  • Page 1 TSA 4–700, TSA 1400, TSA 2200, TSA 4000 power amplifier user manual...
  • Page 2 Musikhaus Thomann e. K. Treppendorf 30 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 13.12.2012...

  • Page 3: Table Of Contents

    Table of contents Table of contents General notes............................... 4 Safety notes..............................7 Features............................... 12 Installation and operation........................13 4.1 Pin assignment..........................14 Connectors and controls........................16 Current consumption..........................24 Technical data............................27 Protecting the environment......................35 TSA 4–700, TSA 1400, TSA 2200, TSA 4000...

  • Page 4: General Notes

    General notes General notes This user manual contains important information on safe operation of the device. Read and follow all safety notes and all instructions. Save this manual for future reference. Make sure that it is available to all persons using this device. If you sell the device, include the manual for the next owner.
  • Page 5 General notes Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. CAUTION! This combination of symbol and signal word indicates a possible dangerous situation that can result in minor injury if it is not avoided.
  • Page 6 General notes Warning signs Type of danger Warning – danger zone. power amplifier...

  • Page 7: Safety Notes

    Safety notes Safety notes Intended use This device amplifies electric audio frequency signals to operate passive speakers. Use the device only as described in this user manual. Any other use or use under other operating con‐ ditions is considered to be improper and may result in personal injury or property damage. No liability will be assumed for damages resulting from improper use.
  • Page 8 Safety notes DANGER! Electric shock caused by high voltages inside Within the device there are areas where high voltages may be present. Never remove any covers. There are no user-serviceable parts inside. DANGER! Electric shock caused by short-circuit Always use proper ready-made insulated mains cabling (power cord) with a pro‐ tective contact plug.
  • Page 9 Safety notes CAUTION! Possible hearing damage The device can produce volume levels that may cause temporary or permanent hearing impairment. Over an extended period of time, even levels that seem to be uncritical can cause hearing damage. Decrease the volume level immediately if you experience ringing in your ears or hearing impairment.
  • Page 10 Safety notes NOTICE! Operating conditions This device has been designed for indoor use only. To prevent damage, never expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and strong vibrations. NOTICE! Power supply Before connecting the device, ensure that the input voltage (AC outlet) matches the voltage rating of the device and that the AC outlet is protected by a residual current circuit breaker.
  • Page 11 Safety notes NOTICE! Magnetic fields The device generates strong magnetic fields that can interfere with the function of poorly shielded devices. The strongest magnetic fields are directly above and below the power amplifier. Therefore, never place sensitive devices such as pre- amplifiers, radio transmission systems, or tape decks directly above or below the power amplifier.

  • Page 12: Features

    Features Features Common features of all device models described here: built-in switched-mode power supply XLR inputs and outputs lockable NL4 output sockets protective circuits – audio limiter – thermal protection – short-circuit protection suitable for 19" racks (2 rack units) Device-specific features, see Ä...

  • Page 13: Installation And Operation

    Installation and operation Installation and operation Unpack and check carefully there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the device against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively.

  • Page 14: 4.1 Pin Assignment

    Installation and operation 4.1 Pin assignment XLR connections for signal XLR panel sockets are provided for signal inputs. XLR panel plugs are provided for signal out‐ inputs/outputs puts. The figures and tables show the XLR pin assignment. Balanced pinout: Ground Positive signal (+) Negative signal (–) Unbalanced pinout:...
  • Page 15 Installation and operation NL4 panel connectors The adjoining figure shows the pin assignment of the lockable NL4 panel connectors. TSA 4–700, TSA 1400, TSA 2200, TSA 4000...

  • Page 16: Connectors And Controls

    Connectors and controls Connectors and controls TSA 4-700 front panel power amplifier...
  • Page 17 Connectors and controls 1 POWER Mains switch to turn the device on/off. 2 LED indicators for channels CH-A … CH-D These LEDs indicate the ready status of the device (Power), the input signal level (Signal / –20 / –15 / –10 / –5), channel overdrive (Clip) and a fault condition (Fault).
  • Page 18 Connectors and controls TSA 4-700 rear panel power amplifier...
  • Page 19 Connectors and controls 4 Plug for mains cable with fuse holder. 5 OUTPUT CH-A … CH-D Signal outputs, designed as lockable NL4 panel sockets for connecting speakers. 6, 9, 10, 11 INPUT CH-A … CH-D Signal input channels, designed as XLR socket pairs (input/output) for looping the signals through to other devices. 7 Stereo | Bridge selector switch Switch for toggling between “Stereo”...
  • Page 20 Connectors and controls TSA 1400, 2200, 4000 front panel power amplifier...
  • Page 21 Connectors and controls 1 POWER Mains switch to turn the device on/off. 2 LED indicators for channels CH-A and CH-B These LEDs indicate the ready status of the device (Power), the input signal level (Signal / –20 / –15 / –10 / –5), channel overdrive (Clip) and a fault condition (Fault).
  • Page 22 Connectors and controls TSA 1400, 2200, 4000 rear panel power amplifier...
  • Page 23 Connectors and controls 4 Plug for mains cable with fuse holder. 5 OUTPUT CH-A … CH-B Signal outputs, designed as lockable NL4 panel sockets for connecting speakers. 6, 9 INPUT CH-A … CH-B Signal input channels, designed as XLR socket pairs (input/output) for looping the signals through to other devices. 7 Stereo | Bridge selector switch Switch for toggling between “Stereo”...

