Icom IC-M73 Service Manual page 23

[RF UNIT]
REF PARTS
NO. NO.
C62 4030017460 S.CER C1005 JB 1H 102K-T
C63 4030016790 S.CER C1005 JB 1E 103K-T
C64 4030017460 S.CER C1005 JB 1H 102K-T
C65 4030017430 S.CER C1005 CH 1H 101J-T
C66 4030017460 S.CER C1005 JB 1H 102K-T
C67 4030017730 S.CER C1005 JB 1H 471K-T
C68 4030017420 S.CER C1005 CH 1H 470J-T
C69 4030017460 S.CER C1005 JB 1H 102K-T
C70 4030007100 S.CER C1608 CH 1H 560J-T
C71 4030007060 S.CER C1608 CH 1H 270J-T
C72 4030006860 S.CER C1608 JB 1H 102K-T
C73 4030017460 S.CER C1005 JB 1H 102K-T
C74 4030017460 S.CER C1005 JB 1H 102K-T
C77 4030016930 S.CER C1005 JB 1A 104K-T
C78 4030016930 S.CER C1005 JB 1A 104K-T
C80 4030017460 S.CER C1005 JB 1H 102K-T
C81 4030017390 S.CER C1005 CH 1H 180J-T
C82 4030017390 S.CER C1005 CH 1H 180J-T
C83 4030017400 S.CER C1005 CH 1H 220J-T
C84 4030018120 S.CER C1005 CH 1H 110J-T
C85 4030017410 S.CER C1005 CH 1H 240J-T
C86 4030017610 S.CER C1005 CH 1H 090C-T
C89 4030017590 S.CER C1005 CH 1H 070C-T
C90 4030017610 S.CER C1005 CH 1H 090C-T
C91 4030017620 S.CER C1005 CH 1H 100C-T
C94 4030017380 S.CER C1005 CH 1H 050B-T
C95 4030017640 S.CER C1005 CH 1H 150J-T
C96 4030017460 S.CER C1005 JB 1H 102K-T
C97 4030017550 S.CER C1005 CH 1H 1R5B-T
C98 4030017550 S.CER C1005 CH 1H 1R5B-T
4030017550 S.CER C1005 CH 1H 1R5B-T
4030017340 S.CER C1005 CH 1H 010B-T
4030017340 S.CER C1005 CH 1H 010B-T
4030017340 S.CER C1005 CH 1H 010B-T
4030017340 S.CER C1005 CH 1H 010B-T
4030017340 S.CER C1005 CH 1H 010B-T
4030017550 S.CER C1005 CH 1H 1R5B-T
4030017550 S.CER C1005 CH 1H 1R5B-T
4030017550 S.CER C1005 CH 1H 1R5B-T
4030017340 S.CER C1005 CH 1H 010B-T
4030017340 S.CER C1005 CH 1H 010B-T
4030017340 S.CER C1005 CH 1H 010B-T
4030017340 S.CER C1005 CH 1H 010B-T
4030017340 S.CER C1005 CH 1H 010B-T
4030017550 S.CER C1005 CH 1H 1R5B-T
C99 4030017660 S.CER C1005 CH 1H 330J-T
C100 4030017560 S.CER C1005 CH 1H 2R5B-T
C101 4030017640 S.CER C1005 CH 1H 150J-T
4030017640 S.CER C1005 CH 1H 150J-T
4030017620 S.CER C1005 CH 1H 100C-T
4030017620 S.CER C1005 CH 1H 100C-T
4030017620 S.CER C1005 CH 1H 100C-T
4030017620 S.CER C1005 CH 1H 100C-T
4030017620 S.CER C1005 CH 1H 100C-T
4030017640 S.CER C1005 CH 1H 150J-T
4030017640 S.CER C1005 CH 1H 150J-T
4030017640 S.CER C1005 CH 1H 150J-T
4030017620 S.CER C1005 CH 1H 100C-T
4030017620 S.CER C1005 CH 1H 100C-T
4030017620 S.CER C1005 CH 1H 100C-T
4030017620 S.CER C1005 CH 1H 100C-T
4030017620 S.CER C1005 CH 1H 100C-T
4030017640 S.CER C1005 CH 1H 150J-T
C102 4030016790 S.CER C1005 JB 1E 103K-T
C103 4030017420 S.CER C1005 CH 1H 470J-T
C104 4030016790 S.CER C1005 JB 1E 103K-T
C109 4030017460 S.CER C1005 JB 1H 102K-T
C110 4030017670 S.CER C1005 CH 1H 390J-T
C111 4030017460 S.CER C1005 JB 1H 102K-T
