5-4 User's Reference Guide

10Base-T

You can connect a standard 10Base-T Ethernet network to the Netopia R2121 using any of its available
Ethernet ports.
Netopia R2121 back panel
Ethernet
The Netopia R2121 in a 10Base-T network
To connect your 10Base-T network to the Netopia R2121 through an Ethernet port, use a 10Base-T cable with
RJ-45 connectors.
If you have more than eight devices to connect, you can attach additional devices using either a 10Base-T hub
or an EtherWave™ daisy chain, or some combination of both.
8 7 6 5
4 3 2 1
Auxiliary
Telco 2
Normal/Uplink
1
Ethernet
Phone 2
Console
8
4
Normal/
1
Phone 1
Power
Telco 1
