INTRODUCTION Always follow the instructions in this manual before using the device. Please keep this manual easily accessible in the vehicle for future reference. Features • iGo Primo, 3D Navisoftware with TMC on 8GB SD card, 46 countries including Turkey with Points of Interests display and search function, 3D building views, TTS voice output, warnings, over 25 system and prompt languages . Latest Map Guarantee (30 days) after activation via www.naviextras.com. • High-resolution 17.8 cm (7“) LCD touchscreen display with 800 x 480 pixels • Improved i9 operating system based on Microsoft Windows CE 6 • 800 MHz ARM 11CPU, 300 MHz DSP, 4 GB iNand Flash Drive, 256 MB DDR1-RAM, 256 MB NAND Flash RAM • Bluetooth™ handsfree, phone book synchronization and A2DP audio streaming • Media playback (MP3/WMA/MPEG4/MPEG1/2/WMV/AVI/DivX etc.) • DVD-Player (DVD, DVD-R/RW, DVD+R/RW, VCD, CD, CD-R/RW, MP3) • File manager with an open file structure, photo slideshow, compatible with MS Office applications • MicroSD card slot and USB port with copy function... -
Page 3: Table Of Contents
INDEX Safety Information ...........................4 Basic functions ............................6 Operating elements .................................6 Main menu ....................................7 Navigation ....................................8 Audio player ....................................9 Radio .....................................10 DVD (DVD/CD-Player)................................11 Bluetooth™...................................13 Apps ......................................16 – LinkPod (optional) ................................17 – Video ....................................17 – TV (optional) ..................................18 – Files ....................................18 – Internet (optional) ................................19 – Options ....................................20 – Audio ....................................23 Custom settings .............................24 Menu assignments ................................24 Wallpaper ....................................25 Start logo ....................................26 Troubleshooting . -
Page 4: Safety Information
SAFETY INFORMATION • In general, the assembly and installation of the device must be performed by a trained and technically skilled specialists, as the installation and connection of the device requires complex knowledge. • This device is only suitable for the operation in a vehicle with an on-board voltage of 12 volts, negative ground. • Improper installation or use may void the warranty. • Note any time the traffic regulations of the country in which the device is operated. • Please ensure, that with the engine turned off the vehicle‘s battery does not discharge fully. The device is another electrical consumer which must be operated with the engine running, other-wise the vehicle‘s battery will be discharged and the vehicle can not be started. • Set the volume of the device only as loud, that you are still be able to hear warning signals (e.g. police sirens) and traffic noise inside the vehicle. • Operate the device as driver only if it‘s absolutely necessary and in the driving safety is not com- promised. The same stands for looking at the screen. If necessary, better park your vehicle at a safe and appropriate location. • The traffic rules of the EU prohibit to view moving pictures or movies while driving, if the screen of the device is installed within sight of the driver, as he may be distracted. View the screen as driver only for the navigation function, and then only briefly that you will not be distracted. Note at any time the local traffic regulations. In an accident, regress claims could be made by the car insurance company. • This device is not a substitute for your personal judgment or perception. All suggested routes from the navigation system should never be taken as a reason to disregard the local traffic rules. Your personal assessment of traffic or your knowledge of safe driving practices is paramount. Always match your driving with the current traffic situation. - Page 5 SAFETY INFORMATION • The device supports only DVD/CD standard disk size of diameter with 12 cm. Do not attempt to insert disks with a different size or any other object into the disk slot. Be sure to load only one disk at the same time. • Please use only the included original accessories. Ensure a sufficient mounting of the device by using the included installation accessories, as in the event of an accident enormous accelerations may occure. Poorly installed devices and equipment in accidents could represent a severe risk to the driver and the other passengers of the vehicle. • Note under all circumstances the regulations and advices of the vehicle manufacturer and do not make any modifications to the vehicle, which could interfere with safe driving. Please treat all parts of the device and the components of your vehicle always with caution. • Please avoid short circuits and make sure that no metal objects can get inside the device. Also make sure that all connections are properly connected and avoid the interchanging of the polarity of all connections. Complete the installation only while the the ignition is turned off. • In the event of a defect or malfunction, do not attempt to repair it by yourself or open the device, this is dangerous and could cause injury or damage to the equipment or vehicle. A repair should be done by trained and authorized personnel only. The device uses a Class 1 laser to read the disk. Eye contact with a laser is very dangerous to the human eye. • If you connect an external device, you should first read the instruction manual of the external device and make sure that it is compatible. Avoid connecting an incompatible external device. • If you install external applications onto the operating system of the device or operate files, make sure that they are „virus free“ and compatible with Windows CE 6. Otherwise there is a risk that the operating system no longer works properly and must be reinstalled. • Do not damage or scratch the screen with sharp objects. Do not operate the screen with hard objects. • Please refer the notes in chapter GENERAL NOTES on page 32. This symbol indicates important information and instructions in this manu- al, which serve to improve traffic safety and operability of the device.
