100PIN C0FBAJ000010...
  • Page 24 SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP...

  • Page 25: Schematic Diagram

    SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP 11 Schematic Diagram SCHEMATIC DIAGRAM-1 Note: The number which noted at the connectors on the schematic diagram as "SCHEMATIC DIAGRAM-1" or "SCHEMATIC DIAGRAM-2" MAIN CIRCUIT :POSITIVE VOLTAGE LINE :AUDIO(DIGITAL) SIGNAL LINE...
  • Page 26 SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP SCHEMATIC DIAGRAM-2 MAIN CIRCUIT :POSITIVE VOLTAGE LINE :AUDIO(DIGITAL) SIGNAL LINE :AUDIO(ANALOG) SIGNAL LINE :FM SIGNAL LINE (16.9344MHz) H G F E D C B A r q n m g f...
  • Page 27 SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP SCHEMATIC DIAGRAM-3 MAIN CIRCUIT :POSITIVE VOLTAGE LINE :AUDIO(ANALOG) SIGNAL LINE :FM SIGNAL LINE B1CHMC000007 RECHARGEABLE BATTERY DET. BATTERY 1.2V B1CHMC000007 POWER SUPPLY 1.5K B1GDCFLL0031 DTC144EETL SWITCHING SWITCHING (POWER OFF)
  • Page 28 SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP SCHEMATIC DIAGRAM-4 SUB(1) CIRCUIT :POSITIVE VOLTAGE LINE :AUDIO(DIGITAL) SIGNAL LINE :AUDIO(ANALOG) SIGNAL LINE :FM SIGNAL LINE :MIC SIGNAL LINE HS501 9 DATA2 1 DATA3 R527 2 CMD 5 CLK...
  • Page 29 SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP SCHEMATIC DIAGRAM-5 SUB(2) CIRCUIT :POSITIVE VOLTAGE LINE :AUDIO(ANALOG) SIGNAL LINE :FM SIGNAL LINE L310 L309 JK301 J0JCC0000307 J0JCC0000307 BATT2 L303 CL306 CL315 J0JBD0000045 R303 BATT3.3V USB TERMINAL VBUS CP301...
  • Page 30 SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP...

  • Page 31: Printed Circuit Board Diagram

    SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP 12 Printed Circuit Board Diagram Note: This printed circuit board diagram may be modified at any time with the development of new technology. MAIN P.C.B. (SIDE : B) MAIN P.C.B. (SIDE : A) SUB(1) P.C.B.
  • Page 32 SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP SUB(2) P.C.B. (SIDE : B) SUB(1) P.C.B. (SIDE : B) MAIN P.C.B.(CP1) HEADPHONE C519 24 26 28 30 32 34 36 38 M501 (MIC) CP501 JK302 R508 C531 17 15...

  • Page 33: Block Diagram

    SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP 13 Block Diagram 16,71, 48,74, 2,27,44, 72,76, 66,79, 7,21,31, 49,50,69, 77,86, 80,85, 108,143, 62,151, 107,109 154,159 SD CARD DACOR HEADPHONES DACOL 120,122, 14,15 LEFT ENWA9301R SDDAT0~3 IC301 RIGHT FM TUNER...
  • Page 34 SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP...

  • Page 35: Terminal Function Of Ics

    SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP 14 Terminal Function of ICs 14.1. IC3 (MNPH930FLDR): Terminal Function Name Microcomputer MND1 I/O Data I/O terminal MND2 I/O Data I/O terminal Terminal Function MND3 I/O Data I/O terminal...

  • Page 36: Caution In Use Of Rechargeable Battery

    SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP 15 Caution in use of Rechargeable Battery · Take Rechargeable Battery out of Carrying Case and use it. · Be sure to carry Rechargeable Battery in this Carrying Case.

  • Page 37: Stereo Earphones

    SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP 17 Replacement Parts List Notes: Ref. Part No. Part Name & Remarks Description · Important safety notice: A2-1 RFA0475-Q BATTERY CARRYING (GCS)(EBS) Components identified by mark have special CASE...
  • Page 38 SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description ECJ0EB1A104K 10V 0.1U C536 ECJ2FB0J106M 6.3V 10U ECUM1H080DCQ 50V 8P C537 ECJ0EC1H050C 50V 5P...
  • Page 39 SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description RPK2275 GIFT BOX (EBS)(EGS) ERJ2GEJ104 1/16W 100K RPK2276 GIFT BOX (GCS)(GNS) ERJ2RHD913 1/16W 91K...
  • Page 40 SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP Ref. Part No. Part Name & Remarks Description R503 ERJ2GEJ391 1/16W 390 R507 ERJ2GEJ100 1/16W 10 R508 ERJ2GEJ100 1/16W 10 R509 ERJ2GEJ2R2X 1/16W 2.2 ERJ2RMJ2R2X R510 ERJ2GEJ2R2X 1/16W 2.2...

  • Page 41: Cabinet Parts Location

    SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP 18 Cabinet Parts Location...

  • Page 42: Packaging

    SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP 19 Packaging 19.1. SV-SD100VEB/EG/GC/GK/GN...

  • Page 43: Sv-Sd100Vpp

    SV-SD100VEB / SV-SD100VEG / SV-SD100VGC / SV-SD100VGK / SV-SD100VGN / SV-SD100VPP 19.2. SV-SD100VPP K0503YH/HM...
