Dualtools PS7000 Owner's Manual page 20

Polisher/sander
Table of Contents

Advertisement

WARNING!
When servicing, use only identical replacement parts. Use of other parts
may create a hazard or cause product damage.
Contact customer service at
obtain replacement parts from an authorized service facility.
No
Description
1
auxilary handle
2
outer pad
3
outer pad ass'y
4
inner pad
5
inner ass'y
6
plain washer 4
7
screw M4x16
8
spring washer 4
9
screw M4x10
10
plain washer 3
11
circlip for shaft 10
12
tapping screw ST2.9x9.5
13
tapping screw ST4.2x16
14
circlip for hole 21
15
ball bearing 61801-2Z
16
inner driver
17
spring washer 4
18
plain washer 4
19
packing gland
20
ball bearing 6005-2Z
21
gear A
22
ball bearing 6001-2Z
23
spindle
24
washer
25
gear B
26
cross recessed countersunk
head screw M4x6
27
bearing clamp
28
ball bearing 608-2RS
29
gear case
30
tapping screw ST4.2x32
PARTS LIST
1‑888‑760‑4405
Qty
1
1
1
1
1
3
4
3
3
2
1
2
2
1
1
1
4
4
1
1
1
1
1
2
1
3
1
1
1
4
19
for information on how to
No
Description
31
cap
32
pinion
33
ball bearing 6000-2Z
34
O-ring 25*2
35
Intermediate cover
36
armature
37
ball bearing 607-2Z
38
bearing bush
39
fan guide
40
tapping screw ST4.2x70
41
stator
43
stator lead wire and
contact ring ass'y
44
housing
45
name plate
46
brush holder
47
carbon brush
48
brush cap
49
screw M3x14 (levorotation)
50
variable switch
51
switch button cap
52
switch
53
tapping screw ST4.2x16
54
cord binder
55
right handle
56
power cord and plug
57
cord armor
58
connector
59
left handle
60
magnet ring
61
magnet ring sensor
module
Qty
1
1
1
1
1
1
1
1
1
2
1
2
1
1
2
2
2
1
1
1
1
6
1
1
1
1
1
1
1
1
