Back Panel

LABEL
1. 12VDC
2. ON/OFF
3. ETHERNET
4. USB
5. DSL
6. WPS
7. ANTENNA
8. RESET
Downloaded from www.Manualslib.com
M a n u a l
manuals search engine
DESCRIPTION
12V 1.0A DC Input port
Power ON/OFF button
Connecting computers and other Ethernet devices (RJ45)
Connecting USB storage or printer
Connecting the modem to an ADSL line (RJ11)
To setup wireless security with WPS-capable clients
Fixed Wifi Antenna
Underneath the modem
