If you wish to save energy when using your air conditioner, select the Energy saving mode with the button. Sleep button. The sleep timer can be used when you are cooling or heating your room to switch the air conditioner off automatically after a period of six hours. Samsung Electronics...
Page 7
After setting On Timer or Off Timer, press the button to set it completely. And press the button again to cancel On Timer or Off Timer set. Digital On/Off button. If you want to turn off the display during operation press the button. Samsung Electronics...
Page 8
When the temperature has been dropped function to detect an outdoor overload by by total of 2°C, that temperature is main- the sensor of an indoor heat exchanger tained. and to turn the outdoor fan or the compressor ON/OFF for safety. Samsung Electronics...
Page 9
You can set the period of time from 30 minutes to 24 hours. 11. GENERATING ANION : The air conditioner can generate anion with an ionizer in the indoor unit. Samsung Electronics...
Page 10
2-2 Replace PCB Model option 2-2-1 Replace PCB model option Remove power cord Replace the PCB module Check the connection and plug in Replace another PCB Does all display lamp blink? Refer to set up the Model option(2-2-2) Samsung Electronics...
Page 11
$ When pressing the button appear on the display, select one of them. % When pressing the button appear on the display, select one of them. ^ When pressing the button appear on the display, select one of them. Samsung Electronics...
Page 12
If all lamps of indoor unit are flickering, Plug out and plug in again and pressing ON/OFF key to retry. If the unit is not working properly or all lamps are continuously flickering after setting the option code, see if the correct option code is set up for it’s model. Samsung Electronics...
10) In order to disassemble the panel grille, press, in order, the left, center, and right of the upper side of the panel grille with the palm of the hand to remove the hook. And then disassemble the panel grille. Samsung Electronics...
Page 15
2) Loosen 2 fixing earth screws of right side. 3) Separate the connection pipe. 4) Separate the holder pipe at the rear side. 5) Loosen 3 fixing screws of right and left side. 6) Separate the heat exchanger from the indoor unit. Samsung Electronics...
Page 16
Cross Fan 2) Loosen 2 fixing screws and separate the motor holder. 3) Loosen 1 fixing screw of fan motor. (M3 wrench) 4) Separate the fan motor from the fan. 5) Separate the fan from the left holder bearing. Samsung Electronics...
Page 17
3-2 Outdoor Unit AQ12PGGE / SH12ZPG / SH12ZPGA / SH09ZPG / SH09ZPGA / SH07ZPG / SH07ZPGA Parts Procedure Remark Common Work 1) Loosen 2 fixing screws and separate the cover valve. 2) Separate the connection wire from the terminal block.
Page 18
1) Do "1","2","3", above. 2) Open the terminal cover of compressor and unscrew the connection terminal. 3) Disassemble the inlet and outlet pipe of compressor by welding. 4) Loosen 3 fixing bolts of the lower part. 5) Separate the compressor. Samsung Electronics...
Page 19
3) Separate the connection wire from the terminal block. 4) Loosen 6 fixing screws and separate the cabi front. 5) Loosen 1 fixing screw of assy E-part. 6) Loosen 12 fixing screws and separate the cabi side. Samsung Electronics...
Page 20
1) Do “1”, “2”, “3”, above. Compressor 2) Open the terminal cover of compressor and unscrew the connection terminal. 3) Disassemble the inlet and outlet pipe of compressor by welding. 4) Loosen 3 bolts of the lower part. 5) Separate the compressor. Samsung Electronics...
Page 21
3) Separate the connection wire from the terminal block. 4) Loosen 13 fixing screws and separate the cabi front. 5) Loosen 1 fixing screw of Ass'y E-part. 6) Loosen 4 fixing screws and separate the cabi side. Samsung Electronics...
Page 22
1) Do “1”,“2”,“3”, above. 2) Open the terminal cover of compressor and unscrew the connection terminal. 3) Disassemble the inlet and outlet pipe of compressor by welding. 4) Loosen 3 bolts of the lower part. 5) Separate the compressor. Samsung Electronics...
4. Exploded Views and Parts List 4-1 Indoor Unit 12-4 12-6 12-1 7-1 7-9 12-3 7-10 12-2 12-5 1-1-2 1-1-3 1-1-4 1-1-1 1-1-5 1-1-6 1-1-7 You can search for the updated part code number through the ITSELF. URL : http://itself.sec.samsung.co.kr Samsung Electronics...
Page 25
Exploded Views and Parts List Indoor Unit Parts List Q’TY AQ09P8GE AQ07P8GE Code No. Description Specification Remark AQ12PGGE SH12ZPG AQ09PBGE AQ07PBGE AQ12PBGE SH12ZPGA SH09ZPG SH07ZPG SH09ZPGA SH07ZPGA DB92-00383A ASSY PANEL FRONT TOTAL ASSY DB92-00414A ASSY PANEL FRONT TOTAL ASSY DB92-00392A...
Page 26
Exploded Views and Parts List Q’TY AQ09P8GE AQ07P8GE Code No. Description Specification Remark AQ12PGGE SH12ZPG AQ09PBGE AQ07PBGE AQ12PBGE SH12ZPGA SH09ZPG SH07ZPG SH09ZPGA SH07ZPGA 7-10 DB93-01383D ASSY CONNECTOR WIRE ION DB93-01451A ASSY CONNECTOR WIRE ION DB67-60030A SPRING SENSOR DB70-00276A HANGER PLATE...
Page 51
C2 : COMP CAPACITOR O.L.P : OVER LOAD PROTECTOR Code No : DB68-02773A 7-2-2 STEEL OUTDOOR UNIT DIAGRAM-OUTDOOR C1 : MOTOR CAPACITOR FM : FAN MOTOR C2 : COMP CAPACITOR O.L.P : OVER LOAD PROTECTOR Code No : DB98-11762A Samsung Electronics...
