Before Starting a Print Job
Always check the following points:
• unit connected correctly? (page 9)
• Printer driver installed? (page 9)
• Paper loaded correctly? (page 10)
• Menu settings and menu adjustments done correctly?
Starting a Print Job
Press the power ON/OFF switch to turn the unit on.
The back light on the LCD lights in green, and
"READY" is displayed on the LCD.
Execute the print job with the software application.
When the message is displayed on the LCD
If a problem occurs, the back light on the LCD lights in
umber and the error message stating the problem is
displayed on the LCD.
Cause and remedy
Paper is not loaded. Load paper.
The door is open. Close the door.
When the unit stops printing during printing
When printing almost black images continuously, the
thermal head protection circuit may shut down the unit
to prevent the thermal head from overheating. In such a
case, the message "COOL" is displayed on the LCD.
Leave the unit until the head cools down and this
Paper currently selected
You can confirm the paper currently selected on the
LCD. The pointer points to the paper currently selected.
In the following figure, the currently selected paper is
the UPP-110S paper.
Indicates the UPP-110S
Indicates the UPP-110HD
Indicates the UPP-110HG
Cancelling a Print Job
To cancel a print job in progress, press the OPEN button
or the FEED button.
Making Copies of the Last Printout
Press the COPY button. The unit makes a copy of the
last printout. The image of the last printout is retained in
the unit's memory until you make a printout of another
image or turn the power off. You can make only one
copy regardless of the print quantity set using the menu.
If you press the COPY button immediately after turning
the power on, the alarm buzzer will sound as nothing is
stored in memory.
To make multiple copies of the same printout
Press the COPY button as many times as necessary
(maximum 20 copies including the first printout) while
copying the first printout. Each time you press the
COPY button, a short buzzer sounds.
To interrupt copying
Press the OPEN or FEED button while copying.
To feed paper, press the FEED button. The unit will
continue to feed paper as long as you hold down the
FEED button. Do not attempt to pull paper out of the
unit with your hand.