  • Page 24: Current Consumption

    Current consumption Current consumption The tables below list typical current consumption values as a function of the power output level (A values). All values are based on a 220 V mains voltage. With a 230 V mains voltage, all values must be multiplied by 0.96. With a 120 V mains voltage, all values must be multiplied by 1.83.
  • Page 25 Current consumption TSA 1400 Load 1/8 power (pink 1/3 power (pink full power (sine noise) noise) wave) (2 ×) 8 W 330 W / 1.93 A 734 W / 4.4 A 1400 W / 7.74 A (2 ×) 4 W 480 W / 2.86 A 1200 W / 6.9 A 2300 W / 12.2 A...
  • Page 26 Current consumption Load 1/8 power (pink 1/3 power (pink full power (sine noise) noise) wave) (2 ×) 2 W 850 W / 5.0 A 1800 W / 9.8 A 4200 W / 21 A 8 W, bridged 680 W / 4.1 A 1200 W / 6.8 A 2850 W / 15.2 A 4 W, bridged...

  • Page 27: Technical Data

    Technical data Technical data TSA 4-700 Load impedance Nominal power output (THD = 1 %, 1 kHz) 4 × 490 W 4 × 810 W 4 × 930 W Max. power output, bridged mode 2 × 1600 W 2 × 1800 W –...
  • Page 28 Technical data Input impedance (20 Hz – 20 kHz, balanced) 20 kW (balanced) 10 kW (unbalanced) Input sensitivity (nominal power output, 1 kHz) Damping factor (100 Hz / 1 kHz, 8 W) > 400 Signal-to-noise ratio (SNR) 105 dB (A-weighted) Protective circuits Thermal, short circuit, limiter Cooling...
  • Page 29 Technical data TSA 1400 Load impedance Nominal power output (THD = 1 %, 1 kHz) 2 × 450 W 2 × 670 W 2 × 800 W Max. power output, bridged mode 2 × 1380 W 2 × 1600 W –...
  • Page 30 Technical data Input impedance (20 Hz – 20 kHz, balanced) 20 kW (balanced) 10 kW (unbalanced) Input sensitivity (nominal power output, 1 kHz) Damping factor (100 Hz / 1 kHz, 8 W) > 400 Signal-to-noise ratio (SNR) 105 dB (A-weighted) Protective circuits Thermal, short circuit, limiter Cooling...
  • Page 31 Technical data TSA 2200 Load impedance Nominal power output (THD = 1 %, 1 kHz) 2 × 590 W 2 × 910 W 2 × 1200 W Max. power output, bridged mode 2 × 1800 W 2 × 2400 W –...
  • Page 32 Technical data Input impedance (20 Hz – 20 kHz, balanced) 20 kW (balanced) 10 kW (unbalanced) Input sensitivity (nominal power output, 1 kHz) Damping factor (100 Hz / 1 kHz, 8 W) > 400 Signal-to-noise ratio (SNR) 105 dB (A-weighted) Protective circuits Thermal, short circuit, limiter Cooling...
  • Page 33 Technical data TSA 4000 Load impedance Nominal power output (THD = 1 %, 1 kHz) 2 × 1000 W 2 × 1500 – Max. power output, bridged mode 2 × 2865 W – – (THD = 1 %, 1 kHz) Max.
  • Page 34 Technical data Input impedance (20 Hz – 20 kHz, balanced) 20 kW (balanced) 10 kW (unbalanced) Input sensitivity (nominal power output, 1 kHz) Damping factor (100 Hz / 1 kHz, 8 W) > 450 Signal-to-noise ratio (SNR) 106 dB (A-weighted) Protective circuits Thermal, short circuit, limiter Cooling...

  • Page 35: Protecting The Environment

    Protecting the environment Protecting the environment Disposal of the packaging mate‐ rial For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling.
  • Page 36 Notes power amplifier...
  • Page 37 Notes TSA 4–700, TSA 1400, TSA 2200, TSA 4000...
  • Page 38 Notes power amplifier...
  • Page 40 Musikhaus Thomann e.K. · Treppendorf 30 · 96138 Burgebrach · Germany · www.thomann.de...
