DW DWC-MV421D User Manual page 12

Megapix 1080p snapit outdoor dome ip camera
Table of Contents

Advertisement

INSTALLATION*
C e i l i n g M o u n t f o r V 4 H o u s i n g
1
1.
Verify all parts are in
the box.
4
4.
Use the mounting
template to make pilot
holes. Use the dry wall
anchors and wood
screws to attach the
assembly to the wall.
2.
Attach the top shield to
the pendant mount.
5
5.
Connect all cables and
verify camera is
operating properly.
2
3.
6.
3
Run all necessary
cables from the
ceiling to the mount.
6
Attach the camera to
the ceiling mount
and secure the cover
dome properly.
