- Page 1 16 ports 10/100Mbps Fats Ethernet Switch Layer 2 with 1 optional port 100Base-FX Fiber Module USER’S GUIDE...
-
Page 3: Fcc Warning
The Atlantis Land logo is a registered trademark of Atlants Land SpA. All other names mentioned mat be trademarks or registered trademarks of their respective owners. Subject to change without notice. No liability for technical errors and/or omissions. FCC Warning... - Page 4 UL Warning a) Elevated Operating Ambient Temperature- If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer's maximum rated ambient temperature (Tmra).
- Page 5 attention should be given to supply connections other than direct connections to the branch circuit (e.g., use of power strips).
-
Page 6: Table Of Contents
A B L E O F O N T E N T S ABOUT THIS GUIDE... 1 ... 1 URPOSE ... 1 ERMS SAGE INTRODUCTION ... 3 THERNET ECHNOLOGY WITCHING ECHNOLOGY VLAN (V IRTUAL OCAL ... 6 EATURES UNPACKING AND INSTALLATION ... 7 ... - Page 7 ... 17 OGIN ... 18 ONFIGURING ETUP ETTING ONFIGURING YSTEM ONFIGURING ETTING ... 25 TATISTICS TECHNICAL SPECIFICATIONS ... 28 A02-F16-F/M2 (september 2002) ... 19 ... 23 ETTING ... 24...
-
Page 8: About This Guide
100Mbps Fast Ethernet and 10Mbps Ethernet network capabilities in a highly flexible package. Purpose This guide discusses how to install your 16-Port 10/100Mbps Fast Ethernet Smart Switch. Terms/Usage In this guide, the term “ Switch ” (first letter upper case) refers to your 16-Port 10/100Mbps Fast Ethernet Smart Switch, and “... -
Page 9: Introduction
N T R O D U C T I O N This chapter describes the features of the 16-Port 10/100Mbps Fast Ethernet Smart Switch and some background information about Ethernet/Fast Ethernet and Switching technology. Fast Ethernet Technology The growing importance of LANs and the increasing complexity of desktop computing applications are fueling the need for high performance networks. -
Page 10: Switching Technology
the existing investment in hardware, software, and personnel training. Switching Technology Another approach to pushing beyond the limits of Ethernet technology is the development of switching technology. A switch bridges Ethernet packets at the MAC address level of the Ethernet protocol transmitting among connected Ethernet or Fast Ethernet LAN segments. -
Page 11: Vlan (Virtual Local Area Network)
networks, but the cost of a router, the setup and maintenance required make routers relatively impractical. Today switches are an ideal solution to most kinds of local area network congestion problems. VLAN (Virtual Local Area Network) A VLAN is a group of end-stations that are not constrained by their physical location and can communicate as if a common broadcast domain, a LAN. -
Page 12: Features
Features 16×10/100Mbps Auto-negotiation Ethernet ports All ports support auto MDI/MDIX, so there is no need to use cross-over cables or an up-link port Full/half duplex transfer mode for each port Wire speed reception and transmission Store-and-Forward switching scheme capability to... -
Page 13: Unpacking And Installation
Open the shipping cartons of the Switch and carefully unpacks its contents. The carton should contain the following items: One 16-Port 10/100Mbps Fast Ethernet Smart Switch One AC power cord, suitable for your area’s electrical power connections Four rubber feet to be used for shock cushioning... -
Page 14: Installation
Installation The site where you install the hub stack may greatly affect its performance. When installing, consider the following pointers: Install the Switch in a fairly cool and dry place. See Technical Specifications for the acceptable temperature and humidity operating ranges. Install the Switch in a site free from strong electromagnetic field generators (such as motors), vibration, dust, and direct exposure to sunlight. -
Page 15: Rack Mounting
Rack Mounting The switch can be mounted in an EIA standard-size, 19-inch rack, which can be placed in a wiring closet with other equipment. Attach the mounting brackets at the switch’s front panel (one on each side), and secure them with the provided screws. Figure 1. -
Page 16: Connecting Network Cable
Figure 2. Mount the Switch in the rack Connecting Network Cable The Switch supports 10Mbps Ethernet or 100Mbps Fast Ethernet and it runs both in half and full duplex mode. These ports are Auto-MDI type port. The Switch can auto transform to MDI-II or MDI-X type, so you can just make an easy connection that without worrying if you are using a standard or crossover... -
Page 17: Identifying External Components
Switch. Front Panel The figure below shows the front panels of the Switch. Figure 3. Front panel of 16-port 10/100Mbps Fast LED Indicator Comprehensive LED indicators display the status of the switch and the network (see the LED Indicators chapter below). -
Page 18: Rear Panel
Console Port An RS-232 DCE console port is set up and managed the switch via a connection to a console terminal or PC using a terminal emulation program. Rear Panel Figure 4. Rear panel of the Switch AC Power Connector This is a three-pronged connector that supports the power cord. -