-
Page 6: Basic Functions
(except for the AUX jack connector). The factory-installed screen in the middle of the dash is replaced with the touchscreen of the ESX device. The included DVD drive expands as a new component the functions and replaces (optional, not requi- red, see installation manual) the factory CD-ROM drive. -
Page 7: Main Menu
MAIN MENU After power on, the device displays the main menu. The informations of the factory sound system and trip computer are displayed here. The display of the individual functions such as radio, sound control and air condition are covered by factory-installed com- ponents and reflect the state factory. Touchscreen keypad to start the navigation of the ESX device. Touchscreen keypad to start the audio player of the ESX device. Touchscreen keypad to start the Bluetooth™ fuction of the ESX device. Touchscreen keypad to open the application menu. Basically, the device can operate several applications simultaneously. But if too many extensive applications running at the same time, it can slow the operation (not... -
Page 8: Navigation
Visit www.esxaudio.de/navi for more information. Note: If you have accidentally changed the path and want to use the original ESX iGO software, the path must always be „\Storage Card\Navione\Navione.exe“. The unit receives GPS satellite signals automatically. In poor weather conditions or for example while passing a tunnel, these signals may be disturbed. This could lead... -
Page 9: Audio Player
BASIC FUNCTIONS AUDIO PLAYER Open the audio player by tapping „Music“ in the main menu. The audio player supports audio for- mats like MP3, WMA and WAV. Refer to page 11 for CD Audio playback. 8. Progress bar of the currently playing 1. Current time. audio file. With the displacement of the knob 2. -
Page 10: Radio
The operation and function of the radio or the CD player via the controls on the multifunction steering wheel or the center console have not changed after installing the ESX device. If necessary, refer to the original manual of the radio. -
Page 11: Dvd (Dvd/Cd-Player)
BASIC FUNCTIONS (DVD/CD-Player) The DVD player supports the following formats: DVD, DVD-R/RW, DVD+R/RW, VCD, CD, CD-R/RW, MP3. Open the DVD application by tapping „DVD“ in the „App“ menu. or by tapping the „CD“ button on the original radio. Tap during DVD playback on any spot on the display to open the DVD menu. When you playback a CD or MP3-CD, the user interface is different. - Page 12 BASIC FUNCTIONS 1. Tap here to open the System Settings of the 5. Tap here for the information of the currently DVD player, where general settings, audio inserted media. Tap again to hide the settings, video settings and language settings information. can be specified. 6. Tap here to open the main menu 2. Tap here to switch through the audio tracks of the currently inserted media. of the DVD (if available). 7. Tap here to go to the previous page of 3. Tap here to switch through the subtitles the DVD menu. of the DVD (if available) NOTE: Some of the described features and settings 4. Tap here to open the title menu. are available only if the inserted media is suited accordingly.
