- Page 1 PREMIER SERIES P1255RBL-18 P2339RBL-18...
- Page 3 P2339RBL-18 P1255RBL-18...
-
Page 6: Brief Introduction
Brief introduction Main specifications &RQVHZ 3 5%/ P P 2339RBL- P1255RB - DQG D OHYHU 35%/ 3 5%/ WR VHZ V DSSDUHO Machine installation... - Page 8 ° ～ ° ° ～...
-
Page 9: Machine Operation
3 5%/ Machine operation × ～ ～... -
Page 11: Machine Adjustment
① Machine adjustment... - Page 14 ～...
- Page 16 P2339RBL-...
- Page 17 1. P2339RBL‐18 Machine casting components Line Part Number Description Notes 300‐1002 Machine bed 200‐1004 Machine arm 200‐1373 A6X30 GB117‐86 200‐1374 Screw M10X35 GB70‐85 200‐1375 Screw M10X35 GB5781‐85 300‐1005 Model label 300‐1006 Brand label 200‐1376 Rivet ɸ2.5X5 GB827‐86 200‐1016 Upper thread guide 200‐1017 Screw SM11/64"X40/8 200‐1018 Back cover 200‐1019 Screw SM11/64"X40/9 200‐1377 Washer 200‐1020 Cover 200‐1021 Front slide plate 200‐1022 Screw SM11/64"X32/5.4...
- Page 18 1.P2339RBL-18 machine casting components...
- Page 19 1. P2339RBL‐18 Machine casting components Line Part Number Description Notes 200‐1056 Thread guide plate 200‐1058 Spring 200‐1060 Thread guide bracket screw assembly 200‐1062 Thread releasing pin (short) 200‐1064 Thread tension nut 200‐1065 Thread tension spring 200‐1067 Thread releasing disc 200‐1070 Thread tension disc 200‐1072 Screw 200‐1073 Screw 200‐1076 Thread controlling disc assembly 200‐1077 Screw SM9/64"X40/4.5 200‐1079 Stop plate 200‐1081 Thread take‐up spring 200‐1086 Thread take‐up spring shaft 200‐1084 Screw SM/64"X40/4.5 200‐1098 Thread releasing pin (long) 200‐1378 Thread tension retaining plate...
- Page 20 2. P1255RBL-18 machine casting components...
- Page 21 2. P1255RBL‐18 Machine casting components Line Part Number Description Notes 200‐1001 Machine bed 200‐1004 Machine arm 200‐1373 A6X30 GB117‐86 200‐1374 Screw M10X35 GB70‐85 200‐1375 Screw M10X35 GB5781‐85 200‐1011 Model label 200‐1013 Brand label 200‐1376 Rivet ɸ2.5X5 GB827‐86 200‐1016 Upper thread guide 200‐1017 Screw SM11/64"X40/8 200‐1018 Back cover 200‐1019 Screw SM11/64"X40/9 200‐1377 Washer 200‐1020 Cover 200‐1021 Front slide plate 200‐1022 Screw SM11/64"X32/5.4...
- Page 22 2. P1255RBL-18 machine casting components...
- Page 23 2. P1255RBL‐18 Machine casting components Line Part Number Description Notes 200‐1060 Thread guide bracket screw assembly 200‐1062 Thread releasing pin (short) 200‐1064 Thread tension nut 200‐1065 Thread tension spring 200‐1067 Thread releasing disc 200‐1070 Thread tension disc 200‐1072 Screw 200‐1073 Screw 200‐1076 Thread controlling disc assembly 200‐1077 Screw SM9/64"X40/4.5 200‐1079 Stop plate 200‐1081 Thread take‐up spring 200‐1083 Thread take‐up spring shaft 200‐1084 Screw SM/64"X40/4.5 200‐1086 Thread releasing pin (long) 200‐1378 Thread tension retaining plate 200‐1089 Thread releasing spring 100‐1027 Screw...
- Page 24 3. Upper shaft and presser foot components...
- Page 25 3. Upper shaft and presser foot components Line Part Number Description Notes 200‐1101 Upper shaft 200‐1102 Upper shaft bushing (front) 200‐1103 Screw SM1/4"X24/13 200‐1104 Oil felt Wool felt 200‐1105 Needle crank 200‐1106 Screw SM9/32"/28 200‐1108 Screw 200‐1109 Screw SM1/4"X40/7 200‐1110 Screw SM1/4"X40/4 200‐1111 Eccentric cam 200‐1379 Stop ring ɸ25 GB894.1‐86 200‐1114 Slot for front crank sliding block 200‐1116 Stop ring 200‐1117 Screw SM15/64"X28/8.5 200‐1119 Screw SM15/64"X28/15...
- Page 26 4. Needle bar and lower shaft components...
