SERVICE MANUAL
FAN COIL-CASSETTE
SF-08C, SF-12C, SF-16C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SF-08C and is the answer not in the manual?

Questions and answers

Related Manuals for Sinclair SF-08C

Summary of Contents for Sinclair SF-08C

  • Page 1 SERVICE MANUAL FAN COIL-CASSETTE SF-08C, SF-12C, SF-16C...
  • Page 2 PRODUCT Cooling Model Name Capacity Volume Remarks (V, Ph, Hz) SF-08C 4600/7500 220-240V~ 50Hz SF-12C 6700/10500 1270 220-240V~ 50Hz SF-16C 8700/12900 1640 220-240V~ 50Hz...
  • Page 3 Model SF-08C SF-12C SF-16C Type V-Ph-Hz 220-240V- 50Hz 220-240V- 50Hz 220-240V- 50Hz Power systém Input High 1250 1640 Airflow volume Medium 1030 1450 1328 Cooling 4640 6700 8700 Capacity Heating 7500 10500 12900 Electric heater rated power 1400 1400 1400 Water flow volume 0.81...
  • Page 4 Cooling capacity .

  • Page 5: Wireless Remote Controller

    CONTROL 1. WIRELESS REMOTE CONTROLLER 1.1 YB1F2(X-FAN)
  • Page 8 Press MODE button to select desired running mode. Press +/ - button to set the desired temperature.(It is unnecessary to set the temperature at AUTO mode) be selected. Press Press TIMER button, then press +/- button, About AUTO RUN temp. approachs the preset temp. as soon as possible. About lock the icon 3.4 Changing batteries and notices...
  • Page 9 When the remote control sends out signal, a mark 1.2 YB1FA(X-FAN) AUTO COOL HEAT ON/OFF button MODE button Press this button, Auto, Cool, Dry, Fan Heat mode can be selected circularly. FAN button...
  • Page 10 AUTO Medium High CLOCK button blinks and displays, you can set the time by pressing displays on the LIGHT button set,the mark X-FAN button - button Presetting temperature can be decrease the temperature by 1 degree Celsius degree Celsius. + button Press this button increase the temperature by 1 degree Celsius once.
  • Page 11 TIMER ON again to cancel the setting. TIMER OFF button b. Press TIME ON and TIME OFF button to scheduled the unit ON/OFF. b. Press MODE button, select desired running mode ,or press COOL or HEAT mode to enter the corresponding operation directly.

  • Page 12: Wired Remote Controller

    2. WIRED REMOTE CONTROLLER 2.1 Introduction to Z5K351(optional) NOTE Time display MODE button FAN button Ambient temp. display Fresh air display TIMER button Mode(COOL, DRY, FAN, AUTO) ON/OFF button...
  • Page 13 2.2 Introduction to Z4E351B (optional) Function Description It indicates the sleeping status. It indicates the “ Cool ” mode. It indicates the “ Dry ” mode. It indicates the “ Fan ” mode. It indicates the “ Heat ” mode. It indicates the gate control status.
  • Page 14 It indicates the turbo status. It indicates the ambient temperature/set temperature. It indicates the timer status. Quiet ” and “ Auto Quiet ”. ) Note Press Bottoms Function Description Enter/Cancel Quiet ” and “Auto Quiet ”. Cool ”,“ Dry ”, “ Fan ”, and “ Heat ”. (2) When the “Save Mode Heat ”...

  • Page 15: Selection The Mounting Position

    INSTALLTION 1. SELECTION THE MOUNTING POSITION 39''(1,000mm) or more 4''(100mm) or more 4''(100mm) or more (2 directions) (2 directions) (3 directions) (4 directions) Piping position 4''(100mm) or more pipe pipe indoor unit. The ceiling rear height is 9-3/8 " inches(250mm) or more.