-
Page 13: Bluetooth
BASIC FUNCTIONS BLUETOOTH™ Open the Bluetooth™ application by tapping „Bluetooth™“ in the main menu. PAIRING At first pair the devices, if necessary refer to the manual of your mobile phone. Open the „Settings“ menu on your mobile phone and open the Bluetooth settings. Turn on Bluetooth and then search for compatible devices. The Bluetooth name of the device will be displayed. Select your device from the device list in the phone and enter the PIN code 1234. Alternatively, you can also search your mobile phone under „Devices“ and connect to the device. Once you have connected your phone to the device, the pairing starts automatically as soon as the two devices are within range. Leave Bluetooth activated on the mobile phone. If a mobile phone has already been added to the list of Bluetooth devices, you can also manually pair the devices. The range for a satisfactory connection is about 10 m. DISCONNECT To disconnect the two Bluetooth Choose the mobile phone from the list and tap „Dis- devices, tap on „Devices“. connect“ or quit the Bluetooth connection on your phone. - Page 14 BASIC FUNCTIONS CONTACTS AND CALL HISTORY Once your mobile phone has been connected via Bluetooth to the device, the synchronization of your contacts and call history starts automatically. Tap on „Contacts“. Tap on a name to start a phone call. Tap on the white search field to search for Tap on „History“. a contact, by typing its name on the screen keyboard. Tap on „Missed“ to display the missed pho- Tap on „Received“ to display the already re- ne calls. ceived phone calls.
- Page 15 BASIC FUNCTIONS Tap on „Dialled“ to display the already tran- To synchronize your contacs and call history sacted phone calls. tap on „Sync. Now“. KEYPAD Tap on „Keypad“ to enter phone numbers manually. Then enter the desired number and then tap the green phone icon to start dialing. Tap the red phone icon to end the phone call. You can dial with the paired mobile phone, but this is not re- commended while driving and may be illegal in your country. An incoming call should not be accepted automatically by the device. If this occurs and the call is automatically answered, disconnect the phone and pair it again. AUDIO STREAMING As soon as a mobile phone is paired via Bluetooth with the device, it is possible to play audio files from the mobile phone via the device, if the mobile phone supports the Bluetooth A2DP audio streaming standard. The...
-
Page 16: Apps
BASIC FUNCTIONS APPS Open the application menu by tapping on „Apps“ in the main menu. The device offers a variety of applications that can be used as described below. Some of these func- tions require the appropriate accessories. 1. Tap here to open the Movie Menu. 6. Tap here to open the File Manager. -
Page 17: Linkpod (Optional)
BASIC FUNCTIONS LinkPod (optional) Make sure that the iPod™ is properly connected to the device via the supplied USB cable. This cable allows also the connec- tion of an iPhone™ to use its built-in audio playback mode. The battery is charged via the USB port when the device is switched on. With older iPod ™ models, it may occur, that they will not be detected, after the device was switched off. Disconnect and connect again the iPod ™ in this case. The user interface is modeled like the user interface of the iPod™. You get access to the iPod™ and its con- tents and playlists through the lower control panels. By tapping „MENU“ and „Media Library“ you can make the desired playback settings. Please avoid disconnecting the iPod/iPhone™ during operation. This could cause a sys- tem crash. -
Page 18: Tv (Optional)
BASIC FUNCTIONS (optional) The device offers the possibility to connect and operate a se- parate TV tuner (DVBT) for the reception of digital TV signals. Optionally, it is also possible to connect and operate an exter- nal digital radio receiver (DAB, DAB+). Depending on the model the touchscreen function is enabled. Please refer to the manual of the connected tuner. Files With the file manager, it is possible to manage and open com- puter specific file formats. The system supports the following file formats: Photo: BMP, JPEG, GIF, PNG Video: MPEG 1/2/4, WMV Audio: MP3, WMA, WAV, LST (Playback List) Tap once on a file to select it, tap twice on the selected file to open it. Tap on the desired storage location to dis- Tap on the desired file category to display play the available and compatible files. the other available and compatible files. -
Page 19: Internet (Optional)
BASIC FUNCTIONS Tap on „Option“ to perform file operations, such as deleting or copying files. With the copy function, it is possible to move files to another location or to another disk. Once you have open an image file, you can start a slideshow of all the pictures stored in the directory. Tap on the image and the playback options are displayed. Tap on „Info“ to view the memory information of each storage locations. Here you can view the file categories and the used disk space on the selected storage location. The usage is displayed in percent and in kilobytes/megabytes/ gigabytes. Internet (optional) With a separately available 3G USB stick and an activated SIM card (3G/UMTS), it is possible to use the „Internet“ feature. Open in the main menu Apps > Files > chose „Local“ and „Others“. There you will find the pre-installed file „DialUpSet- ting.exe“. Open the program and a virtual keayboard appears as well as the „Internet Settings“ window. Both windows can... -