- Page 27 4. Needle bar and lower feed components Line Part Number Description Notes 200‐1382 Oil wick ɸ2.5X80 cotton thread 200‐1383 Shaft for needle bar rocking frame 200‐1384 Screw SM5/16"X28/10 100‐1049 Screw SM15/64"X28/8 200‐1385 Oil wick ɸ2.5X240 cotton thread 200‐1386 Bushing 200‐1387 Thread take‐up lever 200‐1388 Thread take‐up lever sliding block 200‐1123 Screw SM15/64"X28/12 200‐1389 Oil wick ɸ3x25 200‐1390 Plug 200‐1391 Needle bar crank pin 200‐1392 Oil wick ɸ3x80 cotton thread 200‐1393 Needle bar link 200‐1394 Needle bar rocking frame 200‐1395...
- Page 28 4. Needle bar and lower shaft components...
- Page 29 4. Needle bar and lower feed components Line Part Number Description Notes 200‐1418 Bushing 200‐1147 Screw SM1/4"X24/8 200‐1419 Needle bar rocking shaft 200‐1145 Screw 200‐1420 Rear crank 200‐1421 200‐1422 Link lever 200‐1423 Screw 200‐1424 Feed shaft right crank 200‐1425 Pin 200‐1426 Washer 200‐1139 200‐1427 Feed shaft bushing 200‐1103 Screw 200‐1428 Collar 200‐1110 Screw SM1/4"X40/4 200‐1429 Feed crank 200‐1171 Split stop ring Stop ring 5 GB896‐86 200‐1430...
- Page 30 5. Lower shaft thread looping components...
- Page 31 5. Lower shaft thread looping components Line Part Number Description Notes 200‐1178 Right hook saddle 200‐1179 Screw 2 (1) SM14/64"X28 200‐1180 Upper bushing 2 (1) 200‐1181 Lower bushing 2 (1) 200‐1182 Rotary hook assembly 2 (1) 200‐1183 Bobbin 2 (1) 200‐1184 Oil wick 2 (1) ɸ2.5X14 cotton thread 200‐1185 Hinge shaft 2 (1) 200‐1186 Screw 2 (1) SM3/16"X32 200‐1187 Link lever 2 (1) 200‐1188 Inner hook finger bracket 2 (1) 200‐1116 Screw 2 (1)
- Page 32 6. Stitch length adjustment components...
- Page 33 6. Stitch length adjustment components Line Part Number Description Notes 200‐1237 Stitch length adjusting rocking lever 200‐1238 Screw SM15/64"X28/8.5 200‐1239 Set screw SM15/64"X28/12 200‐1240 Stitch length link 200‐1241 Eccentric shaft 200‐1242 Reverse feed shaft 200‐1243 Reverse feed crank 200‐1244 Screw SM15/64"X28/13 200‐1245 Screw SM15/64"X40/10.5 200‐1246 Reverse feed lever 200‐1247 Sliding block 200‐1248 Crank spring 200‐1249 Spring bracket 200‐1250 Screw SM11/64"X40/8 200‐1251 Stop pin 200‐1252 Spring 200‐1254...
- Page 34 7. Knee lifter and winding components...
- Page 35 7. Knee lifter and winding components Line Part Number Description Notes 200‐1266 Screw 200‐1267 100‐1017 Thread tension spring 100‐1019 Thread tension disc 200‐1268 Thread tension shaft 200‐1269 Crank 200‐1270 Screw 200‐1272 Bobbin winding pulley 200‐1273 Screw 200‐1274 Friction ring 200‐1275 Winder base 200‐1277 Winding crank 200‐1279 200‐1281 Screw (lower) 200‐1283 Winding spanner 200‐1285 Spring lever 200‐1286 Screw 200‐1288 Screw 200‐1289 Screw 200‐1290 Winding spanner shaft...
- Page 36 8. Lubrication components...
-
Page 37: Lubrication Components
8. Lubrication components Line Part Number Description Notes 200‐1311 Oil felt press spring 200‐1312 Screw SM3/16"X28/12 200‐1313 Oil felt Wool felt 200‐1314 Oil pipe 3DX0.5X60 200‐1315 Oil wick Cotton thread 200‐1316 Oil cup 200‐1317 Oil cup cover 200‐1476 Screw M4X16 GB69‐85 200‐1320 200‐1321 Oil wick press spring 200‐1322 Oil pipe 3DX1X400 200‐1323 Oil draining pipe 5DX1X400 200‐1324 Oil wick ɸ2.5X550 cotton thread 200‐1325 Oil pipe positioning clamp 200‐1326 Needle bar oil returning pipe 3DX0.5X150... - Page 38 9. Accessories...
- Page 39 9. Accessories Line Part Number Description Notes 100‐1299 Parts bag 100‐1310 Casting hinge 100‐1311 Casting hinge cushion 200‐1356 Casting cushion (big) 200‐1357 Casting cushion 200‐1183 Bobbin 100‐1309 Oil pot 200‐1358 V‐belt O' type 1050 200‐1167 Needle 1 bag DPX17 23# 200‐1361 Hexagon wrench S=2.5MM 200‐1362 Hexagon wrench S=3MM 100‐1302 Srewdriver (big) 100‐1301 Screwdriver (middle) 100‐1300 Screwdriver (small) 200‐1365 Needle thread guide assembly 200‐1367 Machine head cover 100‐1314...
