- Page 1 ATTENTION Please read your owner’s manual before driving your scooter. Owner’s Manual 888SL Page - 1 -...
- Page 2 Page -2-...
-
Page 3: Table Of Contents
CONTENTS INTRODUCTION .......................4 FEATURE GUIDE .....................4 SAFETY ADVICE ......................5 EMI Warning ......................7 ADJUSTMENT ......................8 SCOOTER TILLER CONTROLS ................10 FREE WHEEL OPERATION ..................11 STARTING TO DRIVE YOUR SCOOTER ..............12 EXTRA GUIDELINES IN THE CONTROL OF YOUR SCOOTER ......13 BATTERIES AND BATTERY CHARGER ..............13 MAINTENANCE ......................15 TROUBLE SHOOTING GUIDE ................16 TECHNICAL SPECIFICATIONS ................17... -
Page 4: Introduction
Congratulations on your purchase of the Shoprider scooter. This scooter incorporates the latest ® innovative designs patented and only available on a Shoprider scooter. This scooter can be used ® in confined spaces both indoors and outdoors. Direct drive transaxles and electromagnetic brakes give a safe and efficient ride. -
Page 5: Safety Advice
SAFETY ADVICE • Do not carry passengers. • This mobility Product is intended to assist you. For your own safety, please read the Owner’s Manual before using the Scooter. If in any doubt, contact your supplier directly for advice. • Do not exceed inclines over 9 degrees (15% grade). •... - Page 6 or dampness could cause the scooter to electrically malfunction and prematurely rust. • Do not lean against or pull forward on the tiller while mounting or dismounting the scooter. Other- wise, injury may occur. • Do not operate the unit or turn the key on while charging. •...
-
Page 7: Emi Warning
EMI Warning Shoprider scooters may be susceptible to electromagnetic interference (EMI), which is a kind of ® interfering electromagnetic energy (EM) emitted from sources such as radio stations, TV stations, amateur radio (HAM) transmitters, two-way radio, and cellular phones. The interference (from radio wave sources) can cause the scooter to release its brakes, move by itself, or move in unintended directions. -
Page 8: Adjustment
4. Be aware that adding accessories or components, or modifying the scooter may make it more susceptible to EMI. NOTE! There is no easy way to evaluate the overall immunity of the scooter. 5. Report all incidents of unintended movement or braking to your Shoprider dealer, and note ®... - Page 9 Seat Slide & Swivel Adjustment. Pulling up on the seat slide lever allows the seat position to be adjusted forward or backward. Release the lever and he seat will lock in that position. Under the right side of the seat there is a spring loaded red lever. Pulling up on he lever allows the seat to swivel, when released the seat Adjustable will lock into one of 3 positions.
-
Page 10: Scooter Tiller Controls
SCOOTER TILLER CONTROLS (1 & 2) Speed Controls The speed control allows you to set a speed between 1 (minimum) and 10 (maximum). Turn the dial knob counter-clockwise to “minimum” to decrease speed, and clockwise towards “maximum” to increase your speed. The “High / Low” switch for extra speed. Please use extra cau- tion when using the scooter in “High”... -
Page 11: Free Wheel Operation
(5) Horn A yellow button operates the horn. (6) Thumb/Finger Lever Controls The left thumb/finger lever controls the reverse and the right thumb/finger lever controls the forward motion. The amount of pressure applied to each lever will determine the speed the scooter travels at. -
Page 12: Starting To Drive Your Scooter
Anti-tip wheels The anti-tip wheels are located at the rear of the scooter frame. The scooter should not be used unless the anti-tipping wheels are in place. The original manufacturer and the importer of the scooter is not responsible for damage or injury incurred due to improper or misuse of the scooter. -
Page 13: Extra Guidelines In The Control Of Your Scooter
Any scooter used outside these parameters may be unsafe and or cause future prob- lems with the electrical systems BATTERIES AND BATTERY CHARGER The Shoprider scooter is supplied with maintenance free, sealed lead acid batteries. Battery per- ® formance can be affected by temperature, terrain, condition of battery, type of battery charger, the weight of the user, wind speed, etc. - Page 14 (2-pin). Please refer to the LED indicator description based on charging status of the charger’s manual. Once the batteries are completely charged, unplug the A/C cord from the wall then unplug the 3-pin lead from the tiller. WARNING: Only use the original Shoprider approved charger! ®...
-
Page 15: Maintenance
MAINTENANCE Lubrication At six-month intervals you should lubricate the following parts with a light oil or similar lubricant: • Seat pivot post. • Seat release lever pinion. • Wheel bearings. • Axle of scooter. CAUTION – DO NOT USE WD40 TO LUBRICATE PARTS!! DO NOT LUBRICATE TRANSAXLE/GEAR BOX!! In the event of any difficulties please consult your dealer. -
Page 16: Trouble Shooting Guide
Please consult your dealer if your scooter does not run after checking these points. Please consult your selling Shoprider provider if your scooter does not run after checking these points. -
Page 17: Technical Specifications
TECHNICAL SPECIFICATIONS Model Name 888SL 1280(50) x 600(24) x Overall Dimensions: L x W x H mm(in) 1100~1210(43.3~48) Front Pneumatic Tire Diameter pcs x in 2 x 11” Rear Pneumatic Tire Diameter pcs x in 2 x 11” Suggested User Weight... - Page 18 Page -18-...
-
Page 19: Disclaimer
This scooter is not intended for use by people with physical limitations that may prevent a normal and safe use of the scooter. SHOPRIDER® disclaims all liability for any injury caused to another or due to personal misuse of its products. - Page 20 EU.- - SHOPRIDER 5, rue bommel ZAE Robert Steichen L-4970 Hautcharage LUXEMBOURG www.shoprider.eu.com Page -20-...