Page 20: Options
BASIC FUNCTIONS Option Open this menu from the main menu by tapping on the „Menu“ and „Option“. Language settings Tap on „Skin“. Select the desired language. Tap on „Apply“. User interface Tap on „Skin“. Tap on the menu „Skins“ and select the desired design theme (skin). Tap on „Apply“. Operating system Under „System“ you find information about the system. Shell: Version number of the user interface OS: Version number of the operating system MCU: Version number of the CAN-BUS protocol Check under www.esxaudio.de/navi if an operating system update is available or ask your retail dealer. Then follow the installation instructions that come with the update. Do not turn off the car‘s ignition while updating process of the operating system. Don‘t run the update while driving. - Page 21 BASIC FUNCTIONS Display Tap on „Display“. Set the desired brightness level for the dis- play. The checkbox „CCD Camera“, enables the optional rear view camera function. As soon as reverse gear is engaged, the transmission of the video camera is automatically displayed on the screen. Calibration of the touchscreen operation If the touchscreen function is inaccurate you can recalibrate the display. Proceed as follows: Tap on „System“. Tap on „Calibration“. Tap with the included stylus marker on the „+“. Then the „+“ will be moved to another location, then tap again on the „+“ and repeat this process until the calibration is complete. Then confirm the calibration process.
- Page 22 BASIC FUNCTIONS Date/Time Tap on „Date/Time“. Select the desired time zone. Set the current date. Set the current time. Tap on the checkbox right to set on daylight Tap on „Apply“. saving time. Tap on the checkbox left to set the time for- mat to 12-hours (AM / PM). Please operate complex settings as a driver generally only if you have parked the car, otherwise the traffic safety is endangered. Otherwise you can not react in time, to avoid occuring danger situations.
-
Page 23: Audio
You can open the audio settings in the main menu by tapping on „Apps“ and „Audio“. Sound control / Volume The sound control through the buttons in the middle Here you can change the settings of bass/ center console has not changed after installing the mid/treble and master volume. However, ESX device. If necessary, refer to the user‘s manual please observe that thereof only the audio of the original radio. sources of the ESX device (such as naviga- tion, movies, iPod) are affected. We recom- mend the basic sound settings should be made directly on the original radio. -
Page 24: Custom Settings
CUSTOM SETTINGS Menu assignment You have the possibility to arrange the main menu or apps menu to your liking. To change the position of a control panel, press and hold for 5 seconds the regarding panel in the main or apps menu until the dashed lines are visible. Then hold and slide the control panel to the desired position within the menu. To occupy a control panel with a new function, touch the con- trol panel for 2-5 sec. to open the edit menu. Tap on „Delete“ to remove the panel. Tap on „Edit“ to select a new function or application or tap on „Default“ to restore the original factory settings. To occupy a control panel with a new function, touch the con- trol panel for 1-2 sec. to open the edit menu. Tap on „Delete“ to remove the panel. The possible applications may vary from the picture and are dependent from the device or the car features. You have also the possibility to link a control panel with any compatible software application (.EXE), which must be stored on the available storage locations. Tap on „Browse“ to select the desired application. Note: To exit the edit menu either press „OK“ or „Cancel.“ To exit the edit mode, tap on the screen (outside of the dashed lines) and the process is complete. -
Page 25: Wallpaper
CUSTOM SETTINGS Wallpaper You have the possibility to customize the background image to your liking. First, copy the desired wallpaper file to the microSD card, the USB stick or on the local hard drive. Tap on „Apps“. Tap on „Options“. Tap at „Wallpaper“ on „Browse“ Select a file by double click. Tap on „Apply“ to confirm your selection or Alternatively you can set an already opened „Delete“ below to remove the current file. -
Page 26: Start Logo
CUSTOM SETTINGS Bootlogo You have the possibility to customize the bootlogo (startup logo) to your liking. First, copy the desired file to the microSD card, the USB stick or on the local hard drive. Open the desired file in the file manager by Tap on „Options“ and select „Use as Startup double click. Logo“. NOTE: In this case a MicroSD card must be inserted in the device. - Page 27 CUSTOM SETTINGS...
