Page 1
APC4035 Owner’s Manual 25 Gallon Vertical AIR COMPRESSOR Please read and save these instructions. HAVE QUESTIONS OR NEED SERVICE DO NOT RETURN TO STORE! 888-896-6881 www.allpoweramerica.com...
SPECIFICATIONS TABLE Maximum Air Pressure 125 PSI Air Tank Capacity 25 Gallons 6.2 CFM at 40 PSI Air Flow Capacity 5.2 CFM at 90 PSI 2 HP Working / 3 HP Peak Motor 120 Volt / 60 Hz / 12 A / 1-Phase Required Circuit Minimum 20 Amp *Dedicated Pump Stage...
Page 3
DO NOT OVERREACH. Keep proper footing and balance at all times to prevent tripping, falling, back injury, etcetera. INDUSTRIAL APPLICATIONS MUST FOLLOW OSHA REQUIREMENTS. STAY ALERT. Watch what you are doing at all times. Use common sense. Do not use this product when you are tired or distracted from the job at hand. CHECK FOR DAMAGED PARTS.
SPECIFIC PRODUCT WARNINGS AND PRECAUTIONS WARNING: Make sure to fill the Air Compressor with a premium quality, 30-weight, non-detergent compressor oil before each use. Running the Air Com- pressor with no oil or low oil will cause damage to the equipment. Note: The oil reservoir has an optimal capacity of 30 ounces of oil.
Page 5
TO EXTEND THE LIFE OF YOUR AIR TOOLS AND EQUIPMENT, it is recom- mended to install an oiler and water filter in series with the Air Output Line of the Air Compressor. UNPACKING When unpacking, check to make sure all the parts shown on the Parts Lists on pages 9, and 10 are included.
Page 6
If necessary, add a premium quality, 30-weight, non-detergent compressor oil into the Oil Fill Hole until the level of oil reaches the maximum level as indicated on the Oil Window (20B). The optimal capacity of the oil reservoir is 30 ounces. Do not overfill.
Page 7
NOTE: With the Air Compressor turned on, the operation is automatic and under the control of the automatic switches inside the box under the Power Switch (1A). NEVER open the power switch box or adjust the controls within. To Adjust The Air Output To The Pneumatic Tool: NOTE: When adjusting the air pressure being forwarded to the pneumatic tool, you will need to compare the pressure readings of both the Tank Pressure Gauge (3A) and the Tool Pressure Gauge (4A).
Reference: Overload Switch (35B) The overload breaker will trip if an over-current condition is sensed, stopping the motor. If this occurs, shut off the pressure switch and wait at least 5 minutes. Release the air pressure in the tank to ease restarting. Then press the breaker button to reset it, and turn on the pressure switch.
Page 9
PARTS LIST A / ASSEMBLY DIAGRAM A Part Description Qty. Part Description Qty. ON/OFF Power Switch 11A Quick Release Coupler Tool Pressure Adjuster 12A Rubber Wheel with Bolt Tank Pressure Gauge 13A Washer Tool Pressure Gauge 14A Nut Pressure Release Valve 15A Fitting Air Flow Valve 16A Oil Drain Plug with Gasket...
PARTS LIST B / ASSEMBLY DIAGRAM B Part Description Qty. Part Description Qty. Bolt Gasket Cylinder Case Oil Window Gasket Crankshaft Bolt Valve Seat Crankshaft Gasket Crankshaft Case Cylinder 24B* Stator Compression Ring 25B* Bearing Oil Scraping Ring 26B* Armature Piston Start Capacitor, 70 mF±5% bMK Gasket...
LIMITED WARRANTY All-Power warrants to the original purchaser who uses the product in a consumer application (personal, residential or household usage) that all products covered under this warranty are free from defects in material and workmanship for one year from the date of purchase.
Page 12
Expendable parts or accessories supplied with the product which are expected to become inoperative or unusable after a reasonable period of use. Merchandise sold by All-Power which has been manufactured by and identified as the product of another company, such as gasoline engines. The product manufacturer's warranty, if any, will apply.
