Okina USA SIR36-870VF650LP User Manual

700 tvl long distance smart shift 36 ir license plate capture camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SIR36-870VF650LP
700 TVL Long Distance Smart Shift
36 IR License Plate Capture Camera

FEATURES

•
700 TVL
•
1/3" Sony Exview HAD CCD II
•
6.0~50.0mm Varifocal 1.3 Megapixel Lens
•
36 IR LED; Distance up to 200ft / 60m
•
Mechanical IR Cut Filter
•
1100mA max @ Boot up
1250mA max @ IR on ; 260mA max @ IR off
•
12V DC / 24V AC
•
IP67 Rating
Please read the Manual before attempting to use this product.
** THIS CAMERA IS DESIGNED FOR LICENSE PLATE CAPTURE **
Copyright © 2014. All Rights Reserved.

USER MANUAL

Specifications and appearance are subject to change without notice.
L-819
R201407-V24

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SIR36-870VF650LP and is the answer not in the manual?

Questions and answers

Related Manuals for Okina USA SIR36-870VF650LP

Summary of Contents for Okina USA SIR36-870VF650LP

  • Page 1: Features

    SIR36-870VF650LP 700 TVL Long Distance Smart Shift 36 IR License Plate Capture Camera USER MANUAL FEATURES • 700 TVL • 1/3” Sony Exview HAD CCD II • 6.0~50.0mm Varifocal 1.3 Megapixel Lens • 36 IR LED; Distance up to 200ft / 60m •...

  • Page 2: Safety Precautions

    License Plate Capture Series SIR36-870VF650LP Disposal of Old Electrical & Electronic Equipment (Applicable in the European Union and other European countries with separate collection systems.) This symbol on the product or on its packaging indicates that this product shall not be treated as household waste.

  • Page 3: Table Of Contents

    LIMITED WARRANTY OKINA USA products are covered under warranty for one (1) year from the date of purchase. The warranty will automatically be voided if any of the following occurs: 1. Camera sticker is removed If the camera sticker is removed, we will not be able to confirm any information regarding when and where the product was purchased.

  • Page 4: Package Contents

    License Plate Capture Series SIR36-870VF650LP PACKAGE CONTENTS One (1) SIR36-870VF650LP LPC Camera Four (4) Wall Mounting Screws Four (4) Wall Anchors One (1) Rubber Washer One (1) Sticker Mounting Template One (1) User Manual * For any returns, please include all components listed above with original packaging in Resalable Condition.

  • Page 5: Functions

    License Plate Capture Series SIR36-870VF650LP FUNCTIONS The camera includes auto white balance mode (AWB) auto capture and color temperature. The range is 2400°K~9600°K. SENSOR：Auto Cell Device Sensor, the IR LED would on when night comes to make up lightness. IR LED would not on in the day, to reduce power consumption.

