SVSi N3000 SERIES Quick Start

N3000 SERIES QUICK START
Congratulations on the purchase of your N3000 series products. An SVSi
Networked AV system comprises video and/or audio encoders, decoders, and
other network accessories including recording solutions, multi-window processing,
audio only end points, and system controllers. The system allows you to distribute
HD Video, Audio and Control across a gigabit Ethernet network. Options are
available for recording, playback, windowing, and wall processing.
Network Bandwidth per video stream = 0.032-10Mbs (user-selectable)
Analog or digital video is input through the DVI-I connector on the N3000 encoder
and converted to network packets for output through the RJ-45 connector. Audio
can be input as embedded digital audio through the DVI-I connector or as
balanced analog audio through the 5-pin phoenix connectors. Both encoder and
decoder can be powered either +12V externally with optional wall-wart or by
power-over-Ethernet (PoE).
The N3000 series decoder accepts the network packets and reconstitutes
synchronized video and audio for display through its DVI-D port. Digital only video
is output by the decoder. The streaming h.264 output of the N3000 can also be
decoded in software with the free VLC Player application available from
http://www.videolan.org/vlc/index.html.
IR and Serial commands can be transmitted by either encoder or decoder using
SVSi's free NetLite configuration software, SVSi's N8000-series controller, or
using third-party controllers. IR and serial ports are not pass-through and must use
a central controller to direct commands to each device.
Optional accessories:
N9312 12V wall-wart
N6123 dual-channel networked video recorder
N3510 4x1 windowing processor (available Q4-2013)
N3121 Encoder Rear*
N3221 Decoder Rear*
*Note: models may not have all
connectors and options
