- Page 1 ELEMENT SERIES POWERED OWNER’S MANUAL SUBWOOFER ES-SUB-ELE8-110 ES-SUB-ELE10-200 ES-SUB-ELE12-300...
- Page 2 ES-SUB-ELE-8-10-12 Owner’s Manual CAUTION Risk of Electrical Shock! DO NOT OPEN! ATTENTION ! RISQUE DE CHOC ! ÉLECTRIQUE PAS OUVRIR ! The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
-
Page 3: Welcome To Episode
1. Welcome to Episode® Episode® is one of the most highly regarded brands of speakers available today. We appreciate your business and we stand committed to providing our customers with the highest degree of quality and service in the industry. -
Page 4: Installation And Setup
ES-SUB-ELE-8-10-12 Owner’s Manual Installation and Setup 3. Overview Proper installation of the Episode® ELE Sub powered subwoofer requires these basic steps: 1. Place the subwoofer in the room. (Page 4) 2. Make connections to the system. (Pages 5 & 6) 3. -
Page 5: Making System Connections
220-240V Preamp Out LOW LEVEL POWER 100-120V~60Hz 1.6A / 220-240V~50Hz 0.8A LFE/ Optional Loop out to more subwoofers SUB Out Use same connection type as input (LFE or L/R) AV Receiver/Processor RCA Outputs Speaker Outputs © 2013 Episode Page 5... -
Page 6: Speaker-Level Connections
ES-SUB-ELE-8-10-12 Owner’s Manual 5.2.2. Speaker-Level Connections WARNING! Do not connect to both the low-level RCA and high-level speaker connections. Use only one connection method. STATUS AUTO ES-SUB-ELE8-110 VOLUME Designed and Engineered in USA Manufactured in China PHASE 0˚ 180˚ CROSSOVER... -
Page 7: Settings And Controls
6.2. Fine Tuning Audio and Operation 1.6A LOW LEVEL After making all the connections and calibrating the loudspeakers, set up your Episode® subwoofer using the following steps: 1. Set the MODE switch to the ‘ON’ position for setup. 2. Plug the subwoofer into an electrical outlet using the included power cord. The status LED will illuminate solid blue when power is present and the subwoofer is on. -
Page 8: Troubleshooting
ES-SUB-ELE-8-10-12 Owner’s Manual 7. Troubleshooting Episode® speakers are designed to function trouble-free. Most problems that occur are due to simple issues. If you have trouble, please check the list of simple fixes below. If the problem persists, contact Episode® Technical Support at 1.866.838.5052. -
Page 9: Connections And Controls
ES-SUB-ELE-8-10-12 Owner’s Manual III. Reference 9. Connections and Controls 9.1. ES-SUB-ELE8-110 STATUS AUTO ES-SUB-ELE8-110 VOLUME Designed and Engineered in USA PHASE Manufactured in China 0˚ 180˚ CROSSOVER HIGH LEVEL 100-120V 220-240V LOW LEVEL POWER 100-120V~60Hz 1.6A / 220-240V~50Hz 0.8A 1. STATUS LED Red- Subwoofer is in standby mode, or power mode switch is set to OFF. -
Page 10: Power Mode Switch
ES-SUB-ELE-8-10-12 Owner’s Manual 9.2. ES-SUB-ELE10-200 & ES-SUB-ELE12-300 ES-SUB-ELE12-300 STATUS Designed and Engineered in USA AUTO Manufactured in China VOLUME CAUTION: ATTENTION: PHASE For continued Protection against risk Utiliser un fusible de rechange de of fire, replace only with same type meme type et calibre. -
Page 11: Specifications
11. 10/2-Year Limited Warranty Episode® Subwoofers have a 2-Year Warranty on the amplifier and a 10-Year Warranty on the woofer and box. This warranty includes parts and labor repairs on all components found to be defective in material or workmanship under normal conditions of use. - Page 12 Rev: 140819-1400...
