QUICK START GUIDE
Ransomes MP653 Ride on Rotary Mower With ROPS
STARTING THE ENGINE
SEAT ADJUSTMENT
CONTROLS
DRIVING
MOWING
VISUAL DISPLAY
Refer To The Safety, Operation And Maintenance Manual For Full Operating Instructions.
GB
RJL 100 May 2015
United
Kingdom
25097G-GB (rev.0)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MP653 Ride and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ransomes MP653 Ride

Summary of Contents for Ransomes MP653 Ride

  • Page 1 QUICK START GUIDE Ransomes MP653 Ride on Rotary Mower With ROPS STARTING THE ENGINE SEAT ADJUSTMENT CONTROLS DRIVING MOWING VISUAL DISPLAY Refer To The Safety, Operation And Maintenance Manual For Full Operating Instructions. RJL 100 May 2015 United Kingdom 25097G-GB (rev.0)
  • Page 2 QUICK START GUIDE Ransomes Jacobsen Limited reserves the right to make design changes without obligation to make these changes on units previously sold and the information contained in this manual is subject to change without notice. © 2015 , Ransomes Jacobsen Limited. All Rights Reserved...

  • Page 3: Starting The Engine

    QUICK START GUIDE STARTING THE ENGINE BEFORE YOU OPERATE FOR THE FIRST TIME • Check and adjust tyre pressure, if necessary, see Safety, Operation and Maintenance manual. • If necessary, add diesel fuel to tank. • Check engine oil and if necessary fill. •...

  • Page 4: Seat Adjustment

    QUICK START GUIDE SEAT ADJUSTMENT SEAT (GRAMMER MSG85) C. WEIGHT ADJUSTMENT To Adjust Adjustments to the seat can be made for leg The position of the operator weight adjust reach, backrest angle and operator weight to lever (C) is on the front of the seat. To give a good position to operate the machine.

  • Page 5: Steering Wheel Adjustment

    QUICK START GUIDE STEERING WHEEL ADJUSTMENT STEERING TILT CONTROL When the operators seat is in the correct position to operate the traction pedal comfortably. Push the small foot pedal (A) at the base of the steering column. Tilt the column backward or forward to the correct position.
  • Page 6 QUICK START GUIDE CONTROLS Starter Key Switch Hazard Warning Switch Throttle Control Lever Right Side Unit Lift and Lower Parking Brake Switch Centre Unit Lift and Lower Deck Lock Switch Left Side Unit Lift and Lower Cutter Switch The Cutting Unit is engaged Beacon Right side cutting unit in cutting 4 WD In Reverse...

  • Page 7: Starter Key Switch

    QUICK START GUIDE CONTROLS STARTER KEY SWITCH PARKING BRAKE SWITCH Move the orange button back and press the switch to engage the parking brake. Turn the starter key to the right to start the engine. Release the key to return When the engine is stopped, the parking automatically to the 'on' position for normal brake is applied.
  • Page 8 QUICK START GUIDE CONTROLS HORN BUTTON BEACON SWITCH For machines without the lighting kit. The horn button (A) is on the control panel. If the lighting kit is fitted, the horn is found on the end of the indicator stalk. Operates the vehicles rotating beacon CUTTER SWITCH 4 WHEEL DRIVE IN REVERSE SWITCH...

  • Page 9: Cruise Control

    QUICK START GUIDE CONTROLS AUXILLARY HYDRAULIC SERVICES KIT DIESEL PATRTICULATE FILTER SWITCH SWITCH (OPTIONAL) With the switch in the center position This switch sets the rotary brush or snow (default) it allows automatic Active Regen. blade to a right side or a left side forward Operation of the mower is not changed position.

  • Page 10: How To Drive

    QUICK START GUIDE DRIVING HOW TO DRIVE • Set the throttle to maximum engine speed. • Release the parking brake before you move in a forward or reverse direction. • Forward - Carefully press the top of the Traction pedal to engage forward drive. •...
  • Page 11 QUICK START GUIDE MOWING HOW TO MOW Release any transport locks and lower the cutting units with the joysticks. To engage the cutting mechanism, press the upper half of the cutting unit switch, found on the control panel. Release the parking brake and drive in a forward direction.

  • Page 12: Visual Display

    QUICK START GUIDE VISUAL DISPLAY START UP SCREEN FIRST SCREEN MODE When the ignition key is turned to the start This screen shows the cutter switch in the position, this screen is shown. OFF position, the transport lock engaged, The hour meter will show total hours of the TST is in operation and speed mode.

  • Page 13: Engine Will Not Start

    QUICK START GUIDE VISUAL DISPLAY ENGINE WILL NOT START WARNING SLOPE ANGLE 19° 0° Slopes > = 19° in either x or y When the ignition key is turned to the start If the slope angle reaches 19º the screen will position this screen is shown.

  • Page 14: Warning Oil Pressure Fault

    If this happens during operation, or possible and contact your local Ransomes does not go off when the engine is run at Jacobsen Dealer more than 1000 rpm. Stop the engine and check the oil level.

  • Page 15: Warning Battery Fault

    QUICK START GUIDE VISUAL DISPLAY The number in the top right of the screen WARNING HRDRAULIC OIL LEVEL LOW indicates the total number of faults recorded. Press the button below the  to confirm the fault WARNING BATTERY FAULT When this screen is shown, the hydraulic oil level is low.
  • Page 16 ™ When this screen is shown, there is a fault with the TST. Stop as soon as possible and contact your local Ransomes Jacobsen Dealer The number in the top right of the screen indicates the total number of faults recorded.
  • Page 20 Europe & Rest of The World Except North & South America Ransomes Jacobsen Limited West Road, Ransomes Europark, Ipswich, IP3 9TT English Company Registration No. 1070731 www.ransomesjacobsen.com North & South America Jacobsen, A Textron Company 11108 Quality Drive, Charlotte, NC 28273, USA...