  • Page 16: Precautions For Drainage Raising Pipe

    Water pipe 840(Indoor unit ) 890(Ceiling opening) SF-08C, SF-12C, SF-16C 2. DRAINAGE PIPE 1-1.5m (Wrong) Heat insulation should be done to indoor drain hose. 3. PRECAUTIONS FOR DRAINAGE RAISING PIPE...
  • Page 17 300mm. 3.1 Instruction guaranteed. Spanner Thread fasten Valve Torque wrench Tape Wiring interface water inlet tube Water tube joint Flare nut insulation.

  • Page 18: Electric Wiring

    Body Intlet tube Outlet tube WATER VALVE Warning 4. ELECTRIC WIRING 5. Earth properly. 4.1 Wiring of unit and the controller Wiring of the controller...

  • Page 19: Installation Of Panel

    Precautions 5. INSTALLATION OF PANEL Install the decoration panel. rise) 6. Body is reduced to 5~8 mm.
  • Page 20 5.1 Precautions indoor unit body.

  • Page 22: Care And Maintenance

    MAINTENANCE 1.TROUBLESHOOTING Error code Error Water pump error Communications error Indoor temperature sensor error at the return air inlet 2.CARE AND MAINTENANCE Warning: buckle 1. Open the suction grille. Note: 4. The suction grille must be opened by skilled personnel.
  • Page 23 How to clean to the suction grille 1. Open the suction grille 7. Close the suction grille. Changing air cleaner 1. Open the suction grille...
  • Page 24 Cassette Type Fan Coil Unit Service Manual How to clean the air outer and case. outlets parts on both the indoor and outdoor units. damaged. End of season cleaning...

  • Page 25: Wiring Diagram

    Cassette Type Fan Coil Unit Service Manual 3. WIRING DIAGRAM SF-08C, SF-12C, SF-16C LIMIT WATER VALVE LIQUID HEAT PIPE TEMP Manual Panel ROOM TEMP COMMUNICATION CORD is the optional accessory PUMP MOTOR POWER FANM OTOR Temperature limiter...

  • Page 26: Disassembly And Assembly Procedure Of Main Parts

    Cassette Type Fan Coil Unit Service Manual 4. DISASSEMBLY AND ASSEMBLY PROCEDURE OF MAIN PARTS Model;SF-08C, SF-12C, SF-16C Process Handling Description 1.Disassemble Plug 2. Disassemble 3. Disassemble the drain pan. 4.Disassemble...
  • Page 27 Cassette Type Fan Coil Unit Service Manual 5.Disassemble the 6.Disassemble the drain pan asher Fan Blade 7.Disassemble...
  • Page 28 Cassette Type Fan Coil Unit Service Manual Mounting Plate Ba le take it out. 8. Disassemble Connection Board Clamp electric heater and earth lead out through the Motor 9. Disassemble the motor motor out. Retaining Plate 10. Disassemble Drain Pipe and the drain pipe...

  • Page 29: Exploded Views And Spare Part Lists

    Cassette Type Fan Coil Unit Service Manual 5. EXPLODED VIEWS AND SPARE PART LISTS SF-08C, SF-12C, SF-16C...
  • Page 30 Cassette Type Fan Coil Unit Service Manual SF-08C SF-12C Discription Quantity Part Code Part Code 02217102 02217102 01332701 01332701 01302718 01302718 01302715 01302715 Base Plate 01222701 01222701 01302714 01302714 Bottom Foam 52012722 52012722 Motor Gasket 76712711 76712711 Bolt M6 70212711...
  • Page 31 Cassette Type Fan Coil Unit Service Manual SF-16C Discription EM52000080 Quantity Part Code 02217102 01332701 01302713 01302711 Base Plate 01222732 01302709 Bottom Foam 52012721 Motor Gasket 76712711 Bolt 70210012 01702701 Motor FN50T 15012710 Electric Heater 32002701 10310101 01072735 Cable-cross Loop 76515202 Tube sensor 3900012125...