-
Page 28: Troubleshooting
Display Inaccurate or delayed input of touch- The touch-screen is not properly Calibrate the touch screen screen function. calibrated. under Apps - Options - System. The device opens an application or is Wait until the process is completed. currently processing. Screen is black. The display is disabled. Tap on the screen. The ignition is off. Switch on the ignition. The original display of the vehicle is You are using the wrong software Check if you have installed the correct not working. version. Note that the OEM devices ESX device software. Check this via CD300 and CD400 need different Bluetooth identifier of ESX device. versions. The ESX device have been installed Check the correct wiring in the vehicle incorrectly. - refer to the installation guide. Note that the original display must still be connected to the vehicle. Sound There is no sound via the sound The connection or installation was Check all connections and replace a system of the vehicle hearable. not done correctly or one of the possibly damaged cable with a new cables is defective. one. One of the audio settings is incorrect... - Page 29 (iPod™/TV-Tuner etc.) The connected device is not working. The device is not properly connected Check all connections and replace a or the connection cable is defective. possibly damaged cable with a new one. The devices is not compatible. If necessary, make a software update or try another device. USB drive or microSD card is not Incorrect storage or data format. Format the storage with the MS-DOS recognized. file system (FAT32). The factory AUX connector of the This is not an error. The factory AUX Use the AV connection (RCA) of the vehicle no longer works. port can no longer be used. ESX device. Internet The Internet connection is not No proper reception for 3G devices in Continue until the 3G-Signal is availa- possible. the current location. ble again. The SIM card is defective or installed Check the SIM card or possibly insert incorrectly. a new one. The inserted SIM card is no longer Contact your contractor of the SIM active. card. The Browser is not starting. No compatible surfstick is inserted or Insert a compatible surfstick. faulty software/drivers are installed.
- Page 30 You are in an area with weak or no Continue driving until the GPS signal GPS signal, such as in a tunnel or on is available again. a remote road. The route guidance does not match The navigation software is not up Update the software or contact the with the current road or the map is to date. software supplier. is wrong. The navigation system does not show The navigation software considers Usually the navigation software the shortest way. many factors in determining a route, selects a route which is a good such as the condition of the roads, compromise and most immediate to traffic rules, one-way streets, major the goal. roads, etc. On the displayed map The display scale of the map is set too Change the ratio of the display scale, is nothing to see. large or too small. until the map is properly displayed. A brief loss of the GPS signal. Continue driving until the GPS signal is available again. Faulty maps. When you use the ESX iGO Software, contact the iGO Support e.g. via the „Naviextras Toolbox“...
