Summary of Contents for Atlantis Land A02-F16(24)/M2
- Page 1 16(24)-Port 10/100Mbps Fast Ethernet Switch Layer 2 (Rackmount) User’s Guide...
-
Page 2: Fcc Warning
The Atlantis Land logo is a registered trademark of Atlantis Land SpA. All other names mentioned mat be trademarks or registered trademarks of their respective owners. Subject to change without notice. No liability for technical errors and/or omissions. FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. -
Page 3: Table Of Contents
ABLE OF ONTENTS About This Guide ... 1 ... 1 URPOSE ... 1 ERMS SAGE VERVIEW OF THIS Introduction ... 2 THERNET WITCHING ECHNOLOGY ... 4 EATURES Unpacking and Installation... 6 ... 6 NPACKING ... 6 NSTALLATION OUNTING Identifying External Components... 9 ... -
Page 4: About This Guide
This guide discusses how to install your 16(24)-port 10/100Mbps Fast Ethernet Switch. Terms/Usage In this guide, the term “Switch” (first letter upper case) refers to your 16(24)-port 10/100Mbps Fast Ethernet Switch, and ”switch” (first letter lower case) refers to other Ethernet switches. -
Page 5: Introduction
NTRODUCTION This chapter describes the features of the Switch and some background information about Ethernet/Fast Ethernet switching technology. Fast Ethernet Technology The growing importance of LANs and the increasing complexity of desktop computing applications are fueling the need for high performance networks. -
Page 6: Switching Technology
For Fast Ethernet networks, a switch is an effective way of eliminating problems of chaining hubs beyond the “two-repeater limit.” A switch can be used to split parts of the network into different collision... -
Page 7: Features
As all ports support 200Mbps, the Switch can be cascaded from any port and to any number of switches. The Switch is a perfect choice for site planning to upgrade to Fast Ethernet in the future. Ethernet workgroups can connect to the Switch now, and change adapters and hubs anytime later without needing to change the Switch or reconfigure the network. - Page 8 The Switch is an unmanaged 10/100 Fast Ethernet Switch that offers solutions in accelerating small Ethernet workgroup bandwidth. Other key features are: 16(24)-port 10/100BASE connectors Support Auto-negotiation for speed and duplex modes for each port Supports Auto-MDI/MDI-X for each port...
-
Page 9: Unpacking And Installation
If any item is found missing or damaged, please contact your local reseller for replacement. Installation The site where you install the Switch stack may greatly affect its performance. When installing, consider the following pointers: Install the Switch in a fairly cool and dry place. See Specifications for the acceptable temperature and humidity operating ranges. -
Page 10: Rack Mounting
Install the Switch on a sturdy, level surface that can support its weight, or in an EIA standard-size equipment rack. For information on rack installation, see the next section, Rack Mounting. When installing the Switch on a level surface, attach the rubber feet to the bottom of each device. -
Page 12: Identifying External Components
LINK 100Mbps 16 and 24 -port 10/100Mbps Fast Ethernet Switch LED Indicator Panel Refer to the detailed information about each of the switch’s LED indicators. Power (PWR) This indicator lights green when the switch is receiving power, otherwise, it is off. -
Page 13: Rear Panel
Link / Activity ( green ) This indicator light green when the port is connected to a Fast Ethernet or Ethernet station, if the indicator blinking green will be transmission or received data . 100Mbps ( green ) This LED indicator light green when the port is connected to a 100Mbps Fast Ethernet station. - Page 14 If you continue to have problems you should contact the dealer where you bought this product. If you have any other questions you can contact the Atlantis Land company directly at the following address: AtlantisLand spa Via Gandhi 5 Ing2,Scala A...
-
Page 15: Technical Specification
ECHNICAL IEEE 802.3 10BASE-T Ethernet Standards IEEE 802.3u 100BASE-TX Fast Ethernet Protocol CSMA/CD Data Transfer Ethernet: 10Mbps (half duplex), 20Mbps (full-duplex) Rate Fast Ethernet: 100Mbps (half duplex), 200Mbps (full- duplex) Topology Star 10BASET: 2-pair UTP Cat. 3,4,5, EIA/TIA- 568 100-ohm STP Network Cables 100BASE-TX: 2-pair UTP Cat. - Page 16 Transmits Store-and-forward Method: RAM Buffer: 512(2500)KBytes per device Filtering 8K entries per device Address Table: Packet 10Mbps Ethernet: 14,880/pps Filtering/Forwar 100Mbps Fast Ethernet: 148,800/pps ding Rate: MAC Address Automatic update Learning: Performance...
