DIAMOUND INSERT MANUAL
READ AND KEEP THIS MANUAL FOR FUTUR REFERENCE
This manual can be download on the manufacturer's website.
CERTIFIED BY THE
MEETS TEST
U.S. ENVIRONMENTAL
STANDARDS:
PROTECTION AGENCY
EPA
ULC 5627
UL 1482
Soca Industries INC
11740, Philippe-Panneton
Montreal, Quebec, H1E 4G4
Tel: (514) 494-4522
Tel: 1-888-494-4522
Fax: (514) 494-4521
www.foyersnordica.com
info@industriessoca.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DIAMOUND INSERT and is the answer not in the manual?

Questions and answers

André Vaudry
June 25, 2025

pour avoir le manuel de pieces. les 2 braquettes interieur. nordica diamant encastrable.

0

Related Manuals for Nordica DIAMOUND INSERT

Summary of Contents for Nordica DIAMOUND INSERT

  • Page 1 DIAMOUND INSERT MANUAL READ AND KEEP THIS MANUAL FOR FUTUR REFERENCE This manual can be download on the manufacturer’s website. Soca Industries INC 11740, Philippe-Panneton Montreal, Quebec, H1E 4G4 Tel: (514) 494-4522 Tel: 1-888-494-4522 CERTIFIED BY THE MEETS TEST Fax: (514) 494-4521 U.S.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ....................................3 DIMENSION OF WOOD STOVE ................................3 WARNING ......................................3 SECURITY REQUIREMENTS ................................. 4 EXPANSION NOISES ................................... 4 COMBUSTIBLE MATERIALS ................................4 OVERHEATING ....................................4 CREOSOTE ......................................5 WOOD ....................................... 5 MANUFACTURED LOGS ..................................5 LIGHTING A FIRE ....................................

  • Page 3: Introduction

    INTRODUCTION Take time to attentively read all continuous information in this instruction manual and keep it for consultation it contains all the necessary information to an installation and an efficient use of the Diamond wood Insert. Before installing the wood Insert consult the local authorities to obtain a construction permit. Take note of all the lawful requirements into force.

  • Page 4: Security Requirements

    SECURITY REQUIREMENTS A. Keep the children away from the stove when it is in use. B. This stove was designed to burn wood in reasonable quantity. Avoid large fires, which could damage the stove. Do not burn wet or green wood, or wood that contains salt, plywood or melamine. C.

  • Page 5: Creosote

    CREOSOTE When wood burns slowly, it produces tar and other organic vapours when, associated with moisture, forms creosote. The creosote vapour condenses in a chimney flue relatively cooled by a slow fire. Its results in an accumulation from creosote inside the pipe. When burning, the creosote forms an extremely blazing hot fire. It is preferable to make small brisk fires rather than large smouldering fires.

  • Page 6: Lighting A Fire

    LIGHTING A FIRE Lighting, a good sharp fire is necessary. Introduce into the outer firebox a small quantity of old ruffled papers and cover them with seasoned kindling. Open the damper keys (located at the center, behind the higher shutter) and light fire. As soon as fire is well taken, add pieces of wood a little larger and close the door.

  • Page 7: Glass Replacement

    GLASS REPLACEMENT Directions to be followed: MANIPULATE THE GLASS WITH CAUTION TO AVOID CUTTING YOURSELF 1) Cast iron door 2) Seal bead 5/8 3) Ceramic glass 11 ⅜ x 11 ⅜ et 11 ⅜ x 5. (Thickness 5mm) 4) Support Bracket 5 Nuts.

  • Page 8: Refractory Bricks Replacement

    REFRACTORY BRICKS REPLACEMENT Do not use the stove when there is a missing or broken brick. If a refractory brick is broken replace it by a similar one. You can purchase replacement refractory bricks at your retailer or at Soca Industries INC. REFRACTORY BRICK DOOR MAINTENANCE Before heating the stove for the first time, it is necessary to remove all the labels and wash the door with soapy water...

  • Page 9: Maintenance Of Plated Surfaces

    MAINTENANCE OF PLATED SURFACES Never clean plated surfaces with abrasive cleanser. Plated surfaces of your stove can easily be scratched. To retain their original finish only use a soft damp during maintenance. CHIMNEY MAINTENANCE It is important to inspect the chimney or clean it periodically. It is necessary to clean the chimney after an accumulation of 3 mm creosote.

  • Page 10: Chimney

    CHIMNEY The stove must not be connected to any other distribution system: such as an incinerator, heating system or ventilation system. The Diamond requires a stainless liner that must be placed from the nozzle of the stove to the top of the chimney. The liner facilitates the sweeping and maintenance, since the sweeping can be done from the top of the chimney and that the deposits can be removed from inside the insert.

  • Page 11: Fresh Air Input & Return Of Smoke

    FRESH AIR INPUT & RETURN OF SMOKE Diamond stove well installed should not produce any smoke in the house. If the stove produces smoke, it will probably be for one of the following reasons : 1. The external installation of the chimney is defective or incorrect, engaging in an air return problem and, consequently difficult lightings.

  • Page 12: Chimney Fire

    CHIMNEY FIRE Communicate with the municipal or provincial fire prevention services to obtain information on how to control chimney fires. If a chimney fire is declared, they know exactly the measures to take. If you suspect the existence of a chimney fire, it is recommended to: ...

  • Page 13: Clearance For Combustible Materials

    CLEARANCE FOR COMBUSTIBLE MATERIALS ATTENTION: No combustible material must be in the space directly over the fireplace, except the framing which supports the shelf facing. This space must be left empty for 56” (1200mm) starting at the base of the stove. Sidewall 736 mm (29’’) Shelf height...

  • Page 14: Chimney Lining System Installation Diagram

    CHIMNEY LINING SYSTEM INSTALLATION DIAGRAM WARNING: do not remove bricks and mortar from the existing fireplace. The space between the Diamond Insert and the masonry fireplace must be closed. The masonry fireplace must meet the minimum code requirement for a safe installation. Contact your local Building Inspector for requirement in your area.

  • Page 15: Full Flue Liner Method

    FULL FLUE LINER METHOD The Insert must be installed as per the requirements of your local inspection authority. In Canada a full flue liner is required. A full flue liner is where a stainless steel rigid or flexible liner pipe is routed from the insert outlet collar to the top of the chimney.

  • Page 16: 25 Years Limited Warranty

    NOTE: Each complaint must be accompanied by proof of purchase. The Soca Indutries INC offers to the original purchaser of a Nordica wood stove, a limited warranty of twenty-five years from the date of purchase of the wood stove, against any defects in materials or workmanship.

  • Page 17: Soca Industries Inc Warranty Card

    SOCA INDUSTRIES INC WARRANTY CARD DIAMOND INSERT Complete this form and return by mail PERSONAL INFORMATION First name : __________________________________ Last name : __________________________________ Address : ___________________________________________________________________________________ City : ________________________ Province : ____________________ Postal Code : __________________ INFORMATION RELATING TO THE PURCHASE Model : ____________________________________________________________________________________ Date of purchase : _____________________________ Serial number : _______________________________...