- Page 31 TROUBLESHOOTING Problems Causes Remedy Bluetooth/Phone No connection or pairing of the Bluetooth function of the phone is not Enable Bluetooth function in the devices. enabled. phone settings. Bluetooth enabled but the phone is Enable „visible“ in the phone settings. not visible. The Bluetooth standard of the phone Use a compatible phone. is not compatible. Too many Bluetooth devices are Delete unused Bluetooth devices from registered in the device. the storage of the device. Bluetooth connection is too quiet The preset volume is set too low. Set the preset volume under Apps - Audio - Advanced - Bluetooth on a higher value. The volume on the phone is set too Set the volume of the phone higher. low. No Bluetooth audio function. The Bluetooth audio function is not Enable the function in the phone enabled. settings. The Bluetooth standard of the phone Use a compatible phone. is not compatible. Rear camera No transmission on the screen. The camera is not properly connec- Check the connections for any ted to the device.
-
Page 32: General Notes
GENERAL INFORMATION Care and Maintenance This device is equipped with high precision and sensitive technique and should always be treated with caution. Please note the following tips to avoid endangering the warranty and extend the life of the appliance. • Children under 12 should not operate the device. Keep the device and all accessories away from small children. • Keep the device and its components dry. The effects of water, liquid or moisture can cause damage to the vehicle, the device itself or injury. • Keep the device and its components away from excessive heat. High temperatures may shorten the life of appliance of the electrical components. • Keep the device and its components away from excessive cold. Extreme temperature changes and moisture inside the device may cause the breaking of certain components. • Do not to drop the device and avoid violent shocks or excessive shaking • Do not use strong chemical cleaners, solvents or water to clean the device. Use a slightly moistened cotton cloth with soft surface. • Replace a blown fuse only with a new one with the same values . However, before you replace a defective fuse, check at first what is the cause of the short circuit. Start with the power supply cable. If the fuse blows again, a malfunction consists inside the device. In this case you should contact your authorized dealer. Warranty information The warranty complies with the legal rules in your country. To maintain your warranty coverage upright, keep your original purchase receipt to prove the date of purchase. Any damage of the product, based on incorrect or improper use, accident, incorrect and improper installati- on, modification of the barcode, natural disaster or any non-appropriate interventions, repairing or alteration outside our factory or authorized service centers, and caused by other acts, which are unauthorized, because have been made in an incompetent manner, is excluded from the warranty. This warranty is limited only to de- fective parts and especifically excludes all incidental or consequential damages and those who are associated with. Damage to the operating system or loss of data, which were caused by operator error or by third party software or computer viruses, are also excluded from the guarantee. -
Page 33: Declaration Of Conformity
GENERAL INFORMATION Legal Notice • ESX or Audio Design GmbH are in no way affiliated with with the car manufacturer or any of its subsidiaries or affiliated companies connected to, or is acting on its behalf or with its authorization. • All registered product names, trade marks and brands are the property of their respective owners. • This owner‘s manual was made with the utmost care. • If you need to dispose the device, be aware that no electronic devices should be deposed in the household waste. Dispose the device in an appropriate recycling facility according to the local waste regulations. Consult if neccessary your local authority or dealer. • Technical changes and errors reserved. Due to the ongoing development of this device, it is possible that the information in this manual is incomplete or is not matching to the delivery status. Please visit periodically www.esxaudio.de/navi on the internet, to check if additional information and soft- ware updates are available. Customer service In general, the assembly and installation of the device should be made by a trained and technically skilled specialists. If you have any problems with operating the device, contact your specialist dealer or the Audio Design Service Department under Tel. +49 (0) 7253 - 94 65 95 or by E-Mail to navi@esxaudio.de. Declaration of Conformity Distributor: Audio Design Lautsprecher Vertriebs GmbH Am Breilingsweg 3, DE-76709 Kronau/Germany Hereby, Audio Design GmbH declares that the ESX VN709 OP-ASTRA device is in compliance with the essen- tial, fundamental requirements and other relevant provisions of the following directive: R&TTE Directive 1999/5/EG... - Page 34 NOTES...