C112 4030017560 S.CER C1005 CH 1H 2R5B-T
C113 4030017540 S.CER C1005 CH 1H R75B-T
C114 4030017650 S.CER C1005 CH 1H 270J-T
C115 4030017380 S.CER C1005 CH 1H 050B-T
C116 4030017350 S.CER C1005 CH 1H 020B-T
C119 4030017500 S.CER C1005 CH 1H 560J-T
C120 4030016970 S.CER C1005 JB 1E 223K-T
C121 4030017460 S.CER C1005 JB 1H 102K-T
C122 4030016790 S.CER C1005 JB 1E 103K-T
C125 4030016930 S.CER C1005 JB 1A 104K-T
C126 4030018860 S.CER C1005 JB 0J 105K-T
C131 4030017630 S.CER C1005 CH 1H 120J-T
C154 4030017460 S.CER C1005 JB 1H 102K-T
C155 4030017360 S.CER C1005 CH 1H 030B-T
C156 4030017460 S.CER C1005 JB 1H 102K-T
C157 4030016970 S.CER C1005 JB 1E 223K-T
C158 4030017460 S.CER C1005 JB 1H 102K-T
C159 4030016790 S.CER C1005 JB 1E 103K-T
C160 4030016780 S.CER C1005 JB 1E 153K-T
C220 4030019560 S.CER GRM21BB31C106KE15L
C223 4030016790 S.CER C1005 JB 1E 103K-T
C225 4030011770 S.CER C1608 CH 1H 060B-T
C380 4030017460 S.CER C1005 JB 1H 102K-T
C381 4030017460 S.CER C1005 JB 1H 102K-T
C400 4030017420 S.CER C1005 CH 1H 470J-T
C401 4030017420 S.CER C1005 CH 1H 470J-T
C402 4030017420 S.CER C1005 CH 1H 470J-T
C510 4030017460 S.CER C1005 JB 1H 102K-T
C512 4030017460 S.CER C1005 JB 1H 102K-T
J101 6510025121 S.CON 30RF-JMCS-G-1B-TF(N)(LF)(SN)
S250 2260002800 S.SWI SW-167 (SKQTLAE010)
S328 2260002800 S.SWI SW-167 (SKQTLAE010)
Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
DESCRIPTION M.
LOCATION
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
B
B
B
B
B
B
[USA] B
[EXP]
[EUR-01]
[EUR]
[UK]
[FRG]
[HOL]
[AUS]
[USA-10]
[EXP-10]
[EUR-11]
[EUR-10]
[UK-10]
[FRG-10]
[HOL-10]
[AUS-10]
B
B
[USA] B
[EXP]
[EUR-01]
[EUR]
[UK]
[FRG]
[HOL]
[AUS]
[USA-10]
[EXP-10]
[EUR-11]
[EUR-10]
[UK-10]
[FRG-10]
[HOL-10]
[AUS-10]
B
B
B
B
B
B
B
B
B
B
B
B
B
B
T
T
T
T
B
T
B
B
B
B
B
T
T
T
T
T
T
T
T
B
B
T
T
T
[RF UNIT]
H/V REF PARTS
NO. NO.
16.6/13.8 EP2 6910014690 S.BEA
14.1/13.7 EP3 6910014690 S.BEA
11.4/3.8
12.3/5.1
14.3/2.6
18.7/12.2
22.1/13.1
13.2/13.7
21.5/1.7
25.9/3.8
23.2/5.2
29.8/11.6
26.6/8.6
10.5/3.8
12.9/3.8
28.5/4.8
24.8/5.1
25.0/6.0
28.8/6.5
30.1/4.3
29.7/5.6
30.4/9.4
32.2/4.3
23.4/4.0
26.6/6.2
26.7/10.4
24.9/20.5
21.0/21.1
29.3/14.2
24.4/19.2
24.0/20.5
23.0/17.1
22.4/18.3
19.3/17.5
19.3/18.4
20.5/18.6
17.0/15.9
15.7/19.1
15.7/21.5
16.2/14.1
14.5/16.0
14.0/20.6
14.0/17.2
12.9/16.0
7.3/17.6
8.2/17.5
7.2/16.4
8.0/17.1
14.4/27.3
14.7/26.4
8.0/13.1
4.6/11.7
3.7/20.8
2.5/29.7
4.6/29.3
3.7/29.3
7.9/25.3
10.0/21.7
12.8/33.0
22.4/16.4
21.5/4.3
21.9/18.7
25.4/18.7
18.0/27.1
18.6/25.4
8.7/32.0
1.5/3.7
5.8/1.8
11.8/20.1
20.0/39.9
5.0/39.9
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
6-6
DESCRIPTION M.
MPZ1608S221A-T T
MPZ1608S221A-T T
S.=Surface mount
H/V
LOCATION
15.4/15.0
18.3/13.4
