Summary of Contents for All-Power apc4200
-
Page 1: Table Of Contents
Air Compressor Table of Contents Page Topic Safety Guidelines-Definitions Hazard Warnings Air Compressor Precautions Basic Air Compressor Components Assembling the Air Compressor Compressor Controls Electrical Power Requirements Breaking In The Pump Operating Instructions Maintenance Storage Service Troubleshooting Glossary Terms Limited Warranty Parts List... -
Page 2: Air Compressor
This Manual Before Operating. Failure To Comply With Instructions In This Manual Could Result In Personal Injury, Property Damage, And / Or Voiding Of Your Warranty. All-Power America Will Not Be Liable For Any Damage Because Of Failure To Follow These Instructions. Air Compressor Prior to installation and usage, thoroughly inspect air compressor for damages. -
Page 8: Precautions
Owner’s Manual Owner’s Manual Compressor (cont’d) Basic Air Compressor Components Oil-less aircompressor are factory lubricated for life and do not require any oil. The basic components of the air compressor the electric motor, pump, pressure switch, and tank. The electric motor (see A) powers the pump. -
Page 9: Compressor Controls
Owner’s Manual Owner’s Manual Compressor (cont’d) Compressor (cont’d) COMPRESSOR CONTROLS Assembling the Air Compressor Unpack the air compressor. Inspect the unit for damage. If the unit has been damaged Power Switch: This switch turns the compressor power ON and OFF. in transit, contact the carrier and complete a damage claim. -
Page 10: Electrical Power Requirements
Owner’s Manual Owner’s Manual Compressor (cont’d) Compressor (cont’d) ELECTRICAL POWER REQUIREMENTS (cont’d) Electrical Power Requirements Extension Cord Electrical Wiring Use the chart on the right for LENGTH OF Refer to the air compressor’s serial label for the unit’s voltage and amperage the proper extension cord length. -
Page 11: Breaking In The Pump
Owner’s Manual Compressor (cont’d) BREAKING IN THE PUMP 1.Turn the switch to the OFF position. 2. Open the petcock. Turn counterclockwise (loosen). 3. Plug in the power switch to the ON position. 4. The compressor will start. ALLOW THE COMPRESSOR TO RUN FOR 15 MINUTES, TO BREAK IN THE INTERNAL PARTS. -
Page 12: Maintenance
Owner’s Manual Owner’s Manual Compressor (cont’d) Compressor (cont’d) MAINTENANCE MAINTENANCE (cont’d) Relieve the air pressure in the system and open the petcock on the WARNING! TO AVOID PERSONAL INJURY, ALWAYS SHUT bottom of the tank to drain. OFF AND UNPLUG THE COMPRESSOR AND RELIEVE ALL AIR PRESSURE FROM THE SYSTEM BEFORE PERFORMING ANY SERVICE ON THE AIR WARNING! CONDENSATION WILL ACCUMULATE IN THE TANK. -
Page 14: Troubleshooting
Owner’s Manual Owner’s Manual Compressor (cont’d) Compressor (cont’d) TROUBLE SHOOTING (cont’d) TROUBLE SHOOTING (cont’d) Overheating Motor will not run (cont’d) • Poor ventilation • Fuse blown or circuit breaker tripped Relocate compressor to an area with cool, dry and well-circulated air. Replace blown fuse or reset circuit breaker. -
Page 15: Limited Warranty
Owner’s Manual LIMITED WARRANTY All-Power Amercia warrants to the original purchaser who uses the product in a consumer application (personal, residential or household usage) that all products covered under this warranty are free from defects in material and workmanship for one year from the date of purchase. -
Page 16: Parts List
Expendable parts or accessories supplied with the product which are expected to become inoperative or unusable after a reasonable period of use. Merchandise sold by All-Power Amercia which has been manufactured by and identified as the product of another company, such as gasoline engines. The product manufacturer's warranty, if any, will apply.
