User Manual
Hikvision Technical Manual
DS-7108HI-S Series Net DVR
Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for HIKVISION DS-7108HI-S Series
Summary of Contents for HIKVISION DS-7108HI-S Series
- Page 1 Hikvision Technical Manual DS-7108HI-S Series Net DVR Technical Manual ©2006 – 2010 by HIKVISION. All rights reserved.
- Page 2 HIKVISION and then only on the condition that this notice is included in any such reproduction. No information as to the contents or subject...
- Page 3 Hikvision Technical Manual Contents 1. Overview 2. Model Description 3. Features 4. Specifications ©2006 – 2010 by HIKVISION. All rights reserved.
- Page 4 Hikvision Technical Manual 1. Overview DS-7108HI-S series network digital video recorder is a new generation digital surveillance product applies Linux OS and the latest TI DaVinci DSP, along with the most advanced technology in the information industry, such as video and audio encoding/decoding, hard disk recording and TCP/IP.
-
Page 5: Model Description
HDDs supported. 1-ch composited video output and 1-ch spot video output. Ch1-8 Loop Out interface.1 RS-232 Port. Note: 1. The default DVRs are without HDD. 2. A factory recommended HDD should be used for this device. ©2006 – 2010 by HIKVISION. All rights reserved. - Page 6 Support video signal loss alert. Support play forward, backward, pause, frame-by-frame, etc User-defined preview layout. Support one playback channel. Playback by files or by time. Display local recording status. ©2006 – 2010 by HIKVISION. All rights reserved.
- Page 7 View and search log Others Support network voice talk. IR remote control Multi-level user management. Automatically recovery from abnormal conditions. Network SDK and client demo source code available ©2006 – 2010 by HIKVISION. All rights reserved.
-
Page 8: Specifications
1 USB 2.0 interface, support USB mouse, support USB disk, USB HDD, USB CD/DVD-R/W 1VGA resolution: 800*600/60Hz VGA Interface 800*600/75Hz 1024*768/60Hz Alarm in 16 channels Alarm out 4 channels Power supply DC 12V Power ≤30W(without HDDs) consumption Working -10° C~+55° C ©2006 – 2010 by HIKVISION. All rights reserved. - Page 9 Hikvision Technical Manual temperature Working humidity 10%~90% Size 445mm(W)*290mm(D)*44mm(H) Weight ≤3.28Kg(without HDDs) PAL: 176×144(QCIF), 352×288(CIF), 704×288(2CIF), 528×384(DCIF), 704×576(4CIF); NTSC: 176×120(QCIF), 352×240(CIF), 704×240(2CIF), 528×320(DCIF), 704×480(4CIF). ©2006 – 2010 by HIKVISION. All rights reserved.
