Outdoor split-system heat pumps

Advertisement

INSTALLATION INSTRUCTION
GENERAL
This instruction covers the installation of the following outdoor
units: E1FB012A(S)06, E1FB018A(S)06, E1FB024A(S)06,
E1FB030A(S)06, E9FB012S06, E9FB018S06, E9FB024S06,
and E9FB030S06.
The outdoor units are designed to be connected to a matching
indoor coil with either quick or sweat connect lines. Quick
connect units are factory charged with refrigerant for a match-
ing indoor coil and factory charged line sets are available in
various lengths. Sweat connect units are factory charged with
refrigerant for a matching indoor coil plus 15 feet of field
supplied lines.
Matching indoor coils are available with a thermal expansion
valve or an orifice liquid feed (YORKMATE flow control device)
sized for the most common usage. The orifice size and/or
refrigerant charge may need to be changed for some indoor-
outdoor unit combinations, elevation differences or total line
lengths. Refer to Application Data covering "General Piping
Recommendations and Refrigerant Line Length".
INSPECTION
As soon as a unit is received, it should be inspected for possible
damage during transit. If damage is evident, the extent of the
damage should be noted on the carrier's freight bill. A separate
request for inspection by the carrier's agent should be made in
writing. See Form 50.15-NM for more information.
REFERENCE
Use this instruction in conjunction with the instructions for the
appropriate indoor unit, air moving system and accessories.
Installer should pay particular attention to the words: NOTE,
CAUTION and WARNING.
NOTES are intended to clarify or make the installation easier.
®
SPLIT-SYSTEM HEAT PUMPS
Supersedes: 515.26-N1Y (1291)
MODELS E1FB012 thru E1FB030
AND E9FB012 thru E9FB030
OUTDOOR
CAUTIONS are given to prevent equipment damage.
WARNINGS are given to alert the installer that personal injury
and/or equipment damage may result if installation procedures
are not followed properly.
NOMENCLATURE
Product Category
E = Outdoor Split System Heat Pump
Product Generation
1 = Design Level
9 = Canada
Product Identifier
FB = High Efficiency Heat Pump
Nominal Cooling Capacity
012 = 1 Tons
024 = 2 Tons
030 = 2.5 Tons
018 = 1.5 Tons
Refrigerant Line Connections
A = Quick-Connect Fittings
S = Sweat Fittings
Voltage Code
06 = 208/230-1-60
LIMITATIONS
The unit should be installed in accordance with all national and
local safety codes.
Limitations for the indoor unit, coil and appropriate accessories
must also be observed.
The outdoor unit must not be installed with any ductwork in the
air stream. The outdoor fan is the propeller type and is not
designed to operate against any additional external static pres-
sure.
The maximum and minimum conditions for operation must be
observed to assure a system that will give maximum perform-
ance with minimum service.
LOCATION
TABLE 1 - APPLICATION LIMITATIONS
AIR TEMPERATURE °DB
ON OUTDOOR COIL
Min.
Max.
Cool
Heat
Cool
Heat
50
-10*
115
75
* If ambient will be below this, Accessory Kit 2LT06700224 must be installed to
cutoff heat pump.
** Operation below this temperature is permissible for a short period of time,
during morning warm-up.
515.26-N1Y (1092)
035-10021
E
1
FB 018 A
06
AIR TEMPERATURE
ON INDOOR COIL
Min.
Max.
°WB
°DB
°WB
°DB
Cool
Heat
Cool
Heat
57
50**
72
80

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E1FB012 and is the answer not in the manual?

Questions and answers

Summary of Contents for York E1FB012

  • Page 1 INSTALLATION INSTRUCTION 515.26-N1Y (1092) Supersedes: 515.26-N1Y (1291) 035-10021 MODELS E1FB012 thru E1FB030 AND E9FB012 thru E9FB030 CAUTIONS are given to prevent equipment damage. WARNINGS are given to alert the installer that personal injury and/or equipment damage may result if installation procedures are not followed properly.
  • Page 2: Installation Procedures

    515.26-N1Y Before starting the installation, select and check the suitability Normal operating sound levels may be objectionable if the unit of the location for both the indoor and outdoor unit. Observe all is placed directly under windows of certain rooms (bedrooms, limitations and clearance requirements, see Figure 2.
  • Page 3: Unit Placement

    515.26-N1Y 4. Route the vapor and liquid lines. 6. Make a hole(s) in the structure wall large enough to accom- modate the insulated vapor line, the liquid line and the 5. Connect tubing and leak test. wiring. 6. Make electrical control connections. ELECTRICAL CONNECTIONS 7.
  • Page 4: Indoor Unit

    515.26-N1Y The crankcase heater, when furnished, is energized whenever the field supplied disconnect switch where it will be easily seen. the compressor is not running. Check for proper operation by See below: feeling for heat on the compressor where the heater is installed. The heater should be energized for at least 8 hours before the thermostat is set to operate the compressor.
  • Page 5: Tubing Connections

    515.26-N1Y DEFROST Additional charge is required for inter-connecting piping greater than 15 feet for sweat units and some indoor coil matches. The unit has a demand defrost control. The lines should be installed so that they will not obstruct service access to the coil, air handling system or filter. Install During troubleshooting, defrost can be initiated by shorting the lines with as few bends as possible.
  • Page 6 515.26-N1Y Pack fiber glass insulation and a sealing material such as Each coil will have an orifice installed in the fitting between the permagum around refrigerant lines where they penetrate a wall liquid line connection and distributor. The orifice is identified on to reduce vibration and to retain some flexibility.
  • Page 7 515.26-N1Y tion. However, if another orifice should be used, see the coil DO NOT OVERTIGHTEN (between 40 and 60 inch-lbs. instruction for details to change the orifice in the coil. maximum). 6. Do not remove the flare caps from the service ports except when necessary for servicing the system.
  • Page 8: Line Installation

    515.26-N1Y Valve can be opened by removing the plunger cap and fully NOTE: Do not use the system refrigerant in the outdoor unit inserting a hex wrench into the stem and backing out counter- to purge or leak test. clockwise until valve stem just touches retaining ring. 8.
  • Page 9: System Charge

    515.26-N1Y EVACUATION NOTE: The charge for pre-charged lines should be included in the system charge shown on the data plate but need It will be necessary to evacuate the system if the unit has not be added to the system. If sweat connect lines are developed a leak during shipment or was, for any other reason, used, the line charge over 15 feet should be included opened to the atmosphere.
  • Page 10: System Operation

    515.26-N1Y WHEN THE SYSTEM IS FUNCTIONING PROPERLY AND WITH POWER TO UNIT AND THERMOSTAT IN COOLING THE OWNER HAS BEEN FULLY INSTRUCTED, SECURE POSITION. THE OWNER’S APPROVAL. 1. Reversing valve is energized through thermostat system INDICATIONS OF PROPER OPERATION switch to position refrigerant circuit for cooling operation. In the cooling cycle, discharge gas is pumped to the outdoor COOLING coil which is the condenser.
  • Page 11: Defrost Cycle

    515.26-N1Y and start the system, if the compressor has been off 5 temperature. This could cause a lockout due to high discharge minutes. With fan switch in “AUTO” position, a circuit is pressure! made from thermostat heating contact through blower relay to provide blower operation.
  • Page 12: Maintenance

    Allow solution to remain on coil for 30 minutes attempt start. Wait 5 minutes. If system does not start, call serviceman. Official Sponsor of the 1992 U.S. Olympic Team 36USC380 P.O. Box 1592, York, Pennsylvania USA 17405-1592 Subject to change without notice. Printed in U.S.A.