Page 19: Understanding Led Indicators
N D E R S T A N D I N G The front panel LEDs provides instant status feedback, and help monitor and troubleshoot when needed. 16-Port 10/100Mbps Ethernet Smart Switch POWER Link/ACT SYSTEM Figure 5. LED indicators of the Switch... -
Page 20: Ports 1~16 Status Leds
Ports 1~16 Status LEDs Link/ACT : When the Link/ACT LED lights on, the respective port is successfully connected to an Ethernet network. Blinking : When the Link/ACT LED is blinking, the port is transmitting or receiving data on the Ethernet network. : No link. -
Page 21: Configuration
ONFIGURATION This Switch is an unmanaged, but “smart” Switch because programmable administration parameters make the Switch operate more effectively than unmanaged (dumb) switches. This chapter will describe how to configure the Switch. Console Port (RS-232 DCE) The console configuration requires connecting a terminal, such as a Workstation or a PC running a terminal emulation program (such as HyperTerminal, which is automatically installed with Microsoft... -
Page 22: Configuring The Switch
Configuring the Switch The 16-Port 10/100Mbps Fast Ethernet Smart Switch has a menu-driven console interface for smart switch configuration. The Switch can be configured through the serial port. A network administrator can manage, control and monitor the switch from the console program. This section indicates how... -
Page 23: Login
Login First execute the terminal emulation program on the remote workstation, and turn on the Switch. When login to the Switch, the following screen (Figure 10) prompt: Password: Input the password in the blank, and then press Enter to login Main Menu. -
Page 24: Main Menu
Main Menu The main menu appears, as shown in Figure 11. Find the console keys in the lower part of the screen. Move to highlight a desired option by using Up Arrow, Down Arrow and Tab keys, and then press Enter key to confirm. -
Page 25: Configuring Setup Setting
Configuring Setup Setting Find that there are two items, including Port Configuration and VLAN in Setup menu, shown as Figure 12. Port Configuration In Port Configuration menu (Figure 13), each port’s (port 17: Fiber Port) Speed, Flow Control, and QoS can be controlled. - Page 26 Figure 13. Port Configuration (1) Speed There are five modes— Auto, 100M Full, 100M Half, 10M Full, and 10M Half—for speed selections. To change the speed setting, highlight Port and enter the port number to select the desired port, next highlight Speed, click Enter, and use Space Bar to toggle back and forth between the five different options.
- Page 27 (3) QoS If some ports need to have the priority to manage the data transfer, QoS should be change. QoS has two functions to alter, High and Low. The default settings of all ports’ QoS are High. To change the QoS setting, highlight Port and enter the port number to select the desired port.
- Page 28 Figure 14. VLAN Configuration For example, there are five computers (PC1~PC5) connected to the Switch’s port 1~5. They had been divided into two VLAN groups: VLAN1 (PC1~PC4) and VLAN2 (PC2~PC5). There is no way to connect PC1 and PC5 shown as Figure 15. If PC1 has to connect to PC5, it should joint PC1 and PC5 in the same VLAN.
- Page 29 VLAN groups. Both VLAN groups are independent and there’s no link between these VLAN groups. The Switch can be regarded as two smaller switches. 16-Port 10/100Mbps Ethernet Smart Switch P O W E R Link/ACT S Y STE M Figure 16.
- Page 30 Figure 17. System Setting Configuring File Setting The Switch can be uploaded or downloaded its configuration files by using the File screen shown in Figure 18. Upload Configuration : Select this for back up a file the setting from the device. (in Hyper Terminal, Transfer > Receive File) Download Configuration : Select this for downlading the back up file to the device.
-
Page 31: S Tatistics
Figure 18. File installation Statistics Statistics Menu In the Statistics menu screen (shown Figure 19), all ports’ transferring (Tx) and receiving (Rx) status summaries can be viewed. - Page 32 Figure 19. Statistics Statistics Detail Highlight Port and enter port number to view the statistics details (see Figure 20).
- Page 33 Figure 20. Statistics Detail...
- Page 34 E C H N I C A L IEEE 802.3 10BASE-T Ethernet Standards IEEE 802.3u 100 BASE-TX, 100BASE-FX Fast CSMA/CD Protocol Data Ethernet: 10Mbps (half duplex), 20Mbps (full duplex) Fast Ethernet: 100Mbps (half duplex), 200Mbps (full Topology Star 10BASE-T: 2-pair UTP/STP Cat. 3, 4, 5; up to 100m 100BASE-TX: 2-pair UTP/STP Cat.
-
Page 35: Physical And Environmental
Number of 16 × 10/100Mbps Auto-MDIX STP ports 1 × expansion slot for 100BASE-FX fiber module Physical and Environmental... - Page 36 AC inputs: Power Consumption: Temperature: Humidity: Dimensions: Weight: Emissions: Safety: Transmits Method: RAM Buffer: Filtering Address Table: Packet Filtering/Forwarding Rate: MAC Address Learning: 100~240V AC, 50/60 Hz internal universal power supply 12 watts. (max.) Operating: 0°~40°C, Storage: -10°~70°C Operating: 10%~90% RH, Storage: 5%~90% RH 440 x 140 x 44 mm (W x H x D) 2.0kg...