  • Page 6: Cable Management Bracket

    License Plate Capture Series SIR36-870VF650LP Remove the focus/zoom knob cover to access adjustment knobs. OSD KEYPAD NC (No function) D/N, day and night switcher NC (No function) Reflection LED switch (for 18 pcs of reflection LED) : IR on / IR off...
  • Page 7 License Plate Capture Series SIR36-870VF650LP Setup menu description. Menu Item Description Lens Defines the lens brightness and iris speed. Exposure Defines the method of iris control. Defines the highlight compensation (HLC), backlight compensation (BLC), and high Backlight spotlight compensation (HBLC) set up.
  • Page 8 License Plate Capture Series SIR36-870VF650LP ※ Shutter speed corresponding with car speed Shutter Speed Car Speed Camera to Object Distance 1/60 ~ 1/120 6~12mph / 10~20km 100~130ft / 30~40m 1/150 ~ 1/300 18~37mph / 30~60km 50~65ft / 15~20m 1/310 ~ 1/500...
  • Page 9 License Plate Capture Series SIR36-870VF650LP HSBLC 1. GAIN 2. MODE NIGHT ONLY 3. MASK LEVEL ↵ 4. DEFAULT 5. M. SKIP AREA 6. RETURN RET↵ 3-3-1 Gain: adjust gain value. The values range from 0 to 100. 3-3-2 Mode: only when the HSBLC is enabled. It can be set to Night ONLY or ALL DAY.
  • Page 10 License Plate Capture Series SIR36-870VF650LP Night → Day: Set the threshold level on how light it should be before switching from Night to Day mode. The values range from 0 to 160. D&N Auto 1. DELAY 2. D→N(AGC) 3. N→D(AGC) 4.
  • Page 11 License Plate Capture Series SIR36-870VF650LP 6. SMART 3DNR Smart 3D noise reduction reduces the background noise in a low luminance environment with 2D + 3D filtering system In the main menu, select SMART 3DNR to set up noise reduction. SMART 3DNR 1.
  • Page 12 License Plate Capture Series SIR36-870VF650LP 8. FUNCTION There are additional functions are available in this section. In the main menu, select function and press enter, the below figure shows the different options available. FUNCTION 1. MOTION 2. PRIVACY ↵ 3. D-EFFECT ↵...
  • Page 13 License Plate Capture Series SIR36-870VF650LP 8-2-1 Area: Select the privacy mask (AREA1 to AREA8) that you want to configure. Each privacy mask is already associated with a pre-selected color which you can change using the COLOR setting. 8-2-2 Area display: Choose whether to enable the selected privacy mask. If enabled, you can also customize the position and size of the privacy mask.
  • Page 14 License Plate Capture Series SIR36-870VF650LP 8-3-2-1 Range: set the zoom in / out. The values range from x2 to x5. 8-3-2-2 Position: defines the zoom area. When a motion is detected, it can automatically zoom in/out. 8-3-2-3 Sensitivity: set the sensitivity level for activation (ranged from 0 ~100).
  • Page 15 License Plate Capture Series SIR36-870VF650LP Gamma: Gamma correction controls and adjusts the overall brightness of an image for consistency. The values range from 0.05 to 1.00 Ped level: defines the master pedestal level value. The values range from 0 to 63.
  • Page 16 License Plate Capture Series SIR36-870VF650LP To enter a character, move the cursor to the desired character and press Enter & select it. It appears in the input line. Repeat the process until all characters are entered. To move the character, input position in the input line, move the cursor in the command line to ← or → and press Enter.

  • Page 17: Rules To Design License Plate Capture Camera

    License Plate Capture Series SIR36-870VF650LP RULES TO DESIGN LICENSE PLATE CAMERA 1. Location and Trajectory Please note the following diagram: In order to obtain the most optimal image, place the camera where it can obtain a clear, straight view of the license plate.

  • Page 18: Recommended Camera Keyboard Controller

    The quality of the DVR used is also an important factor for this application. A high-resolution DVR capable of recording at 20 to 30 FPS per channel is the minimum requirement for recording of SIR36-870VF650LP images. To have optimal recorded playback performance, a 30 FPS DVR is suggested.
  • Page 19 License Plate Capture Series SIR36-870VF650LP Enter LENS then Under MAIN MENU, configure the BRIGHTNESS value until you can see the License Plate. After BRIGHTNESS configuration please have vehicle drive by to see Front and Rear License Plate, it may have an little blurring when vehicle is moving, please adjust Automatic gain control (AGC) value when during the vehicle driving.

  • Page 20: Specifications

    License Plate Capture Series SIR36-870VF650LP SPECIFICATIONS Model SIR36-870VF650LP Image Sensor 1/3” Sony Exview HAD CCD II Total Pixels NTSC: 1028(H) x 508(V) / PAL: 1028H) x 596(V) Effective Pixels NTSC: 976(H) x 494(V) / PAL: 976(H) x 582(V) Resolution 700 TV Lines...
