You can find VT100 terminals on most PCs by navigating to Start > Programs >
Accessories > Communications > HyperTerminal> HyperTerminal. When you
have opened a Hyper Terminal session, enter the settings described in Step 4.
1. Connect the DB-9 (male) connector of your serial cable to the CONSOLE port on the rear
panel of the unit.
2. Connect the other end of the serial cable to the terminal or PC.
Many PCs do not come with a standard serial port. A universal serial bus (USB)
to serial adapter can be used instead. The drivers for the USB to serial adapter
must be installed according to the manufacturer's instructions. If the USB to
serial adapter is not properly installed on your PC, you will not be able to
communicate with the AOS unit and you should seek support from the USB to
serial adapter manufacturer.
3. Provide power to the unit as appropriate. Refer to the NetVanta 3000 Series Hardware
Installation Guide (provided on the AOS Documentation CD or available online at
http://kb.adtran.com
4. Once the unit is powered up, open a VT100 terminal session using the following settings:
9600 baud, 8 data bits, no parity bits, 1 stop bit, and no flow control. Press <Enter> to
activate the AOS CLI.
5. Enter enable at the > prompt and enter the Enable mode password when prompted. The
default password is password.
You can also access the CLI from a Telnet client. In order to do this, you must know the IP
address of the AOS device. If you do not know the unit's IP address, you must use the CONSOLE
port to access the CLI. To access the CLI using a Telnet client, follow these steps:
1. Connect the AOS device's ETH 0/1 port to your computer's Ethernet interface using an
Ethernet Cross-over cable.
2. Open a Telnet client on your computer. You can access the Telnet client by navigating to
Start > Run and entering telnet 10.10.10.1 (Windows XP). If you are running Windows
Vista, you will need to turn on the Telnet client before you access it. To do this, navigate to
Start > Control Panel > Programs and Features > Turn Windows features on or off >
Telnet Client Option and select OK. 10.10.10.1 is the default unit IP address. If you have
changed your unit's IP address, you will need to enter that address.
3. Enter enable at the > prompt and enter the enable password when prompted. The default
password is password.
C CLI C
OMMON
The following are common CLI commands and tips for getting started with the CLI.
• Entering a question mark (?) shows contextual help and options. For example, entering ? at
the prompt will show all commands available from that prompt.
• To view interface statistics, enter show interface <interface type> <interface number>.
• To view the current configuration, enter show running-config.
2
(article number 2263) for more details.
OMMANDS
