Page 1: Technical Data
Air Conditioning Technical Data Wall mounted unit EEDEN15-100 FTX-GV... -
Page 3: Table Of Contents
• Indoor Unit • FTX-GV TABLE OF CONTENTS FTX-GV Features ............. 2 Specifications . -
Page 4: Features
• Indoor Unit • FTX-GV Features Wall mounted unit providing high efficiency and comfort U n i - G V d o o F T X • Online controller (optional): control your indoor unit from any location • Home leave operation maintains the indoor temperature at your via smartphone, laptop, pc, tablet or touch screen specified comfort level during absence, thus saving energy •... -
Page 5: Specifications
• Indoor Unit • FTX-GV Specifications 2-1 Technical Specifications FTX50GV FTX60GV FTX71GV Power input Cooling Nom. 0.034 0.040 (1) / 0.040 (2) / 0.040 (3) 0.045 (1) / 0.045 (2) / 0.045 (3) Heating Nom. 0.036 0.045 (1) / 0.045 (2) / 0.045 (3) 0.060 (1) / 0.060 (2) / 0.06 (3) -
Page 6: Electrical Specifications
• Indoor Unit • FTX-GV Specifications 2-1 Technical Specifications FTX50GV FTX60GV FTX71GV Piping connections Liquid 6.35 12.7 15.9 Drain Heat insulation Both liquid and gas pipes Temperature control Microcomputer control Air direction control Right, Left, Horizontal, Downward Standard Accessories : Operation manual; Quantity : 1;... -
Page 7: Options
• Indoor Unit • FTX-GV Options 3 - 1 Options • Split - Sky Air • FTX-GV... -
Page 8: Dimensional Drawings
• Indoor Unit • FTX-GV Dimensional drawings 4 - 1 Dimensional Drawings FTX50-60GV Air flow (indoor) (For performance and maintenance) The mark shows piping direction Rear Rear Left Right (Space for maintenance) Min. 50 Min. 50 (Space for (Including REQUIRED SPACE maintenance) installation plate) Operation lamp... -
Page 9: Centre Of Gravity
• Indoor Unit • FTX-GV Centre of gravity 5 - 1 Centre of Gravity FTX50-71GV 4D065971B B B • Split - Sky Air • FTX-GV... -
Page 10: Piping Diagrams
• Indoor Unit • FTX-GV Piping diagrams 6 - 1 Piping Diagrams • Split - Sky Air • FTX-GV... -
Page 11: Wiring Diagrams
• Indoor Unit • FTX-GV Wiring diagrams 7 - 1 Wiring Diagrams - Single Phase FTX50-71GV Field wiring RECTIFIER Outdoor CAUTION Transmission Note that operation will restart circuit automatically if the main power supply is turned off and then back on again. -
Page 12: Sound Data
• Indoor Unit • FTX-GV Sound data 8 - 1 Sound Pressure Spectrum FTX60GV Cooling Heating Approximate Approximate threshold hearing threshold hearing for continuous for continuous noise noise Octave band center frequency - IEC (Hz) Octave band center frequency - IEC (Hz) 50Hz 50Hz Scale... - Page 13 • Indoor Unit • FTX-GV Sound data 8 - 1 Sound Pressure Spectrum FTX71GV Cooling Heating Approximate Approximate threshold hearing threshold hearing for continuous for continuous noise noise 3D051225D 3D051225D Octave band center frequency - IEC (Hz) Octave band center frequency - IEC (Hz) 50Hz 50Hz Scale...
