READ AND KEEP THIS MANUAL FOR FUTUR REFERENCE
This manual can be download on the manufacturer's website.
CERTIFIED BY THE
MEETS TEST
U.S. ENVIRONMENTAL
STANDARDS:
PROTECTION AGENCY
EPA
ULC 5627
UL 1482
EVOLUTION MANUAL
Soca Industries INC
11740, Philippe-Panneton
Montreal, Quebec, H1E 4G4
Tel: (514) 494-4522
Tel: 1-888-494-4522
Fax: (514) 494-4521
www.foyersnordica.com
info@industriessoca.com
Advertisement
Table of Contents
Related Manuals for Nordica natural warmth
Summary of Contents for Nordica natural warmth
- Page 1 EVOLUTION MANUAL READ AND KEEP THIS MANUAL FOR FUTUR REFERENCE This manual can be download on the manufacturer’s website. Soca Industries INC 11740, Philippe-Panneton Montreal, Quebec, H1E 4G4 Tel: (514) 494-4522 Tel: 1-888-494-4522 CERTIFIED BY THE MEETS TEST Fax: (514) 494-4521 U.S.
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ....................................3 STOVE DIMENSIONS ..................................3 WARNING ......................................4 SAFETY REQUIREMENTS ..................................4 EXPANSION NOISES ................................... 4 COMBUSTIBLE MATERIALS ................................4 CREOSOTE ......................................5 WOOD ....................................... 5 MANUFACTURED LOGS ..................................5 LIGHTING ......................................6 GLASS ........................................ 6 REPLACEMENT OF GLASS ................................... -
Page 3: Introduction
INTRODUCTION Please read carefully all the information given in this instruction manual and keep it for reference. It contains all the necessary information for installation and a sure and efficient use of the Evolution stove. Before installing the stove, consult the local authorities to obtain a construction permit as well as taking note of all lawful requirements in force. -
Page 4: Warning
WARNING It is prohibited to use gas, oil or other inflammable liquids to ignite the fire. Never use your stove with light fuels, such as draining oil, naphtha, gasoline or engine oil. The fire might get out of control and may cause a chimney fire. During combustion, the stove walls become very hot, do not touch them. -
Page 5: Creosote
CREOSOTE When wood burns slowly, it produces tar and other organic vapours, when associated with moisture, creosote forms. The creosote vapour condenses in a chimney pipe relatively cooled by a slow fire. It results in an accumulation of creosote inside the pipe. When burning creosote forma a blazing fire. -
Page 6: Lighting
LIGHTING Lighting a good sharp fire is necessary. Introduce into the outer firebox a small quantity of old ruffled papers and cover them with seasoned kindling. Open the damper keys (located at the center, behind the upper shutter) and light the fire. As soon as the fire is activated, add larger pieces of wood and close the door. -
Page 7: Replacement Of Glass
REPLACEMENT OF GLASS MANIPULATE THE GLASS WITH CAUTION TO AVOID CUTTING YOURSELF Directions to be followed: 1) Assembled welded door. 2) Glass corner’s junction. 3) Glass support (to prevent them from coming down). 4) Center glass. 5) Side glasses. 6) Glass Outline. 7) Door’s inside frame. -
Page 8: Door Maintenance
DOOR MAINTENANCE Before heating the stove for the first time it is necessary to remove all the labels and wash the door with soapy water (soft soap). Because, the slightest mark on the door will remain forever when heating your stove. Clean your stove regularly by removing the ashes. -
Page 9: Mobile Home Installation
MOBILE HOME INSTALLATION Evolution stoves model is approved for mobile homes. It is easy to install and must be equipped with an exterior air input system. 1. The apparatus must be fixed on the ground by making two holes in bottom of the stove. 2. -
Page 10: Chimney Minimum Height
CHIMNEY MINIMUM HEIGHT The chimney must extend at least 3’ (915 mm) past its point of contact with the roof and must be at least 2’ (610 mm) higher than any walls, roofs or buildings in a 10’ (3050 mm) radius. If the chimney exceeds the roof by 5’... -
Page 11: Chimney Fire
CHIMNEY FIRE Communicate with the municipal or provincial fire prevention services to obtain information on how to control chimney fires. If a chimney fire is declared, they know exactly the measures to take. If you suspect the existence of a chimney fire, it is recommended to: ... -
Page 12: Standard Installation
STANDARD INSTALLATION The Evolution stove should be placed so that there is an open space with any combustible surface as ceiling or walls, see table of releases. STANDARD INSTALLATION The releases can only be reduced by approval of the authorities. COMBUSTIBLE RELEASES Single sided pipe See illustrated figure... -
Page 13: Parts Description
PARTS DESCRIPTION DESCRIPTION PIÈCES Floor protector (Non combustible) 6’’ single or double pipe Certified Chimney 2100 Attic Radiation shield Decorative Ceiling Support Adaptor Roof Plaster Filling REFER TO PAGE 14-15 FLOOR PROTECTION If you have a concrete floor, you can install your stove directly on it. For the installation and conform use according to the manufacturer’s instruction and the local building codes, the unit must be installed on a 3/8’’... -
Page 14: Stove And Chimney Installation Diagram
STOVE AND CHIMNEY INSTALLATION DIAGRAM REFER TO DESCRIPTION ON PAGE 13... -
Page 15: Chimney Installation Diagram
CHIMNEY INSTALLATION DIAGRAM REFER TO DESCRIPTION ON PAGE 13... -
Page 16: 25 Years Limited Warranty
NOTE: Each complaint must be accompanied by proof of purchase. The Soca Indutries INC offers to the original purchaser of a Nordica wood stove, a limited warranty of twenty-five years from the date of purchase of the wood stove, against any defects in materials or workmanship. -
Page 17: Soca Industries Inc Warranty Card
SOCA INDUSTRIES INC WARRANTY CARD EVOLUTION Complete this form and return by mail PERSONAL INFORMATION First name : __________________________________ Last name : __________________________________ Address : ___________________________________________________________________________________ City : ________________________ Province : ____________________ Postal Code : __________________ INFORMATION RELATING TO THE PURCHASE Model : ____________________________________________________________________________________ Date of purchase : _____________________________ Serial number : _______________________________...
